BR0A5–05

F13329

N·m (kgf·cm, ft·lbf)  : Specified torque

8.0 (82, 71 in.·lbf)

8.0 (82, 71 in.·lbf)

BR–58

–

BRAKE

REAR SPEED SENSOR

3225

REAR SPEED SENSOR

COMPONENTS

BR0A6–04

F13328

–

BRAKE

REAR SPEED SENSOR

BR–59

3226

REMOVAL

1.

DISCONNECT SPEED SENSOR CONNECTOR

2.

REMOVE SPEED SENSOR

(a)

Remove the 6 resin clips holding the sensor wire harness.

(b)

Remove the bolt and speed sensor from the axle carrier.
Torque: 8.0 N·m (82 kgf·cm, 71 in.·lbf)

BR0A7–07

BR–60

–

BRAKE

REAR SPEED SENSOR

3227

INSTALLATION

Installation is in the reverse order of removal (See page

BR–59

).

HINT:
After installation, check speed sensor signal (See page

DI–899

).

SR01S–06

–

STEERING

STEERING SYSTEM

SR–1

3228

STEERING SYSTEM

PRECAUTION

Care must be taken to replace parts properly because they could affect the performance of the
steering system and result in a driving hazard.

The SEQUOIA is equipped with an SRS (Supplemental Restraint System) such as the driver air-
bag and front passenger airbag. Failure to carry out service operation in the correct sequence
could cause the SRS to unexpectedly deploy during servicing, possibly leading to a serious
accident. Before servicing (including removal or installation of parts, inspection or replace-
ment), be sure to read the notices precautionary in the RS section.

When disconnecting the battery terminal, initialize the following system after the terminal is re-
connected.

System Name

See Page

Back Door Power Window Control System

BE–77

When replacing the steering angle sensor, drive the vehicle straight ahead at a speed of 6.5 mph
(10.5 km/h) or more. Accordingly, zero point calibration of the steering angle sensor is per-
formed.

After performing ”Front wheel alignment adjustment”, clearing and reading the yaw rate & de-
celeration sensor zero point calibration data is necessary (See page

DI–897

).
