Toyota Highlander (2018 year). Manual - part 148

604

8-2. Steps to take in an emergency

Once

3 times

The driver’s door was opened
and closed while the electronic
key was not in the vehicle, the
shift lever was in P and the
engine switch was not turned
off.
→ Turn the engine switch off.

→ Bring the electronic key

back into the vehicle.

The electronic key was carried
outside the vehicle and a door
other than the driver’s door was
opened and closed while the
engine switch was in a mode
other than off.
→ Bring the electronic key

back into the vehicle.

Once

⎯

The electronic key is not
detected when an attempt is
made to start the engine.
→ Start the engine with the

electronic key present.

9
times

⎯

An attempt was made to drive
when the electronic key was not
inside the vehicle.
→ Confirm that the elec-

tronic key is inside the
vehicle.

⎯

Contin-
uous

An attempt was made to lock
the doors using the smart key
system while the electronic key
was still inside the vehicle.
→ Retrieve the electronic key

from the vehicle and lock
the doors again.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

(Flashes)

(Flashes)

(Flashes)

605

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

Once

Contin-
uous

An attempt was made to lock
either front door by opening a
door and putting the inside lock
button into the lock position,
then closing the door with the
electronic key still inside the
vehicle.
→ Retrieve the electronic key

from the vehicle and lock
the doors again.

Once

⎯

The electronic key has a low
battery.
→ Replace the electronic key

battery. (

→P. 549)

Once

⎯

The steering lock could not be
released within 3 seconds of
the engine switch being
pressed.
→ Press the engine switch

while depressing the brake
pedal and moving the
steering wheel left and
right.

Once

⎯

Indicates a malfunction in the
smart key system
→ Have the vehicle inspected

by your Toyota dealer.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

(Flashes)

(Flashes)

606

8-2. Steps to take in an emergency

Once

⎯

• When the doors were

unlocked with the mechanical
key and then the engine
switch was pressed, the elec-
tronic key could not be
detected in the vehicle.

• The electronic key could not

be detected in the vehicle
even after the engine switch
was pressed two consecu-
tive times.

→ Touch the electronic key to

the engine switch while
depressing the brake
pedal.

Once

⎯

During a engine starting proce-
dure in the event that the elec-
tronic key was not functioning
properly (

→P. 635), the engine

switch was touched with the
electronic key.
→ Press the engine switch

within 10 seconds of the
buzzer sounding.

⎯

⎯

Indicates that:
• With the engine switch off,

the doors were unlocked and
then the driver’s door was
opened and closed

• The engine switch was turned

to ACCESSORY mode with-
out starting the engine

• The shift lever was shifted to

P from another position with
the engine switch in IGNI-
TION ON mode.

→ Press the engine switch

while depressing the brake
pedal.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

607

8-2. Steps to take in an emergency

8

Wh

en tro

uble

 a

ris

es

*

: The engine may not be restarted depending on the vehicle condition.

■

Messages displays
The message illustrations used are intended as examples, and may differ
from the image that is actually displayed on the multi-information display.

■

Warning buzzer


→P. 587

Once

⎯

The engine switch has been
turned off with the shift lever in
a position other than P.
→ Shift the shift lever to P.

Once

⎯

After the engine switch has
been turned off with the shift
lever in a position other than P,
the shift lever has been shifted
to P.
→ Turn the engine switch off.

Con-
tinu-
ous

⎯

Indicates that the engine was
stopped in an emergency while
driving
→ To restart the engine, shift

the shift lever to N and turn
the engine switch to IGNI-
TION ON mode.

*

Once

⎯

Indicates that the engine switch
has been pressed while driving
→ Except when emergency

stopping of the vehicle is
needed, immediately
release the engine switch.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

(Flashes)

(Flashes)

(Flashes)
