556

7-3. Do-it-yourself maintenance

Check the wattage of the light bulb to be replaced. (

→P. 663)



→P. 126

Light bulbs

You may replace the following bulbs by yourself. The difficulty
level of replacement varies depending on the bulb. If necessary
bulb replacement seems difficult to perform, contact your
Toyota dealer.

For more information about replacing other light bulbs, contact
your Toyota dealer.

Preparing for light bulb replacement

Turning off the power back door main switch (if equipped)

557

7-3. Do-it-yourself maintenance

7

Mainten

ance an

d ca

re

■

Front

■

Rear

Bulb locations

Headlight high beam/day-
time running light (if
equipped)

Headlight low beam

Front fog light (if equipped)

Front turn signal light/park-
ing light (if equipped)

Front side marker light

1

2
3

4

5

Rear turn signal light

Back-up light

License plate lights

1

2

3

558

7-3. Do-it-yourself maintenance

■

Headlight low beams

For the right side only:
Remove the washer fluid
tank opening.

Turn the cover counterclock-
wise.

Turn the bulb base counter-
clockwise.

Unplug the connector while
pressing the lock release.

Replacing light bulbs

1

2

3

4

559

7-3. Do-it-yourself maintenance

7

Mainten

ance an

d ca

re

Replace the light bulb, and
install the bulb base.

Align the 3 tabs on the light bulb
with the mounting and insert.

Turn and secure the bulb
base.

Shake the bulb base gently to
check that it is not loose, turn
the headlight low beams on
once and visually confirm that
no light is leaking through the
mounting.

Turn the cover clockwise and
install it.

For the right side only: Install the washer fluid tank.

5

6

7

8
