468

6-3. Using the storage features

■

Center deck under tray

Pull the strap upwards to
open the center deck board.

To secure the center deck
board, remove the hook on
the backside of the center
deck board and attach the
hook to the head restraint on
the third seats as shown.

■

Deck side box

Pull the strap upwards to open
the side deck board.

Auxiliary boxes

1

2

WARNING

Do not drive with any of the deck boards opened. Items may fall out and
cause injury.

469

6-3. Using the storage features

6

In

te

rior fe

atures

■

Installing the luggage cover

Fold down the third seats. (

→P. 155)

To take out the luggage
cover unit, lift and remove
the center deck board and
side deck board. (

→P. 468)

Press the lock release but-
tons to extend the ends of
the luggage cover unit.

To install the luggage cover
unit, with the lock release
buttons facing upward, insert
one end into the recess, then
compress the other end and
insert it into the other recess.

Pull out the luggage cover
and hook it onto the anchors.

Luggage cover (if equipped)

1
2

3

4

5

470

6-3. Using the storage features

■

Removing the luggage cover

Release the cover from the
left and right anchors and
allow it to react.

Compress the end of the lug-
gage cover and lift up the
luggage cover up.

■

Stowing the luggage cover

Open the center deck board and the side deck board. (

→P. 468)

To store the luggage cover
unit, compress both ends
until they lock.

Store the unit with the lock
release buttons facing up and
the cover portion facing the rear
of the vehicle.

1

2

1
2

471

6-3. Using the storage features

6

In

te

rior fe

atures

WARNING

■

When installing/stowing the luggage cover
Make sure that the luggage cover is securely installed/stowed. Failure to do
so may result in serious injury in the event of sudden braking or a collision.

■

Caution for the luggage cover

●

Do not place anything on the luggage cover to avoid death or serious
injury.

●

Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

■

When extending the luggage cover unit
Do not point the luggage cover unit at your face or body, as doing so may
cause injuries if the cover ends extend suddenly.

NOTICE

■

When using the luggage cover

●

Do not put heavy items on the luggage cover.

●

Install the cover unit in the correct direc-
tion so that the lock release button
faces upward.
