100

2. Instrument cluster

● Pop-up display

Select to set the following pop-up displays, which may appear in
some situations, on/off.

• Route guidance display of the navigation system-linked sys-

tem (if equipped)

• Incoming call display of the hands-free phone system
• Stop & Start system duration (if equipped)
• Stop & Start system status (if equipped)
• Instrument panel brightness adjustment display

● Accent color

Select to change the accent colors on the screen, such as the
cursor color.

● Speed limit display

*

 (if equipped)

Select to set the display of speed limit information stored in the
navigation system to on with the speed limit caution indicator
(yellow) enabled, on with the speed limit caution not enabled, or
off. If enabled, the speed limit caution indicator will come on if the
vehicle speed exceeds the displayed speed limit.

● Initialization

Registered or changed meter settings will be deleted or returned
to their default setting.

*

: Speed limit display may not be available for some regions.

101

2. Instrument cluster

2

Instrum

e

nt clus

ter

■

Settings can be changed
Customizable features:

→P. 681

■

Pop-up display
In some situations, such as when a switch operation is performed, a pop-up
display, will be temporarily displayed on the multi-information display.
The pop-up display function can be set on/off.

■

Setting display automatic cancelation
In the following situations, setting display in which the settings can be
changed through the meter control switch will automatically be turned off.

●

When a warning message appears while the setting display is displayed

●

When the vehicle begins to move while the setting display is displayed

■

Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

WARNING

■

The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the display monitor may
respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.

■

Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious
health hazard.

NOTICE

■

During setting up the display
To prevent battery discharge, ensure that the engine is running while setting
up the display features.

102

2. Instrument cluster

During Eco-friendly acceleration
operation (Eco driving), Eco Driv-
ing Indicator Light will turn on.
When the acceleration exceeds
Zone of Eco driving, and when the
vehicle is stopped, the light turns
off.

Suggests Zone of Eco driving with
current Eco driving ratio based on
acceleration.

Eco driving ratio based on
acceleration

If the acceleration exceeds Zone of
Eco driving, the right side of Eco
Driving Indicator Zone Display
blinks.

Zone of Eco driving

■

Operation of Eco Driving Indicator
Eco Driving Indicator will not operate in the following conditions:

●

The shift lever is anything other than D.

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

■

Eco Driving Indicator Light customization
→P. 99

Eco Driving Indicator

Eco Driving Indicator Light

Eco Driving Indicator Zone Display

1

2

103

2. Instrument cluster

2

Instrum

e

nt clus

ter

Audio system



Entune Audio

Press the “CAR” button.

If the “Past Record” screen is dis-
played, select “Trip Information”.



Entune Audio Plus or Entune Premium Audio

Press the “APPS” button.

Touch “ECO” on the “Apps”
screen.

If the “Past Record” screen is dis-
played, select “Trip Information”.

Fuel consumption information

Fuel consumption information can be displayed on the audio
system screen.

Trip information

1
2
