32

1-1. For safe use

To release plate “B”, press the
release button on buckle “B”.

To release plate “A”, insert the
key (

→P. 108) or plate “B” into

the hole on buckle “A”.

Retract the belt slowly when
releasing and stowing the seat
belt.

Holding plate “A” and “B”
together, insert both plates into
the holder on the roof.

Releasing and stowing the seat belt (for the third center seat)

Release button

Plate “B”

Buckle “B”

1

Buckle “A”

Buckle “A”

Plate “B”

Plate “A”

Plate “A”

2

3

33

1-1. For safe use

1

Fo
r

safety and securi

ty

Push the seat belt shoulder
anchor down while pressing the
release button.

Push the seat belt shoulder
anchor up.

Move the height adjuster up and
down as needed until you hear a
click.

If the shoulder belt sits close to a person's neck, use the seat belt
comfort guide.

Pull the comfort guide from the
pocket.

Slide the belt past the slot of the
guide.

The elastic cord must be behind
the seat belt.

Buckle the seat belt and posi-
tion it comfortably.

Adjusting the seat belt shoulder anchor height (front seats)

1

2

Seat belt comfort guide (for the third center seat)

1

2

3

34

1-1. For safe use

The pretensioners help the seat
belts to quickly restrain the occu-
pants by retracting the seat belts
when the vehicle is subjected to
certain types of severe frontal col-
lision or a vehicle rollover.

The pretensioners do not activate
in the event of a minor frontal
impact, a side impact or a rear
impact.

Seat belt pretensioners (front seats)

35

1-1. For safe use

1

Fo
r

safety and securi

ty

■

Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend so that you can move around fully.

■

Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then retracted
even slightly, the belt is locked in that position and cannot be extended. This
feature is used to hold the child restraint system (CRS) firmly. To free the belt
again, fully retract the belt and then pull the belt out once more. (

→P. 65)

■

When not using the rear seat belts



Second seat belts



Third seat belts

Pass the outer seat belts through the seat
belt hangers and secure the seat belt
plates to prevent the shoulder belts from
being damaged.

Pass the outer seat belts through the seat
belt hangers and secure the seat belt
plates to prevent the shoulder belts from
being damaged.
