52. INSTALL CLUTCH DRUM AND INPUT SHAFT ASSEMBLY (a) Install the 2 thrust needle roller bearings. HINT: ITEM INSIDE OUTSIDE Bearing A 72.0 to 72.3 mm (2.83 to 2.85 in.) 85.3 to 85.6 mm (3.36 to 3.37 in.) Bearing B 36.5 to 36.7 mm (1.437 to 1.445 in.) 52.9 to 53.2 mm (2.08 to 2.09 in.) (b) Coat the clutch drum thrust washer with petroleum jelly and install it onto the clutch drum and input shaft assembly. (c) Install the clutch drum and input shaft drum assembly onto the transmission case. 53. INSTALL OIL PUMP ASSEMBLY (a) Coat a new O-ring with ATF, and install it to the oil pump. (b) Install the 2 thrust bearing races to the front oil pump. Thrust bearing race diameter: ITEM INSIDE OUTSIDE AB60F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMIS... |
