(k) Tighten the 2 bolts. Torque: 37 N·m {375 kgf·cm, 27ft·lbf} (l) Operate the front power seat switch LH (slide switch) to move the seat to the foremost position. (m) Tighten the 2 bolts. Torque: 37 N·m {375 kgf·cm, 27ft·lbf} mounting bolts to adjust the adjuster position. 2. INSTALL INNER SEAT TRACK BRACKET COVER LH (a) Attach the clip to install the inner seat track bracket cover LH. 3. INSTALL OUTER SEAT TRACK BRACKET COVER LH (a) Attach the clip to install the outer seat track bracket cover LH. 4. INSTALL FRONT SEAT HEADREST ASSEMBLY (a) Install the front seat headrest assembly. 5. CHECK SRS WARNING LIGHT 6. INSPECT POWER SEAT CONTROL SYSTEM (a) w/o Seat Position Memory System: (b) w/ Seat Position Memory System: 7. INSPECT SEAT HEATER SYSTEM (w/ Seat Heater System) 8. INSPECT CLIMATE CONTROL SEAT SYSTEM (w/ Climate Control Seat System) SEAT: FRONT SEAT ASSEMBLY (for Power Seat): INSTALLATION; ... |
