A FREEZE FRAME DATA ITEM FOR DTC P1605 RESULT PROCEED TO Initial Engine Coolant Temp, Ambient Temp for A/C, Initial Intake Air Temp Difference in temperature between each item is less than 10°C*1 A Difference in temperature between each item is 10°C or more*2 B HINT: *1: A long time had elapsed after stopping the engine. B GO TO STEP 49 47. READ FREEZE FRAME DATA (a) Connect the Techstream to the DLC3. (b) Turn the ignition switch to ON. (c) Using the Techstream, confirm the vehicle conditions recorded in the freeze frame data which were present when the DTC was stored
. Result FREEZE FRAME DATA ITEM FOR DTC P1605 RESULT SUSPECTED AREA PROCEED TO Initial Engine Coolant Temp, Coolant Temp, Engine Run Time Range A Engine coolant temperature sensor Thermostat A Range B Engine coolant temperature B 3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: P1603,P1605;... |
