2.0 to 3.0 mm (0.0787 to 0.118 in.) NOTICE: Remove any oil from the contact surface. (b) Install the oil seal retainer with the 6 bolts. Torque: 10 N·m {102 kgf·cm, 7ft·lbf} NOTICE: (c) Install the oil strainer with the 2 bolts. Torque: 10 N·m {102 kgf·cm, 7ft·lbf} NOTICE: Make sure the O-ring is not twisted or damaged. 7. INSTALL NO. 1 OIL PAN BAFFLE PLATE (a) Install the baffle plate with the 7 bolts. Torque: 10 N·m {102 kgf·cm, 7ft·lbf} 8. INSTALL NO. 1 OIL PAN SUB-ASSEMBLY (a) Apply seal packing in a continuous line as shown in the illustration. Seal packing: 3UR-FBE ENGINE MECHANICAL: ENGINE UNIT: REASSEMBLY;... |
