Toyota Tundra (2015 year). Manual - part 41
Last Modified: 9-16-2014
6.6 A
Doc ID: RM000002ZVE00RX
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: NAVIGATION: NAVIGATION ANTENNA: REMOVAL; 2015 MY Tundra [08/2014 - ]
REMOVAL
1. PRECAUTION
NOTICE:
After turning the ignition switch off, waiting time may be required before disconnecting the cable from the
battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal
notice before proceeding with work
.
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the
SRS system.
NOTICE:
When disconnecting the cable, some systems need to be initialized after the cable is reconnected
.
3. REMOVE INSTRUMENT PANEL SUB-ASSEMBLY
(a) for Column Shift Type:
(b) for Floor Shift Type:
4. REMOVE NO. 2 HEATER TO REGISTER DUCT
5. REMOVE NO. 2 SIDE DEFROSTER NOZZLE DUCT
6. REMOVE NO. 1 SIDE DEFROSTER NOZZLE DUCT
7. REMOVE DEFROSTER NOZZLE ASSEMBLY
8. REMOVE NAVIGATION ANTENNA ASSEMBLY
(a) Detach the 2 clamps.
