571

8-2. Steps to take in an emergency

8

W

hen
 trou

bl

e ari

se

s

LDA indicator (warning buzzer) (if equipped on vehicles
with multi-information display type B)

Indicates that the LDA (Lane Departure Alert) system is
not available temporarily or has detected a malfunction
when the warning light is illuminated in yellow and a warn-
ing message is displayed on the multi-information display.

→ P. 307

Open door warning light (warning buzzer)

*

5

 (if

equipped)

Indicates that a door is not fully closed

→ Check that all the doors are closed.

Driver’s and front passenger’s seat belt reminder light
(warning buzzer)

*

6

Warns the driver and front passenger to fasten his/her
seat belt

→ Fasten the seat belt.

(On the center panel)

Rear passengers’ seat belt reminder lights (warning
buzzer)

*

8

 (if equipped)

Warn the rear passengers to fasten their seat belts

→ Fasten the seat belt.

Low fuel level warning light

Indicates remaining fuel is approximately 12.0 L (3.2 gal.,
2.6 Imp.gal.) or less

→ Refuel the vehicle.

Low engine oil level warning light (if equipped)

Indicates that engine oil level is low (This warning light
may come on if the vehicle is stopped on a slope. Move
the vehicle to a level surface and check to see if the light
goes off.)

→ Check the level of engine oil and add more oil if nec-

essary.

Master warning light (warning buzzer) (if equipped)

A buzzer sounds and the warning light comes on and
flashes to indicate that the master warning system has
detected a malfunction.

→ P. 577

Warning light

Warning light/Details/Actions

572

8-2. Steps to take in an emergency

(Flashes)

Stop & Start cancel indicator (if equipped)

Indicates a malfunction in the Stop & Start system
(The Stop & Start cancel indicator will come on when the
system is canceled:

→P. 344)

→ Have the vehicle inspected by any authorized Toyota

dealer or repairer, or another duly qualified and
equipped professional immediately.

Parking brake indicator light (warning buzzer)

*

9

Warns the driver to release parking brake.

→ Release the parking brake.

Speed warning light (warning buzzer)

*

10

 (if equipped)

Indicates that your vehicle speed reaches or exceeds 120
km/h (75 mph).

→ Reduce vehicle speed.

Low AdBlue™ level warning light (if equipped)

Indicates that AdBlue™ level is low

→ Have AdBlue™ refilled at any authorized Toyota

dealer or repairer, or another duly qualified and
equipped professional.

(if equipped)

Tire pressure warning light

When the light comes on:
Low tire inflation pressure such as
• Natural causes (

→P. 574)

• Flat tire (

→P. 584)

→ Adjust the tire inflation pressure to the specified

level.
The light will turn off after a few minutes. In case the
light does not turn off even if the tire inflation pres-
sure is adjusted, have the system checked by any
authorized Toyota dealer or repairer, or another duly
qualified and equipped professional.

When the light comes on after blinking for 1 minute:
Malfunction in the tire pressure warning system
(

→P. 575)

→ Have the system checked by any authorized Toyota

dealer or repairer, or another duly qualified and
equipped professional.

Warning light

Warning light/Details/Actions

573

8-2. Steps to take in an emergency

8

W

hen
 trou

bl

e ari

se

s

*

1

: The buzzer sounds if the vehicle reaches a speed of 5 km/h (3 mph).

*

2

: Slow down until the lamp goes off.

*

3

: The buzzer sounds when the differential oil temperature is too high and

turning the front-wheel drive control switch to H2 is required.

*

4

: The buzzer will sound at the same time the warning light flashes.

*

5

: The open door warning buzzer sounds if the vehicle reaches or exceeds a

speed of 5 km/h (3 mph).

*

6

: Models for model code destination V

*

7

: The driver’s and front passenger’s

seat belt buzzer sounds to alert the driver and front passenger that his or
her seat belt is not fastened. Once the engine switch is turned to the “ON”
position (vehicles without smart entry & start system) or IGNITION ON
mode (vehicles with smart entry & start system), the buzzer sounds for 6
seconds. If the vehicle reaches a speed of 20 km/h (12 mph), the buzzer
sounds once. If the seat belt is still unfastened after 30 seconds, the
buzzer will sound intermittently for 10 seconds. Then, if the seat belt is still
unfastened, the buzzer will sound in a different tone for 20 more seconds.
Except models for model code destination V

*

7

: The driver’s and front pas-

senger’s seat belt buzzer sounds to alert the driver and front passenger
that his or her seat belt is not fastened. The buzzer sounds intermittently
for 30 seconds after the vehicle reaches a speed of 20 km/h (12 mph).
Then, if the seat belt is still unfastened, the buzzer will sound in a different
tone for 90 more seconds.

*

7

: See “Checking your vehicle’s model” if you are not sure of which model

your vehicle is. (

→P. 11)

*

8

: The rear passengers’ seat belt buzzer sounds to alert the rear passenger

that his or her seat belt is not fastened. The buzzer sounds intermittently
for 30 seconds after the vehicle reaches a speed of 20 km/h (12 mph).
Then, if the seat belt is still unfastened, the buzzer will sound in a different
tone for 90 more seconds.

*

9

: The parking brake engaged warning buzzer sounds if the vehicle reaches a

speed of approximately 5 km/h (3 mph) or more.

*

10

: The speed warning buzzer sounds if the vehicle reaches or exceeds a

speed of 120 km/h (75 mph) and will stop sounding after 6 seconds or if
you decelerate below 120 km/h (75 mph).

574

8-2. Steps to take in an emergency

Carrying out the corresponding action turns the warning light off.

■

If the malfunction indicator lamp comes on while driving
For some models, malfunction indicator lamp will come on if the fuel tank
becomes completely empty. If the fuel tank is empty, refuel the vehicle imme-
diately. The malfunction indicator lamp will go off after several trips.
If the malfunction indicator lamp does not go off, contact any authorized
Toyota dealer or repairer, or another duly qualified and equipped professional
as soon as possible.

■

When the tire pressure warning light comes on (if equipped)
Carry out the following procedure after the tire temperature has lowered suffi-
ciently.

●

Check the tire inflation pressure and adjust to the appropriate level.

●

If the warning light does not go out even after several minutes, check that
the tire inflation pressure is at the specified level and carry out initialization.

The warning light may come on again if the above operations are conducted
without first allowing the tire temperature to lower sufficiently.

■

The tire pressure warning light may come on due to natural causes (if
equipped)
The tire pressure warning light may come on due to natural causes such as
natural air leaks and tire inflation pressure changes caused by temperature.
In this case, adjusting the tire inflation pressure will turn off the warning light
(after a few minutes).

■

When a tire is replaced with the spare tire (vehicles with the tire pressure
warning system)
The tire pressure warning light will turn on if the tire inflation pressure of the
spare tire is low. If a tire goes flat, the tire pressure warning light will not turn
off even though the flat tire has been replaced with the spare tire.

Other warning light

Warning light

Warning light/Details/Actions

Go to service warning light (warning buzzer) (if
equipped)

Indicates a malfunction in the electronic engine control
system or electronic throttle control system, or the Brake
Override System.

→ Have the vehicle inspected by any authorized Toyota

dealer or repairer, or another duly qualified and
equipped professional.
