Toyota Hilux (2017 year). Manual - part 124

503

7-3. Do-it-yourself maintenance

7

M

ai

nte
nan
ce and

 ca

re

■

Adding engine oil
If the oil level is below or near
the low level mark, add engine
oil of the same type as that
already in the engine.

Make sure to check the oil type and prepare the items needed
before adding oil.

Remove the sand and dust from around the oil filler cap.
Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.

■

Engine oil consumption
A certain amount of engine oil will be consumed while driving. In the following
situations, oil consumption may increase, and engine oil may need to be
refilled in between oil maintenance intervals.

●

When the engine is new, for example directly after purchasing the vehicle or
after replacing the engine

●

If low quality oil or oil of an inappropriate viscosity is used

●

When driving at high engine speeds or with a heavy load, when towing
(models for model code destination W

*

), or when driving while accelerating

or decelerating frequently

●

When leaving the engine idling for a long time, or when driving frequently
through heavy traffic

*

: See “Checking your vehicle’s model” if you are not sure of which model

your vehicle is. (

→P. 11)

Engine oil selection

→P. 628

Oil quantity
(Low

→ Full)

2TR-FE, 1GD-FTV and
2GD-FTV engines

1.5 L (1.6 qt., 1.3 Imp.qt.)

2KD-FTV engine

1.6 L (1.7 qt., 1.4 Imp.qt.)

Items

Clean funnel

1

2

3

4

504

7-3. Do-it-yourself maintenance

■

After changing the engine oil (models for model code destination W

*

)

The engine oil maintenance data should be reset. Perform the following pro-
cedures:

Switch the display to the trip meter A (

→P. 130) when the engine switch is

in the “ON” position (vehicles without smart entry & start system) or IGNI-
TION ON mode (vehicles with smart entry & start system).
Turn the engine switch to the “LOCK” position (vehicles without smart entry
& start system) or off (vehicles with smart entry & start system).
While pressing the odometer/trip meter display change button (

→P. 130),

turn the engine switch to the “ON” position (vehicles without smart entry &
start system) or IGNITION ON mode (vehicles with smart entry & start sys-
tem). (Do not start the engine because reset mode will be canceled.) Con-
tinue to press and hold the button for more than one second after the trip
meter displays “000000”.

*

: See “Checking your vehicle’s model” if you are not sure of which model

your vehicle is. (

→P. 11)

WARNING

■

Used engine oil

●

Used engine oil contains potentially harmful contaminants which may
cause skin disorders such as inflammation and skin cancer, so care
should be taken to avoid prolonged and repeated contact. To remove used
engine oil from your skin, wash thoroughly with soap and water.

●

Dispose of used oil and filters only in a safe and acceptable manner. Do
not dispose of used oil and filters in household trash, in sewers or onto the
ground. Call any authorized Toyota dealer or repairer, or another duly
qualified and equipped professional, service station or auto parts store for
information concerning recycling or disposal.

●

Do not leave used engine oil within the reach of children.

NOTICE

■

To prevent serious engine damage
Check the oil level on a regular basis.

■

When replacing the engine oil

●

Be careful not to spill engine oil on the vehicle components.

●

Avoid overfilling, or the engine could be damaged.

●

Check the oil level on the dipstick every time you refill the vehicle.

●

Be sure the engine oil filler cap is properly tightened.

1

2

3

505

7-3. Do-it-yourself maintenance

7

M

ai

nte
nan
ce and

 ca

re

The coolant level is satisfactory if it is between the “F” and “L” lines on
the reservoir when the engine is cold.

If the level is on or below the “L” line, add coolant up to the “F” line.
(

→P. 613)

■

Coolant selection
Only use “Toyota Super Long Life Coolant” or a similar high quality ethylene
glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with
long-life hybrid organic acid technology.
“Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion-
ized water. (Minimum temperature: -35

°C [-31°F])

For more details about engine coolant, contact any authorized Toyota dealer
or repairer, or another duly qualified and equipped professional.

■

If the coolant level drops within a short time of replenishing
Visually check the radiator, hoses, engine coolant reservoir cap, drain cock
and water pump. If you cannot find a leak, have any authorized Toyota dealer
or repairer, or another duly qualified and equipped professional test the cap
and check for leaks in the cooling system.

Engine coolant

X

Gasoline engine

X

Diesel engine

Reservoir cap
“F” line

“L” line

1
2

3

506

7-3. Do-it-yourself maintenance

Check the radiator, condenser and intercooler and clear away any for-
eign objects. If any of the above parts is extremely dirty or you are not
sure of their condition, have your vehicle inspected by any authorized
Toyota dealer or repairer, or another duly qualified and equipped pro-
fessional.

WARNING

■

When the engine is hot
Do not remove the radiator cap or the engine coolant reservoir cap.
The cooling system may be under pressure and may spray hot coolant if the
cap is removed, causing serious injuries, such as burns.

NOTICE

■

When adding coolant
Coolant is neither plain water nor straight antifreeze. The correct mixture of
water and antifreeze must be used to provide proper lubrication, corrosion
protection and cooling. Be sure to read the antifreeze or coolant label.

■

If you spill coolant
Be sure to wash it off with water to prevent it from damaging parts or paint.

■

Notice on coolant quality
Do not use improper coolant. If improper coolant is used, the engine cooling
system may be damaged.

Radiator, condenser and intercooler (if equipped)

WARNING

■

When the engine is hot
Do not touch the radiator, condenser or intercooler as they may be hot and
cause serious injuries, such as burns.
