391

5-4. Playing an audio CD and MP3/WMA discs

5

Au
dio
 sy
stem

■

Display
Depending on the contents recorded, the characters may not be displayed
properly or may not be displayed at all.

■

Error messages
If an error message is displayed, refer to the following table and take the
appropriate measures. If the problem is not rectified, take the vehicle to any
authorized Toyota dealer or repairer, or another duly qualified and equipped
professional.

■

Discs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on recording format or disc fea-
tures, or due to scratches, dirt or deterioration.

CDs with copy-protect features may not play correctly.

■

CD player protection feature
To protect the internal components, playback is automatically stopped when a
problem is detected while the CD player is being used.

■

If a CD is left inside the CD player or in the ejected position for extended
periods
The CD may be damaged and may not play properly.

■

Lens cleaners
Do not use lens cleaners. Doing so may damage the CD player.

Message

Cause/Correction procedures

“ERROR”

This indicates a problem either in the CD or
inside the player.

“CD CHECK”

The CD may be dirty, damaged or inserted
upside-down.

“WAIT”

Operation has stopped due to a high tempera-
ture inside the player. Wait for a while and
then press the “MODE” button. If the CD still
cannot be played back, contact any autho-
rized Toyota dealer or repairer, or another duly
qualified and equipped professional.

“NO SUPPORT”

This indicates that the MP3/WMA file is not
included in the CD.

392

5-4. Playing an audio CD and MP3/WMA discs

■

MP3 and WMA files
MP3 (MPEG Audio LAYER3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size by using
MP3 compression.
WMA (Windows Media Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3 for-
mat.
There is a limit to the MP3 and WMA file standards and to the media/formats
recorded by them that can be used.

●

MP3 file compatibility
• Compatible standards

MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3)

• Compatible sampling frequencies

MPEG1 LAYER3: 32, 44.1, 48 (kHz)
MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz)

• Compatible bit rates (compatible with VBR)

MPEG1 LAYER3: 32—320 (kbps)
MPEG2 LSF LAYER3: 8—160 (kbps)

• Compatible channel modes: stereo, joint stereo, dual channel and mon-

aural

●

WMA file compatibility
• Compatible standards

WMA Ver. 7, 8, 9

• Compatible sampling frequencies

32, 44.1, 48 (kHz)

• Compatible bit rates (only compatible with 2-channel playback)

Ver. 7, 8: CBR 48—192 (kbps)
Ver. 9: CBR 48—320 (kbps)

393

5-4. Playing an audio CD and MP3/WMA discs

5

Au
dio
 sy
stem

●

Compatible media
Media that can be used for MP3 and WMA playback are CD-Rs and CD-
RWs.
Playback in some instances may not be possible, depending on the status
of the CD-R or CD-RW. Playback may not be possible or the audio may
jump if the disc is scratched or marked with fingerprints.

●

Compatible disc formats
The following disc formats can be used.
• Disc  formats:

CD-ROM Mode 1 and Mode 2
CD-ROM XA Mode 2, Form 1 and Form 2

• File formats:

ISO9660 Level 1, Level 2, (Romeo, Joliet)
MP3 and WMA files written in any format other than those listed above
may not play correctly, and their file names and folder names may not be
displayed correctly.

Items related to standards and limitations are as follows.
• Maximum directory hierarchy: 8 levels
• Maximum length of folder names/file names: 32 characters
• Maximum number of folders: 192 (including the root)
• Maximum number of files per disc: 255

●

File names
The only files that can be recognized as MP3/WMA and played are those
with the extension .mp3 or .wma.

●

Multi-sessions
As the audio system is compatible with multi-sessions, it is possible to play
discs that contain MP3 and WMA files. However, only the first session can
be played.

●

ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title and artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags.
(The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.

394

5-4. Playing an audio CD and MP3/WMA discs

●

MP3 and WMA playback
When a disc containing MP3 or WMA files is inserted, all files on the disc
are first checked. Once the file check is finished, the first MP3 or WMA file
is played. To make the file check finish more quickly, we recommend you do
not write in any files other than MP3 or WMA files or create any unneces-
sary folders.
If the discs contain a mixture of music data and MP3 or WMA format data,
only music data can be played.

●

Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be mistakenly recognized and played as MP3 and
WMA files. This may result in large amounts of interference and damage to
the speakers.

●

Playback
• To play MP3 file with steady sound quality, we recommend a fixed bit rate

of 128 kbps and a sampling frequency of 44.1 kHz.

• CD-R or CD-RW playback may not be possible in some instances,

depending on the characteristics of the disc.

• There is a wide variety of freeware and other encoding software for MP3

and WMA files on the market, and depending on the status of the encod-
ing and the file format, poor sound quality or noise at the start of playback
may result. In some cases, playback may not be possible at all.

• When files other than MP3 or WMA files are recorded on a disc, it may

take more time to recognize the disc and in some cases, playback may
not be possible at all.

• Microsoft, Windows, and Windows Media are the registered trademarks

of Microsoft Corporation in the U.S. and other countries.
