307

4-5. Using the driving support systems

4

D

riv

in

g

■

Warning message
If the following warning message is displayed on the multi-information dis-
play, follow the appropriate troubleshooting procedure.

Warning message

Details/Actions

“LDA MALFUNCTION

VISIT YOUR DEALER”/

“LDA malfunction

Visit your dealer”

The system may not be operating
properly.

→ Have the vehicle inspected at any

authorized Toyota dealer or
repairer, or another duly qualified
and equipped professional.

“FORWARD CAMERA

SYSTEM

UNAVAILABLE

CLEAN WINDSHIELD”/

“Forward Camera

System

Unavailable

Clean Windshield”

Dirt, rain, condensation, ice, snow,
etc., are present on the windshield in
front of the camera sensor.

→ Turn the LDA system off, remove

any dirt, rain, condensation, ice,
snow, etc., from the windshield, and
then turn the LDA system back on.

“FORWARD CAMERA

SYSTEM

UNAVAILABLE”/

“Forward Camera

System

Unavailable”

The operation conditions of the cam-
era sensor (temperature, etc.) are not
met.

→ When the operation conditions of

the camera sensor (temperature,
etc.) are met, the LDA system will
become available. Turn the LDA
system off, wait for a little while,
and then turn the LDA system back
on.

308

4-5. Using the driving support systems

If a different warning message is displayed, follow the instructions displayed
on the screen.

“LDA UNAVAILABLE”/

“LDA unavailable”

The LDA system is temporarily can-
celed due to a malfunction in a sensor
other than the camera sensor.

→ Turn the LDA system off and follow

the appropriate troubleshooting
procedures for the warning mes-
sage. Afterward, drive the vehicle
for a short time, and then turn the
LDA system back on.

“LDA UNAVAILABLE

BELOW APPROX

50km/h”/

“LDA unavailable

Below approx

50km/h”

The LDA system cannot be used as
the vehicle speed is less than approxi-
mately 50 km/h (32 mph).

→ Drive the vehicle at approximately

50 km/h (32 mph) or more.

“LDA UNAVAILABLE

BELOW APPROX

32MPH”/

“LDA unavailable

Below approx

32MPH”

“LDA UNAVAILABLE

AT CURRENT SPEED”/

“LDA unavailable
at current speed”

The LDA system cannot be used as
the vehicle speed is too high.

→ Reduce the vehicle speed.

Warning message

Details/Actions

309

4

4-5. Using the driving support systems

D

riv

in

g

RSA (Road Sign Assist)

∗

RSA recognizes specific road
signs using the camera sensor
and provides information to the
driver via the multi-information
display.

If the system judges that the vehicle is being driven over the speed
limit, performing prohibited actions, etc., in relation to the recognized
road signs, it alerts the driver using a warning display and warning
buzzer

*

.

*

: This setting needs to be customized.

∗

: If equipped

Summary of function

camera sensor

WARNING

■

Before using the RSA
Do not rely solely upon the RSA system. RSA is a system which supports
the driver by providing information, but it is not a replacement for a driver’s
own vision and awareness. Drive safely by always paying careful attention
to the traffic rules.
Inappropriate or negligent driving could lead to an unexpected accident.

310

4-5. Using the driving support systems

After the camera sensor recognizes a sign, it is displayed on the multi-
information display when the vehicle passes the sign.
● When the driving assist system

information is selected, a maxi-
mum of 3 signs can be dis-
played. (

→P. 136)

● When other than the driving

assist system information is
selected, a speed limit sign, a
highway sign or an all canceled
sign can be displayed.
(

→P. 136)

A no overtaking sign and a
speed limit sign with supple-
mental mark are not displayed.
However, if signs other than
speed limit signs are recog-
nized, they are mentioned in a
stack under the current speed
limit sign.

Indication on the multi-information display
