Toyota Hilux (2017 year). Manual - part 15

67

1-2. Child safety

1

Fo
r s

afe
ty a
nd

 se
cu

rity

Install the available child restraint system in vehicle upon confirming
the following items.

■

Standards for child restraint systems
Use a child restraint system that conforms to ECE R44

*

1

 or

ECE R129

*

1, 2

.

The following approval mark is displayed on child restraint systems
which are conformed.
Check for an approval mark attached to the child restraint system.
Example of the displayed regu-
lation number

ECE R44 approval mark

*

3

The weight range of the child
who is applicable for an
ECE R44 approval mark is
indicated.
ECE R129 approval mark

*

3

The height range of the child
who is applicable as well as
available weights for an
ECE R129 approval mark is
indicated.

*

1

: ECE R44 and ECE R129 are U.N. regulations for child restraint sys-

tems.

*

2

: The child restraint systems mentioned in the table may not be available

outside of the EU area.

*

3

: The displayed mark may differ depending on the product.

Child restraint system

1

2

68

1-2. Child safety

■

Mass group (ECE R44 only)
This Mass group table is required when confirming the child
restraint system compatibility. Confirm in accordance with the child
restraint system compatibility table. (

→P. 73, 82, 91, 99).

The child restraint system which conforms to the standard of
ECE R44 is categorized into 5 groups according to the weight of the
child.

*

: The age range is a standard approximation. Choose according to the

weight of the child.

Mass group

Child weight

Reference age

*

Group 0

until 10 kg (22 lb.)

about 9 months

Group 0+

until 13 kg (28 lb.)

about 1.5 years

Group I

9 - 18 kg

(20 to 39 lb.)

from 9 months - about 4 years

Group II

15 - 25 kg

(34 to 55 lb.)

from 3 years - about 7 years

Group III

22 - 36 kg

(49 to 79 lb.)

from 6 years - about 12 years

69

1-2. Child safety

1

Fo
r s

afe
ty a
nd

 se
cu

rity

■

Types of child restraint system installation methods
Confirm with the operation manual enclosed with the child restraint
system about the instruction of the child restraint system.

Installation method

Page

Seat belt attach-

ment

P. 73, 82

ISOFIX rigid anchor

attachment

P. 89, 97

Anchor brackets

(for top strap)

attachment

P. 104

70

1-2. Child safety

When using a child restraint system

WARNING

■

When using a child restraint system
Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Vehicles with front passenger occupant classification system: Never use a
rear-facing child restraint system on the front passenger seat when “ON”
of the “PASSENGER AIR BAG” indicator is illuminated. (

→P. 57)

The force of the rapid inflation of the front passenger airbag can cause
death or serious injury to children in the event of an accident.

●

Vehicles without front passenger
occupant classification system or airbag
manual on-off switch: Never use a rear-
facing child restraint system on the front
passenger seat.
The force of the rapid inflation of the
front passenger airbag can cause death
or serious injury to children in the event
of an accident.

●

Vehicles with airbag manual on-off
switch: Never use a rear-facing child
restraint system on the front passenger
seat when the airbag manual on-off
switch is on. (

→P. 62)

The force of the rapid inflation of the
front passenger airbag can cause death
or serious injury to children in the event
of an accident.

●

On some models: There is a label(s) on
the passenger side sun visor, indicating
it is forbidden to attach a rear-facing
child restraint system to the front
passenger seat.
Details of the label(s) are shown in the
illustration below. The label type B
includes information written in the
language of your country.
