9A-50 Wiring Systems:

L: Floor harness, Luggage compartment light wire, Rear height sensor wire / R: Fuel pump wire (RHD, 3dr)

{

L15

R01

{

L19
L68

L23

L12

L44

L33

L06

L05

L11

L25

L04

L32

L59

L30

L36

L41

L64

L69

L47

L48

L43

L54

L53

L38

L35

L34

L14

R02

R03

L20

L52

Fuel pump wire

L31

 (TO J09)

L42

 (TO O01)

L28

 (TO G72)

L29

 (TO G55)

L08

 (TO G07)

L09

 (TO G08)

L01

 (TO G80)

L07

 (TO J01)

L03

 (TO E79)

L27

 (TO G72)

Luggage compartment
light wire

L

L57

L56

L63

L18

L10

L22

18

21

19

I6JB0B910902-01

Wiring Systems:  9A-51

L: Floor harness

L: Luggage compartment light wire

R: Fuel pump wire

No./Color

Connective position

No./Color

Connective position

L01/N

Main harness (To E80)

L30/YEL

Side air-bag inflator (L)

L03/YEL

Main harness (To E79)

L31/GRY

Front door wire (Passenger side) (To J09)

L04/BLK

Turn signal relay

L32/YEL (8ch) A/B SDM

L05/N

J/B

L33/YEL (8ch) A/B SDM

L06/N

J/B

L34/N

Front door switch (Passenger side)

L07/GRY

Front door wire (Driver side) (To J01)

L35/YEL

Side air- bag sensor (L)

L08/N

Instrument panel harness (To G07)

L36/BLK

Pretensioner (Passenger side)

L09/BLU

Instrument panel harness (To G08)

L38/GRY

Wheel speed sensor (RL)

L10/N

Front door switch (Driver side)

L41/BLK

Side curtain air-bag (Passenger side)

L11/YEL

Side air-bag sensor (R)

L42/N

Rear end door wire (To O01)

L12/BLK

Pretensioner (Driver side)

L43/N

Rear combination light (L)

L14/N

Wheel speed sensor (RR)

L44/N

Keyless entry receiver

L15/GRY

Fuel pump wire (To R01)

L47/N

ACC socket #1

L18/BLK

Side curtain air-bag (Driver side)

L48/N

ACC socket #1

L19/N

Luggage compartment light wire (To L68)

L52/N

Licence plate light #1

L20/N

Rear combination light (R)

L53/N

Licence plate light #2

L22/N

J/C

L54/N

Rear end door switch

L23/N

J/C

L56/N

Seat belt switch (Without seat heater)

L25/YEL

Side air-bag inflator (R)

L57/N

Seat heater & Seat belt switch (Driver
side)

L27/N

Instrument panel harness (To G72)

L59/N

Seat heater (Passenger side)

L28/N

Instrument panel harness (To G73)

L63/N

Rear speaker (R)

L29/YEL

Instrument panel harness (To G55)

L64/N

Rear speaker (L)

No./Color

Connective position

No./Color

Connective position

L68/N

Floor harness (To L19)

L69/N

Luggage compartment light

No./Color

Connective position

No./Color

Connective position

R01/GRY Floor harness (To L15)

R03/N

Fuel pump sub gauge

R02/GRY or

BLK

Fuel pump and gauge

9A-52 Wiring Systems:

L: Floor harness, Luggage compartment light wire, Rear height sensor wire / R: Fuel pump wire (LHD, 3dr)

L44

L33

L06

L04

L05

L25

L32

L56

L57

L31

 (TO J09)

L28

 (TO G73)

L29

 (TO G55)

L08

 (TO G07)

L09

 (TO G08)

L01

 (TO G80)

L07

 (TO J01)

L03

 (TO E79)

L27

 (TO G72)

L

L39

L59

L30

{

L15

R01

{

L19
L68

L23

L36

L11

L12

L41

L64

L69

L47

L48

L43

L81

L54

L53

L38

L35

L10

L14

R02

R03

L80

L20

L52

Fuel pump wire

L42

 (TO O01)

Luggage compartment
light wire

L63

L18

L34

L22

18

21

19

L79

I6JB0B910904-01

Wiring Systems:  9A-53

L: Floor harness

L: Luggage compartment light wire

R: Fuel pump wire

No./Color

Connective position

No./Color

Connective position

L01/N

Main harness (To E80)

L32/YEL (8ch) A/B SDM

L03/YEL

Main harness (To E79)

L33/YEL (8ch) A/B SDM

L04/BLK

Turn signal relay

L34/N

Front door switch (Passenger side)

L05/N

J/B

L35/YEL

Side air- bag sensor (L)

L06/N

J/B

L36/BLK

Pretensioner (Passenger side)

L07/GRY

Front door wire (Driver side) (To J01)

L38/GRY

Wheel speed sensor (RL)

L08/N

Instrument panel harness (To G07)

L39/GRY (IF

EQPD)

YAW/G sensor

L09/BLU

Instrument panel harness (To G08)

L41/BLK

Side curtain air-bag (Passenger side)

L10/N

Front door switch (Driver side)

L42/N

Rear end door wire (To O01)

L11/YEL

Side air-bag sensor (R)

L43/N

Rear combination light (L)

L12/BLK

Pretensioner (Driver side)

L44/N

Keyless entry receiver

L14/N

Wheel speed sensor (RR)

L47/N

ACC socket #1

L15/GRY

Fuel pump wire (To R01)

L48/N

ACC socket #1

L18/BLK

Side curtain air-bag (Driver side)

L52/N

Licence plate light #1

L19/N

Luggage compartment light wire (To L68)

L53/N

Licence plate light #2

L20/N

Rear combination light (R)

L54/N

Rear end door switch

L22/N

J/C

L56/N

Seat belt switch

L23/N

J/C

L57/N

Seat heater (Driver side)

L25/YEL

Side air-bag inflator (R)

L59/N

Seat heater (Passenger side)

L27/N

Instrument panel harness (To G72)

L63/N

Rear speaker (R)

L28/N

Instrument panel harness (To G73)

L64/N

Rear speaker (L)

L29/YEL

Instrument panel harness (To G55)

L79/BLU

J/C

L30/YEL

Side air-bag inflator (L)

L80/BRN

Luggage antenna (R)

L31/GRY

Front door wire (Passenger side) (To J09)

L81/BRN

Luggage antenna (L)

No./Color

Connective position

No./Color

Connective position

L68/N

Floor harness (To L19)

L69/N

Luggage compartment light

No./Color

Connective position

No./Color

Connective position

R01/GRY Floor harness (To L15)

R03/N

Fuel pump sub gauge

R02/GRY or

BLK

Fuel pump and gauge
