8B-106 Air Bag System: Installation 1) Confirm sleeve (1) is surely installed in side-air bag (inflator) module. 2) Tighten sleeve lock nut (2) to specified torque. Tightening torque 3) Install new clip to seat back. 4) Connect side-air bag (inflator) module connector (1) securely as shown in figure. 5) Insert claw (1) of side-air bag (inflator) module on installation hole (2). 6) Push side-air bag (inflator) module into clip (3) with specified force. Side-air bag (inflator) module installation force Side-Air Bag (Inflator) Inspection S6JB0B8206010 WARNING !
• Never attempt to disassemble or repair the side-air bag (inflator) module. If any • Be sure to read “Precautions on Service and Diagnosis of Air Bag System” before
CAUTION !
If air bag (inflator) module was dropped from
Check air bag (inflator) module appearance visually for impact was applied to it. • Bend or deformity of air bag (inflator) module bracket. 1 2, (a) I4RS0A820073-02 1 2 a) b) I4RS0A820070-01 1 2 3 I4RS0A820074-02 I4RS0A820075-02 |
