8B-34 Air Bag System: 2 1) With ignition switch OFF, disconnect SDM connector “G47” or “G46”. 2) Check proper connection to SDM at terminals “G47-5” and “G47-6” or “G46-1” and “G46-2”. 3) If OK, release shorting bar in SDM connector inserting release tool (1) included in special tool (A). 4) Measure resistance between “G47-5” and “G47-6” terminals [A] or between “G46-1” and “G46-2” terminals Special tool Is resistance 0.95 Ω or more? Substitute a known- “GRN/RED” circuit Step Action Yes No [C] [D] [A] [B] “G47-6” “G46-2” “G47-5” “G46-1” 1, (A) (A) 1, (A) (D) “G27” (B) (C) “G26” BASE OF COLUMN (B) BASE OF COLUMN DRIVER PASSENGER I5JB0A820027-02 |
