(101,1) 北米Model "A1340BE-A" EDITED: 2018/ 4/ 2 The following components are monitored Front sub sensor . Airbag control module (including im- pact sensor and rollover sensor) Frontal airbag module – Driver’s side . Knee airbag module (driver’s side) . Side airbag sensor . Front door impact sensor . Side airbag module . Curtain airbag sensor . Curtain airbag module . Satellite safing sensor (under the rear center seat) Seatbelt pretensioner (driver’s side) . Seatbelt pretensioner and adaptive force limiter (front passenger’s side) Lap belt pretensioner (front passen- ger’s side) Seatbelt buckle switch (front passen- ger’s side) Front passenger’s occupant detection system sensor Front passenger’s occupant detection control module Front passenger’s frontal airbag ON and OFF indicator All related wiring WARNING If the warning light exhibits any of . Flashing or flickering of the warn- ing light . No illumination of the warning light when the ignition switch is . Continuous illumination of the warning light . Illumination of the warning light while driving Immediately take your vehicle to & SRS airbag system servicing WARNING . When discarding an airbag mod- ule or scrapping the entire vehi- . The SRS airbag has no user- serviceable parts. Do not use CAUTION If you need service or repair in areas – CONTINUED – Seat, seatbelt and SRS airbags/SRS airbag (Supplemental Restraint System airbag) 1-69 1 |
