Subaru Forester (2019). Manual - part 34





(282,1)

6-5. Accessory power outlets

CAUTION

.

Do not place any foreign objects,

especially metal ones, such as
coins or aluminum foil, into the
accessory power outlet. That
could cause a short circuit. Al-
ways put the cap on the acces-
sory power outlet when it is not in
use.

.

If the plug on your electric appli-

ance is either too loose or too
tight for the accessory power
outlet, this can result in a poor
contact or cause the plug to get
stuck. Only use plugs that fit
properly.

.

Use of an electric appliance in the

accessory power outlet for a long
period of time while the engine is
not running can cause battery
discharge.

.

Before driving your vehicle, make

sure that the plug and the cord on
your electrical appliance will not
interfere with shifting gears and
operating the accelerator and
brake pedals. If they do, do not
use the electrical appliance while

driving.

Electrical power (12 V DC) is available at
any of the accessory power outlets when
the ignition switch is in either the “ACC” or
“ON” position. Accessory power outlets
are located in the following places.

Power outlet below the climate control
panel

Power outlet in the center console

Power outlet in the cargo area

You can use an in-vehicle electrical appli-
ance by connecting it to an outlet.
The maximum power rating of an appli-
ance that can be connected is 120 W.

Accessory power outlets

280

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(283,1)

CAUTION

.

Do not attempt to use a cigarette

lighter in the accessory power
outlets.

.

Use only electrical appliances

which are designed for 12 V DC.

The maximum power rating of an
appliance that can be connected
is 120 W. Do not use an appliance
which exceeds the indicated wat-
tage for each outlet.

.

When using appliances con-

nected to two outlets simulta-
neously, the total power con-
sumed by them must not exceed
120 W. Overloading the acces-
sory power outlet can cause a
short circuit. Do not use double
adapters or more than one elec-
trical appliance.

NOTE

When the lid of the center console is
closed, an opening remains between
the center console and the lid to allow
the power outlet in the center console
to be used. Pass the cord of the
electrical appliance through this open-
ing.

&

Use with the cigarette lighter
(dealer option)

To use the accessory power outlet as a
cigarette lighter socket, purchase the
cigarette lighter plug, which is an optional
accessory. A cigarette lighter plug is
available from your SUBARU dealer.
The cigarette lighter operates only when
the ignition switch is in the “ON” or “ACC”
position.
To use the cigarette lighter, push in the
knob and wait a few moments. It will
automatically spring up when ready for
use.

WARNING

To avoid being burned, never grasp
the lighter by the end with the
heating element. Doing so could
result in injury and could also da-
mage the heating element.

CAUTION

.

Do not hold the lighter pushed in,

because it will overheat.

.

The electrical power socket is

originally designed to use a gen-
uine SUBARU cigarette lighter
plug. Do not use a non-genuine

– CONTINUED –

Accessory power outlets

281

6

Interior

equipment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(284,1)

cigarette lighter plug in the sock-
et. Doing so may cause a short-
circuit and overheating, resulting
in a fire.

.

If the socket is ever used for a

plug-in accessory such as a cell
phone, that may damage the
portion of the socket’s internal
mechanism that causes a cigar-
ette lighter plug to “pop out” after
its lighter element is heated.
Therefore, do not place a cigar-
ette lighter plug in a socket that
has been used, even once, to
power a plug-in accessory. Doing
so may cause the plug to stick
and overheat, creating a potential
fire hazard.

6-6. USB power supply

CAUTION

.

The specification of a USB term-

inal that can be used is the A-
type. If a different specification of
terminal is connected, power
supply or charging may not be
possible, or the device may mal-
function.

.

There is no guarantee when a

connected device malfunctions
or data is damaged. The connec-
tion of a device shall be per-
formed at your responsibility.

.

To avoid an electric shock or a

malfunction, observe the follow-
ing precautions.

– Do not connect a USB hub.

– Do not insert any metal or

other foreign objects into the
USB terminal.

– Do not spill water or other

liquid on the USB terminal.

.

When you have connected a

cable, pay attention not to pull
on it with your legs. Otherwise, it
may result in injury to you by
falling over, or a malfunction of

the connected device.

.

If a device is connected for a long

time when the engine is not
running, it may cause a dis-
charged battery. Even when the
engine is running, we recom-
mend that you do not connect a
device for an unnecessarily long
time.

.

Do not connect a malfunctioning

device. Doing so may cause
smoke and fire.

NOTE

.

The rated voltage of each USB

terminal is 5 V. For details about a
maximum rated power, refer to “How to
use the USB power supply”
FP283.
Before connecting a device, be sure to
read the instruction manual of the
device and check whether or not this
specification of the output is supported
by the device. If a device that requires
power exceeding the maximum rating
is connected, power supply or charging
may not be possible. Even if charging
could be completed, the time required
for charging may be longer than when
the genuine charger for that device is
used.
.

Depending on the device, charging

USB power supply

282

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(285,1)

may be possible only when a special
cable is used. In this case, be sure to
connect the device using the special
cable.
.

When a device that communicates

with a PC is connected, power supply
or charging may not be possible.
.

When connect a device for charging,

disconnect the device promptly after
charging is completed.

&

How to use the USB power
supply

Front seat USB power supply (An audio
device can be connected and used)

Console USB power supply (power supply
function only) (if equipped)

When the ignition switch is in the “ACC” or
“ON” position and a USB electronic device
is connected to the USB terminal, 5 V DC
power can be supplied to the device. Use
the USB terminal to use or charge an
electronic device.
When using the terminal, open the USB
power supply cover. After use, close the
USB power supply cover.

NOTE

The maximum rated power charges
depending on the number of the term-
inal.

Number of USB
terminal

Maximum rated
power

DC 5 V/2.1 A*

*: The available electricity of the two

USB terminals is a maximum of 4.2 A.

USB power supply

283

6

Interior

equipment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(286,1)

6-7. Ashtray (dealer option)

CAUTION

.

Do not use ashtrays as waste

receptacles or leave a lighted
cigarette in an ashtray. This could
cause a fire.

.

Always extinguish matches and

cigarettes before putting them
into the ashtray, and then close
the ashtray securely. If you keep
the ashtray open, the fire of the
cigarette may spread to another
cigarette butt and start a fire.

.

Do not put flammable material in

the ashtray.

.

Do not leave a lot of cigarette

butts in the ashtray.

NOTE

Particles of ash and tobacco will accu-
mulate around the hinges of the ash-
tray’s inner lid. Clean them off using a
toothbrush or a similar narrow-ended
implement.

The portable ashtray can be installed in
each cup holder or bottle holder. For the
locations of the cup holders, refer to “Cup
holders” FP278.
For the locations of the
bottle holders, refer to “Bottle holders”
FP279.

When using the ashtray, open the lid of the
ashtray. Fully close the lid after using the
ashtray to help reduce residual smoke.

6-8. Floor mat

CAUTION

If the floor mat slips forward and
interferes with the movement of the
pedals during driving, it could cause
an accident. Observe the following
precautions to prevent the floor mat
from slipping forward.

.

Be sure to use a genuine
SUBARU floor mat or an equiva-
lent designed with grommets in
the correct locations.

.

Make sure that the driver’s floor

mat is placed in its proper loca-
tion and is correctly secured on
its retaining pins.

Ashtray (dealer option)

284

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(287,1)

.

Do not use more than one floor

mat.

Retaining pins are located on the driver’s
side floor.
The floor mat should be properly secured
using the built-in grommets, by placing the
grommets over the pins and pushing them
downward.

6-9. Shopping bag hook

CAUTION

Do not hang items on the shopping
bag hook that weigh 6 lbs (3 kg) or
more.

A shopping bag hook is attached to each
side of the cargo area.

6-10. Cargo area cover (if
equipped)

The cargo area cover is provided for
covering the cargo area and to protect its
contents from direct sunlight. This cover is
detachable to make room for additional
cargo.

&

Using the cover

To extend the cover, pull the end of the
cover out of the housing, then insert its
hooks into the catches as shown. To
rewind it, unhook it from the catches and
it will rewind automatically. You should
hold on to the cover and guide it back into
the cover housing while it is rewinding.

– CONTINUED –

Shopping bag hook

285

6

Interior

equipment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(288,1)

WARNING

Do not place anything on the ex-
tended cover. Putting excessive
weight on the extended cover can
break it and an object on the cover
could tumble forward in the event of
a sudden stop or collision. This
could cause serious injury.

CAUTION

Be careful not to scratch the rear
gate stays while extending and re-
winding the cover. Scratches on the
stays could cause leakage of gas
from the stays, which may result in
their inability to hold the rear gate
open.

&

To install the front part of the
cover

CAUTION

For models with a reclining rear
seatback, when reclining, move the
front part of the cover back so that it
is not damaged.

1. Align the right side of the front cover
with the triangle mark before fixing the
cover in place.
2. Align the left side of the front cover with
the triangle mark before fixing the cover in
place.
3. Push the front cover to the right side
and adjust the size of the bar as necessary.

&

To remove the front cover

1. Push the front cover to the right side
and shorten the bar.
2. Remove the front cover.

&

To remove the cover housing

1. Rewind the cover.

2. Push the cover housing to the right
side and shorten it.
3. Take it off the retainer.

Cargo area cover

286

-------------------------------------------------------------------------------------------------------------------------------------------------------------

(289,1)

&

Stowage of the cargo area
cover

The cargo area cover can be stowed in
under the cargo floor.

1. Pull the strap to open the center part of
the cargo floor lid, and then remove the lid.
2. Remove the left and right parts of the
cargo floor lid.

3. Stow the cover housing in the cargo
area end.

&

To install the cover housing

1. Insert the protrusion located on the
right end of the sleeve into the recess of
the retainer.

– CONTINUED –

Cargo area cover

287

6

Interior

equipment

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content   ..  32  33  34  35   ..
