FU(H4DOTC)-7

General Description

FUEL INJECTION (FUEL SYSTEMS)

(1)

Fuel tank

(15)

Clamp

(28)

Evaporation hose D

(2)

Fuel tank band RH

(16)

Evaporation hose A

(29)

Evaporation pipe

(3)

Fuel tank band LH

(17)

Clip

(30)

Evaporation hose E

(4)

Fuel delivery tube

(18)

Fuel tank protector LH (Rear)

(31)

Evaporation hose F

(5)

Fuel return tube

(19)

Stopper RH

(32)

Fuel sub level sensor filter

(6)

Jet pump tube

(20)

Stopper LH

(33)

Fuel sub level sensor protector

(7)

Fuel pump assembly

(21)

Retainer

(34)

Clip

(8)

Fuel pump upper plate

(22)

Heat shield cover





(9)

Fuel pump gasket

(23)

Fuel tank protector RH (Front)

Tightening torque:N·m (kgf-m, ft-lb)

(10)

Fuel level sensor

(24)

Fuel tank protector LH (Front)

T1: 4.4 (0.4, 3.2)

(11)

Fuel sub level sensor

(25)

Evaporation hose B

T2: 9 (0.9, 6.6)

(12)

Fuel sub level sensor upper plate

(26)

Connector

T3: 17.5 (1.8, 12.9)

(13)

Fuel sub level sensor gasket

(27)

Evaporation hose C

T4: 33 (3.4, 24.3)

(14)

Fuel filler hose





FU(H4DOTC)-8

General Description

FUEL INJECTION (FUEL SYSTEMS)

5. FUEL LINE

B

A

C

(27)

(24)

(29)

(23)

(23)

(23)

(23)

(22)

(23)

(39)

(28)

(30)

(26)

(25)

(38)

(38)

T2

T4

T1

T2

T1

T2

T6

T2

T6

T3

(21)

(19)

(17)

(16)

(1)

(1)

(1)

(32)

(33)

(1)

(34)

(31)

(20)

(18)

T2

T2

(33)

(1)

(43)

(23)

(42)

(40) (41)

T2

(23)

(37)

(36)

(31)

(23)

C

FU-03292

(1)

(5)

(1)

(3)

(4)

(2)

(8)

(13)

T5

(35)

T5

T2

(6)

(7)

(13)

(13)

T5

(35)

T5

D

D

B

A

(9)

(1)

(11)

(10)

(12)

(14)

(15)

(1)

(13)

(1)

T5

(13)

T2

FU(H4DOTC)-9

General Description

FUEL INJECTION (FUEL SYSTEMS)

(1)

Clip

(18)

Drain filter

(35)

Fuel damper

(2)

Fuel delivery hose A

(19)

Canister protector

(36)

Drain hose

(3)

Evaporation hose A

(20)

Pressure control solenoid valve

(37)

Drain hose connector

(4)

Fuel return hose A

(21)

Evaporation pipe A

(38)

Evaporation hose C

(5)

Fuel return hose B

(22)

Evaporation pipe B

(39)

Evaporation hose D

(6)

Fuel damper holder

(23)

Clip

(40)

Retainer

(7)

Fuel damper bracket

(24)

Fuel filler pipe

(41)

Evaporation tube

(8)

Fuel delivery hose B

(25)

Shut valve

(42)

Evaporation hose E

(9)

Fuel pipe ASSY A

(26)

Gasket

(43)

Quick connector check cover

(10)

Fuel delivery hose C

(27)

Filler ring





(11)

Fuel return hose C

(28)

Fuel filler cap

Tightening torque:N·m (kgf-m, ft-lb)

(12)

Evaporation hose B

(29)

Fuel tank pressure sensor

T1: 4.4 (0.4, 3.2)

(13)

Clamp

(30)

Evaporation pipe protector

T2: 7.5 (0.8, 5.5)

(14)

Grommet

(31)

Connector A

T3: 8 (0.8, 5.9)

(15)

Fuel pipe ASSY B

(32)

Canister hose A

T4: 17.5 (1.8, 12.9)

(16)

Canister

(33)

Connector B

T5: 1.25 (0.1, 0.9)

(17)

Drain valve

(34)

Canister hose B

T6: 1 (0.1, 0.7)

FU(H4DOTC)-10

General Description

FUEL INJECTION (FUEL SYSTEMS)

6. FUEL PUMP

(1)

Sub tank bracket ASSY

(6)

Fuel filter

(10)

Sub tank

(2)

O-ring

(7)

Clip

(11)

Cushion

(3)

O-ring

(8)

Spacer

(12)

Fuel level sensor

(4)

Fuel pump harness

(9)

Pump ASSY

(13)

Fuel temperature sensor

(5)

Spring

(2)

(1)

(2)

(3)

(4)

(5)

(5)

(6)

(2)

(8)

(9)

(10)

(11)

(12)

(7)

FU-04004

a

b

b

a

C

C

d

d

(13)
