General Description

SEAT BELT SYSTEM

• TEST HARNESS Y

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299AG040

TEST HARNESS Y

Used for troubleshooting seat belt buckle switch.

ST98299AG040

2Y

1Y

1Y

1Y

2Y

2Y

AB-01069

1

2

1

2

1

2

1

2

SB-11

General Description

SEAT BELT SYSTEM

• AIRBAG RESISTOR

2. GENERAL TOOL

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299PA040

AIRBAG RESISTOR

Used in replacement of airbag module for which
resistance value is same as airbag module.
Two ST are required for diagnosis of two-stage
inflator type airbag module.

ST98299PA040

AB-00433

3

1

2

1
2

1
2

1

3

4

5

6

2

4

3

TOOL NAME

REMARKS

TORX

®

 T50

Used for removing and installing the inner seat belt assembly.

SB-12

Pretensioner Connector

SEAT BELT SYSTEM

2. Pretensioner Connector

A: PROCEDURE

Refer to airbag connectors in the airbag section.
<Ref. to AB-8, PROCEDURE, Airbag Connector.>

SB-13

Inspection Locations After a Collision

SEAT BELT SYSTEM

3. Inspection Locations After a

Collision

A: INSPECTION

Check for the following, and replace with new parts
if necessary.
• Center pillar lower trim is discolored or cracked.
• Wiring harness and connector are damaged.
