AB(diag)-8

General Description

AIRBAG SYSTEM (DIAGNOSTICS)

C: PREPARATION TOOL

CAUTION:
To measure the voltage and resistance of airbag system component, be sure to use the specified test
harness.

1. SPECIAL TOOL

• TEST HARNESS F

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

1B022XU0

SUBARU SELECT
MONITOR III KIT

Used for troubleshooting the electrical system.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299FC010

TEST HARNESS F

Used when measuring voltage and resistance of
airbag module harnesses.

ST1B022XU0

3F

2F

1F

ST98299FC010

AB-00927

3F

3F

2F

1F

2F

1F

4

3

6

5

1

1

2

2

1
3 4 5 6

2

1 2

2 1

AB(diag)-9

General Description

AIRBAG SYSTEM (DIAGNOSTICS)

• TEST HARNESS H

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299FA030

TEST HARNESS H

Used when measuring voltage and resistance of
front sub sensor and satellite safing sensor.

3H

2H

1H

ST98299FA030

AB-00720

3H

3H

2H

1H

2H

1H

4

3

6

5

1
3 4 5 6

2

1

1

2

2

2

1

2 1

AB(diag)-10

General Description

AIRBAG SYSTEM (DIAGNOSTICS)

• TEST HARNESS N

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299SA000

TEST HARNESS N

Used when measuring voltage and resistance of
driver’s airbag module and seat belt preten-
sioner.

2N

1N

ST98299SA000

AB-00928

2N

1N

1

2

2

1

1

2

2

1

1N

2N

AB(diag)-11

General Description

AIRBAG SYSTEM (DIAGNOSTICS)

• TEST HARNESS P

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

98299SA020

TEST HARNESS P

Used when measuring voltage and resistance of
driver’s airbag module harness and passenger’s
airbag module harness.

ST98299SA020

1P

2P

3P

AB-00679

1P

2P

3P

4

1

2

4

3

3

2

1

4

1

2

3

4

3

1

2
