ME(H4SO)-8

General Description

MECHANICAL

4. CYLINDER HEAD AND VALVE ASSEMBLY

(1)

Exhaust valve

(4)

Valve spring seat

(7)

Retainer

(2)

Intake valve

(5)

Intake valve oil seal

(8)

Retainer key

(3)

Valve guide

(6)

Valve spring

(9)

Exhaust valve oil seal

ME-03322

(2)

(2)

(6)

(6)

(3)

(3)

(4)

(4)

(5)

(9)

(7)

(8)

(7)

(8)

(1)

(1)

ME(H4SO)-9

General Description

MECHANICAL

5. CYLINDER BLOCK

ME-03563

(1)

(29)

(28)

(2)

(3)

(3)

(3)

(4)

(4)

(4)

(5)

(31)

(6)

(7)

(32)

(8)

(32)

(9)

(10)

(10)

(11)

(10)

(28)

(12)

(29)

(15)

(25)

(23)

(22)

T9

T10

T2

T2

T5

T6

T2

T2

T2

T4

T10

T2

T4

T4

T2

T10

T4

T5

T7

(13)

(24)

(26)

(28)

T1

T8

(17)

(18)

(19)

(20)

(30)

(21)

T2

(27)

T3

T2

(16)

(10)

(14)

T2

ME(H4SO)-10

General Description

MECHANICAL

(1)

Oil pressure switch

(17)

Gasket

(32)

Oil pump seal

(2)

Cylinder block RH

(18)

Oil pan





(3)

Service hole plug

(19)

Drain plug

Tightening torque:N·m (kgf-m, ft-lb)

(4)

Gasket

(20)

Drain plug gasket

T1: 5 (0.5, 3.7)

(5)

Oil separator cover

(21)

Oil level gauge guide

T2: 6.4 (0.7, 4.7)

(6)

Water by-pass pipe

(22)

Water pump sealing

T3: 10 (1.0, 7.4)

(7)

Oil pump

(23)

Oil filter

T4: 25 (2.5, 18.4)

(8)

Front oil seal

(24)

Gasket

T5: <Ref. to ME(H4SO)-71, INSTAL-

LATION, Cylinder Block.>

(9)

Rear oil seal

(25)

Water pump hose

(10)

O-ring

(26)

Plug

T6: 16 (1.6, 11.8)

(11)

Service hole cover

(27)

Seal

T7: First 12 (1.2, 8.9)

Second 12 (1.2, 8.9)

(12)

Cylinder block LH

(28)

Seal washer

(13)

Water pump

(29)

Washer

T8: 44 (4.5, 32.5)

(14)

Baffle plate

(30)

O-ring

T9: 45 (4.6, 33.2)

(15)

Oil filter connector

(31)

Engine rear hanger

T10: 70 (7.1, 51.6)

(16)

Oil strainer





ME(H4SO)-11

General Description

MECHANICAL

6. CRANKSHAFT AND PISTON

(1)

Flywheel (MT model)

(9)

Piston pin

(17)

Crankshaft bearing #1, #3

(2)

Ball bearing (MT model)

(10)

Snap ring

(18)

Crankshaft bearing #2, #4

(3)

Reinforcement (AT model)

(11)

Connecting rod nut

(19)

Crankshaft bearing #5

(4)

Drive plate (AT model)

(12)

Connecting rod





(5)

Top ring

(13)

Connecting rod bearing

Tightening torque:N·m (kgf-m, ft-lb)

(6)

Second ring

(14)

Connecting rod cap

T1: 45 (4.6, 33.2)

(7)

Oil ring

(15)

Crankshaft

T2: 72 (7.3, 53.1)

(8)

Piston

(16)

Woodruff key





ME-03549

(5)

(6)

(7)

(8)

(12)

(13)

(13)

(16)

(13)

(19)

(18)

(17)

(17)

(18)

(13)

(15)

(14)

(11)

(14)

(9)

(11)

(1)

(2)

(4)

(3)

T1

T1

T2

T2

(10)

(10)

(12)

(7)

(6)

(5)

(9)

(8)

(10)

(10)
