FU(H4SO)-5

General Description

FUEL INJECTION (FUEL SYSTEMS)

3. CRANKSHAFT POSITION, CAMSHAFT POSITION AND KNOCK SENSORS

(1)

Crankshaft position sensor

(3)

Camshaft position sensor

Tightening torque:N·m (kgf-m, ft-lb)

(2)

Knock sensor

(4)

Camshaft position sensor support

T1: 6.4 (0.7, 4.7)

T2: 24 (2.4, 17.7)

FU-00414

T1

(1)

(2)

T1

T1

(3)

(4)

T2

FU(H4SO)-6

General Description

FUEL INJECTION (FUEL SYSTEMS)

4. FUEL TANK

FU-03250

T1

(11)

(12)

(13)

(31)

(32)

(7)

T4

T1

T4

T3

T3

T3

T2

T3

T3

T4

(16)

(14)

(15)

(15)

(17)

(19)

(17)

(3)

(22)

(23)

(24)

(2)

(20)

(21)

(8)

(10)

(17)

(17)

(30)

(9)

(1)

T2

T3

(17)

(25)

(26)

(27)

(17)

(29)

(28)

(5)

(6)

(4)

(6)

(18)

(17)

(17)

FU(H4SO)-7

General Description

FUEL INJECTION (FUEL SYSTEMS)

(1)

Fuel tank

(14)

Fuel filler hose

(27)

Evaporation hose C

(2)

Fuel tank band RH

(15)

Clamp

(28)

Evaporation hose D

(3)

Fuel tank band LH

(16)

Evaporation hose A

(29)

Evaporation pipe

(4)

Delivery tube

(17)

Clip

(30)

Evaporation hose E

(5)

Jet pump tube

(18)

Evaporation hose F

(31)

Fuel sub level sensor filter

(6)

Retainer

(19)

Fuel tank protector LH (Rear)

(32)

Fuel sub level sensor protector

(7)

Fuel pump ASSY

(20)

Stopper RH





(8)

Fuel pump upper plate

(21)

Stopper LH

Tightening torque:N·m (kgf-m, ft-lb)

(9)

Fuel pump gasket

(22)

Heat shield cover

T1: 4.4 (0.4, 3.2)

(10)

Fuel level sensor

(23)

Fuel tank protector RH (Front)

T2: 9 (0.9, 6.6)

(11)

Fuel sub level sensor

(24)

Fuel tank protector LH (Front)

T3: 17.5 (1.8, 12.9)

(12)

Fuel sub level sensor upper plate

(25)

Evaporation hose B

T4: 33 (3.4, 24.3)

(13)

Fuel sub level sensor gasket

(26)

Connector





FU(H4SO)-8

General Description

FUEL INJECTION (FUEL SYSTEMS)

5. FUEL LINE

B

A

A

C

(27)

(24)

(29)

(23)

(23)

(23)

(23)

(22)

(23)

(38)

(28)

(30)

(26)

(25)

(37)

(37)

T2

T4

T1

T2

T1

T2

T6

T2

T6

T3

(21)

(19)

(17)

(16)

(1)

(1)

(1)

(32)

(33)

(1)

(34)

(31)

(20)

(13)

(12)

(10)

(9)

(13)

(13)

(15)

(14)

(18)

T2

T2

(33)

(1)

(23)

(39)

(11)

(8)

T2

(23)

(36)

(35)

(31)

(23)

C

FU-03120

(7)

(2)

(13)

(5)

(6)

(3)

(1)

(1)

(4)

(13)

T5

T5
