PI-5
Pre-delivery Inspection
PRE-DELIVERY INSPECTION
1. APPEARANCE CHECK
• If the vehicle is covered with protective coating,
visually check the vehicle body for damage and
dents.
• When the protective coating is removed, visually
check the body paints for damage or stains in detail
and repair as necessary.
• Visually check the windshield glass, door glass-
es and light lenses for any damage, cracks or ex-
cessive gaps to the body sheet metal and repair as
necessary.
• Visually check the plated parts, such as the
grilles and door knobs, for damage or loss of gloss
and replace the parts as necessary.
2. TIRE CHECK
• Check the tires for damage, defective, and dents
on wheels.
• Check and adjust the tire size, spare tire and tire
air pressure described on the tire air pressure label
(driver’s side).
3. FUSE INSTALLATION
Fuses for the back-up circuit have been removed to
prevent battery discharge. If the vehicle is about to
be delivered to the customer, attach a 20 A fuse (A)
as shown in the figure.
4. LOCK/UNLOCK AND OPEN/CLOSE
OPERATION CHECKS OF DOORS
1) Using the key, lock and unlock the door several
times to check for normal operation. Open and
close the door several times for smooth movement.
2) Completely close the driver’s door, and then
check the smooth movement with operating door
lock knob from lock to unlock several times. Set the
door lock knob (A) to lock position. Then pull the in-
ner remote (B) to ensure that doors will not open.
For other doors, place the door lock knob (A) to lock
position and then pull the inner remote (B) to en-
sure that doors will not open.
3) Close all the doors, and then press the lock on
power door lock switch at driver’s side. Check that
all doors including rear gate are locked.
PI-00158
(A)
(A) Unlock
(B) Lock
(A) Door lock knob
(B) Inner remote
PI-00246
(A)
(B)
(A)
(B)
PI-00192
PI-00392
