EI-18
EXTERIOR/INTERIOR TRIM
FRONT BUMPER
10
Sanding (II)
Remove excess part of weld with a putty knife. If a drill or disc wheel is used instead of the knife,
operate it at a rate lower than 1,500 rpm and grind the excess part little by little. A higher rpm will
cause the PP substrate to melt from the heat.
Sand the welded spot smooth with #240 sand paper.
11
Masking
Mask the black substrate section using masking tape.
Recommended masking tape: Nichiban No. 533 or equivalent
12
Cleaning/
degreasing
Completely clean the entire coated area, using solvent similar to that used in Process No. 4.
13
Primer coating
Apply a coat of primer to the repaired surface and its surrounding areas. Mask these areas, if nec-
essary.
Recommended primer: Mp/ 364 PP Primer
NOTE:
Be sure to apply one coat of primer at a spraying pressure of 245 to 343 kPa
(2.5 to 3.5 kg/cm
2
, 36 to 50 psi) with a spray gun.
14
Leave unattended.
Leave the repaired area unattended at 20
°
C (68
°
F) for 10 to 15 minutes until primer is half-dry.
NOTE:
If dirt or dust comes in contact with the coated area, wipe it off with a cloth dampended with alcohol.
(Do not use thinner since the coated area tends to melt.)
15
Primer surfacer
coating
Apply a coat of primer surfacer to the repaired area two or three times at an interval of 3 to 5 min-
utes.
Recommended surfacer:
• UPS 300 Flex Primer
• No. 303 UPS 300 Exclusive hardener
• NPS 725 Exclusive Reducer (thinner)
• Mixing ratio: 2 : 1 (UPS 300: No. 303)
• Viscosity: 12 — 14 sec/20
°
C (68
°
F)
• Coated film thickness: 40 — 50
µ
16
Drying
Allow the coated surface to dry for 60 minutes at 20
°
C (68
°
F) [or 30 minutes at 60
°
C (140
°
F)].
17
Sanding (III)
Sand the coated surface and its surrounding areas using #400 sand paper and water.
18
Cleaning/
degreasing
Same as Process No. 12.
19
Top coat (I)
Solid color
Metallic color
Use a “block” coating method.
• Recommended paint:
Suncryl (SC)
No. 307 Flex Hardener
SC Reducer (thinner)
• Mixing ratio: 3 : 1
Suncryl (SC) vs. No. 307 Flex Hardener
• Viscosity: 11 — 13 sec/20
°
C (68
°
F)
• Coated film thickness: 40 — 50
µ
• Spraying thickness: 245 — 343 kPa
(2.5 — 3.5 kg/cm
2
, 36 — 50 psi)
Use a “block” coating method.
• Recommended paint:
Suncryl (SC)
No. 307 Flex Hardener
SC Reducer (thinner)
• Mixing ratio: 3 : 1
Suncryl (SC) vs. No. 307 Flex Hardener
• Viscosity: 11 — 13 sec/20
°
C (68
°
F)
• Coated film thickness: 20 — 30
µ
• Spraying thickness: 245 — 343 kPa
(2.5 — 3.5 kg/cm
2
, 36 — 50 psi)
20
Leave unattended.
Not required.
Leave unattended at 20
°
C (68
°
F) for at least 10
minutes until the topcoated area is half-dry.
NOTE:
Be careful to keep dust or dirt from coming in
contact with the affected area.
Pro-
cess
No.
Process name
Job contents
EI-00042
