SSANGYONG  Y200

0B-8  GENERAL INFORMATION

SPECIFICATIONS  (Cont’d)

Systems

Transfercase

Clutch

Power

steering

Front axle

Rear axle

Brake

Suspension

Air

conditioner

Electrical

Items

Model

Type

Type

Disc type

Type

Drive shaft type

Axle housing type

Drive shaft type

Axle housing type

Master cylinder type

Booster type

Parking brake

Front

Rear

Refrigerant

Compressor type

Battery type/Capacity (V-AH)

Starter capacity (V-kW)

Alternator capacity (V-A)

Diesel

Part-time

Planetary gear type

1.000 : 1

2.483 : 1

Hydraulic

[A/T: Torque converter]

Dry single diaphragm type

[A/T: 3 elements 1 stage 2

phases]

Rack and pinion

36°17

′

32°40

′

Ball joint type

Build-up type

Semi-floating type

Build-up type

Tandem type

Vacuum booster

Disc

Drum (Disc)

Cable type (internal expansion)

Wishbone + Coil spring

5-link + Coil spring

R134a

Vane type

MF / 12 - 90

12 - 2.2

12 - 75 (12 - 90)

Gasoline G32D (G23D)

Full-time (Part-Time)

←
←
←

Torque converter

3 elements 1 stage 2 phases

←
←
←
←
←
←
←
←
←
←

Disc (Drum)

←
←
←
←
←

MF / 112 - 75

12 - 1.8

12 - 115

High

Low

Inner

Outer

Front

Rear

Gear ratio

Type

Steering angle

GENERAL INFORMATION  0B-9

SSANGYONG  Y200

Approved by MB

Sheet 229.1 or 229.3

Viscosity: See MB

Sheet 224.1

Approved by MB

Sheet 229.1 or 229.3

Viscosity: See MB

Sheet 224.1

CASTROL

TQ95

(ATF DEXRON II or III)

 (DOT 4)

ATF DEXRON

â

 II, III, ATF S-2,

S-3, S-4, TOTAL FLUID ATX

ATF DEXRON

â

 II,III, ATF S-2,

S-3, S-4, TOTAL FLUID ATX

DOT4

API GL-5 or

SAE 80W/90

API GL-5 or

SAE 80W/90

(ATF DEXRON II)

Engine Oil

Automatic Transmission

Fluid*

Manual Transmission Fluid

Clutch Fluid

(For Manual Transmission)

Transfer Case

Fluid

Brake Fluid

Front and Rear

Axle Fluid

Power Steering Fluid

Coolant

Air Cleaner

Fuel filter

RECOMMENDED FLUIDS AND LUBRICANTS

Usage

Specification

Service interval

Capacity (L)

Initial change: 1,000 km, Change

every 10,000 km or 12 months

(But, every 5,000 km or 6 months

under severe conditions)

Initial change: max. 1,000 km,

Change every 15,000 km or 12 months

(But, every 7,500 km or 6 months

under severe conditions)

Inspect every 30,000 km or 12 months

(But, change every 60,000 km

under severe conditions)

Initially change at 12,000 km, and

Inspect every 50,000 km

Inspect frequently, Change every

40,000 km or 2 years

Inspect every 10,000 ~ 15,000 km

Change every 60,000 km

Inspect every 10,000 ~ 15,000 km

Change every 60,000 km

Change every 40,000 km or 2 years

(Inspect frequently)

Inspect frequently

Change every 38,000 km

Inspect frequently

Change every 38,000 km

Check and replenish as necessary.

6.0 ~ 8.0

7.0 ~ 9.0

5.5 ~ 7.5

Approx. 9.5 L

Approx. 3.4 L

As required

1.2 L

1.4 L

As required

1.4 L

1.9 L

Approx. 1.1 L

10.5~11.0 L

10.0~10.5 L

11.0~11.5 L

D29ST

G32D

G23D

Part-time

Full-time

Front Axle

Rear Axle

D29ST

G23D

G32D

Diesel

Gasoline

Diesel

Gasoline

Change every 3 years. And, inspect and replenish as necessary.

Clean every 10,000 km, Replace every 30,000 km

Clean every 15,000 km, Replace every 60,000 km

Replace every 45,000 km

Replace every 60,000 km

SSANGYONG  Y200

0B-10  GENERAL INFORMATION

VEHICLE IDENTIFICATION NUMBER SYSTEM

 * K P T G 0 B 1 9 S 1 P 000000

12~17. Production Serial Number

: 000001- 999999

11. Plant Code

P : PyongTaek Plant

10. Model Year

2 : 2002

3 : 2003

9. Check Digit

S : All area except North America

8. Engine Type

6 : 2295cc, In-line 4Cylinder, Gasoline (E23)

9 : 3199cc, In-line 6Cylinder, Gasoline (E32)

D : 2874cc, In-line 5Cylinder, Diesel (662LA)

7. Restraint System

1 : 3-Point Seat Belts, 2 : 2-Point Seat Belts

6. Trim Level

A : Standard, B : Deluxe, C: Super Deluxe

5. Body Type

0 : 5-Door

1 : 4-Door

2 : 3-Door

4. Line Models

G: Rexton (LHD)

H : Rexton (RHD)

3. Vehicle Type

T : Passengr Cars, A : Truck

2. Maker Identification : P

1. Nation : K

*. Symbol according to No.

YAA0B040

VEHICLE IDENTIFICATION
NUMBER (VIN)

Vehicle Identification Number (VIN) is on the right front
axle upper frame.

GENERAL INFORMATION  0B-11

SSANGYONG  Y200

YAA0B050

YAA0B060

YAA0B070

MANUFACTURER’S PLATE

1 Type Approval No.
2 Vehicle Identification No.

Manufacturer’s Plate Location

Gasoline Engine

Diesel Engine
