ELECTRICAL WIRING DIAGRAMS 5-157
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (K) - Engine
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (LH)
Floor - T/M
Floor - T/M
Floor - RR Defogger
W/H Main
W/H Main
W/H Floor
W/H Floor
C108 (4Pin, Colorless)
C203 (13Pin, Green)
C205 (11Pin, White)
C208 (20Pin, Black)
C209 (22Pin, Yellow)
C901 (2Pin, White)
C901 (12Pin, White)
C393 (4Pin, White)
S202 (14Pin, Black)
S206 (14Pin, Black)
G304
G305
Connecting Wiring
Harness
EEngine Room Fuse Box
Under the I/P Fuse Box
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Left the T/C (Under the Floor)
Left the T/C (Under the Floor)
Inside the Upper the Tail Gate
Upper the I/P Relay Box
Behind the Left the FATC
Behind the Quarter Grass #1
Behind the Quarter Grass #1
M/T
XDi
Remark
Connector Position
