5
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
RK STICS
STAVIC - 2004.09
2C
Door lock
Auto door unlock
Front room lamp
Time lag power window control
Parking brake warning
Tail lamp auto cut (battery saver)
Theft deterrent alarm
Panic alarm operating only
(ON: IGN S/W in)
Headlamp control (escort)
3. DESCRIPTIONS
Below table shows the major differences compared to the previous vehicle model before year 2004. For whole functions
and details, refer to corresponding section.
The door unlock output is sent to all doors once for 0.5 seconds when the “LOCK”
signal is inputted into unit within 0.5 seconds after closing the driver’s or
passenger’s door. This is regardless of key in or key out. It is to prevent the
doors from locking due to impact when the door is closed.
Previously, G-sensor in STICS outputs auto door unlock signal if the vehicle
collides over 15 km/h of vehicle speed. However, the air bag system is installed
in this vehicle as a basic equipment. When a collision, the “Auto Door Unlock”
function is activated by using a collision signal from the air bag module.
1. When receiving the unlock signal from remote control key with the door
closed, the front room lamp comes on for 30 seconds.
2. When receiving the unlock signal again during the time lagging operation,
another 30 seconds will be extended from unlock point.
The power window can be operated for 30 seconds after removing the ignition
key from key switch. This lagging operation stops when closing the door.
When the vehicle speed signal is inputted with the parking brake applied, the
warning light blinks and the chime buzzer in ICM box continuously sounds for 0.
6 seconds with 0.3 seconds of pausing time (when driving over 10 km/h of vehicle
speed for more than 2 seconds).
1. Turns on or off the tail lamp relay according to the tail lamp switch
operations.
2. The tail lamp relay is turned off (auto-cut) when removing the ignition key
and opening and closing the door while the tail lamp switch is turned on.
The hazard warning relay in ICM box outputs when the remote control key is
operated or the theft deterrent alarm is activated. At this time, separate warning
horn sounds.
1. The theft deterrent horn sounds for 27 seconds when receiving the panic
signal from the remote control key.
2. The panic alarm is turned off when receiving any signal from the remote
control key during the panic alarm operation.
3. This function works under armed mode.
1. The headlamp control supplies the power to headlamp relay for 20 seconds and
turns off when receiving the escort signal from the remote control key with the
ignition key off (if the escort signal is inputted again, it will be extended once for
20 seconds). However, the power supply and output is activated only when the
vehicle is in armed mode activated by remote control key.
2. The headlamp relay output is turned off immediately after receiving the
remote control lock signal during its operation (however, signals other than
lock signal from remote control key will be ignored).
3. The headlamp relay output is immediately turned off when the key is turned
to “ON” position during its operation (this function is also activated under
remote starting).
Item
RK STICS
