SsangYong Stavic / SsangYong Rodius (2005 year). Manual - part 201

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ELECTRICAL SYSTEM

STAVIC - 2004.09

4

2A

2. SWITCHES, UNITS AND SENSORS IN ENGINE COMPARTMENT

(EXCEPT ENGINE RELATED SENSORS AND UNITS)

Horn

Ambient temperature sensor (FFH)

Receiver drier

AQS/Ambient temperature sensor

(Integrated type) – Air conditioner

FFH (Fuel Fired Heater)

AQS sensor

Ambient tempera-

ture sensor

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ELECTRICAL SYSTEM

STAVIC - 2004.09

5

2A

Fuse and relay box in engine

compartment

Brake pressure sensor

ABS (ESP) HECU (under the battery)

PTC power supply relay (PTC system

equipped vehicle)

Sub condenser

Theft deterrent horn (under the

washer fluid reservoir)

beside battery positive

(+) terminal

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ELECTRICAL SYSTEM

STAVIC - 2004.09

6

2A

3. SWITCHES IN PASSENGER COMPARTMENT

4WD switch and rear washer/
wiper switch

Outside rearview mirror
adjusting and folding
switch

Window switches

Audio remote control switch on the steering wheel

Power button

Mode button

SEEK button – Up

SEEK button – Down

Mute button

Volume button – Up

Volume button – Down

CHANGED BY

EFFECTIVE DATE

AFFECTED VIN

ELECTRICAL SYSTEM

STAVIC - 2004.09

7

2A

Room lamp and sun roof switch

(multi meter integrated type)

Multi meter

Driver seat warmer
s w i t c h

Outside rearview mirror and
rear glass heated switch

ESP

OFF

Passenger seat
warmer switch

Hazard switch

Passenger’s window

switch

Multifunction switch and

steering wheel angular sensor

Room lamp switch
(coupled operation
with door)

Sun roof switch

Front room lamp switch

Front room lamp switch

Front defogger switch

Front fog lamp
