03-4

Driver's Seat

Seat air bag added; armrest and lumbar support removed
Lumbar support used for vehicle without seat air bag

4. CHANGES IN SEAT & SEAT BELT

1) Front Seat

Lumbar support

Side air bag module

Under tray

Armrest

3. CAUTIONS FOR POWER SEAT

You can operate the power seat with the ignition switch OFF. However, frequent operation of the

seat switch with the engine stopped can result in battery becoming discharged.

Operating more than one seat adjustment switch at the same time can cause damage to the seat

motor. Therefore, operate the seat switch only one at a time.

Do not use organic solvents such as benzene, thinner, alcohol or gasoline to prevent the seat

cover from being damaged while cleaning.

Do not operate the seat position adjustment switch forcefully when the seat does not move or it

contacts an object.

If the power seat is not operated, check and correct the problem before driving off.

1.

2.

3.

4.

5.

Front Passenger's Seat

Under tray removed

03-5

7410-01

2) Rear Seats

3) Rear Seat Rails

Outer storage box and 2-point seat belts for LH/RH seat removed as the rear 1st row seat swing
function has been removed
Rear 1st row and 2nd row seat cushions changed(11p Only)

Moving distance for rear 1st row and 2nd row seats changed; whole moving distance changed (from
680 mm to 720 mm)

03-6

Seat warmer switch

Sliding adjust lever

Back flat adjust lever

1. LAYOUT AND COMPONENTS

1) Components of Seat

Seat Control Switch (Driver's Seat)

Seat position control

Seat height control

Reclining control

Back supporter

(Driver’s seat)

Sliding control

03-7

7410-01

Seat sliding adjust lever

Rear 3rd Row Seatback Folding Lever

Headrest

Back folding adjust lever
