01-4

Headlamp

Puddle lamp

Front fog light

Side repeater

Turn signal

lamp

Headlamp

(High beam)

Headlamp

(Low beam)

Tail lamp,

DRL (EU)*

01-5

0000-00

High mounted stop lamp

License plate lamp

Rear combination lamp

Vehicle with spoiler

Vehicle without spoiler

Back-up lamp

Stop lamp

Tail lamp

Turn signal

lamp

Stop lamp,

Rear fog

light (EU)

01-6

Front room lamp

Glove box lamp

Sun visor lamp

2. INTERIOR LAMP SYSTEM LAYOUT

01-7

0000-00

Luggage lamp

Door courtesy lamp

Center room lamp
