SsangYong Korando III (2010 year). Manual - part 418

01-11

0000-00

02-3

0000-00

1. SPECIFICATIONS

System

Unit

Description

Specification

Intake

system

Air cleaner element

Filtering type

Dry, filter element

Filtering area

0.208m²

Service interval

EU: Change every 20,000 km

(But, shorten the service

interval under severe

conditions)

GEN: Clean every 7,500 km,

change every 15,000 km (But,

shorten the service interval

under severe conditions)

Air cleaner assembly

Weight

1.5kg

Operating temperature

-30 ~ 100℃

Capacity

8L

Intercooler

Core material

Aluminum

Size

510X122X67(WxHxT)

Tank material

Plastic (Molding)

Efficiency

80%

Exhaust

system

Turbocharger assembly

Max. temperature of turbine

housing

780 ℃

Diameter of turbine housing

ø40.0

Diameter of compressor

housing

ø46.8

Cooling type

Air cooled type
