03-22 (3) 1st Drive Gear (4.212) Front sun gear and middle & rear planetary gears locked, and rear sun gear always rotated When the rear sun gear rotates, the rear planetary gear set reduces the speed at first, and then the reduced power is transferred to rear & front annulus gear. The power is secondarily reduced at front planetary gear locked with sun gear and flows to front planetary gear. At this moment, the middle sun gear rotates in reverse direction without load (idling) by the rotation of middle annulus gear integrated with front planetary gear. - - - Power flow ▶ Description 35R C OD C 26 B UD B LR B O.W.C 1ST ● ○ ● Operated below 5 km/h of vehicle speed O : |
