03-6 3. SPECIFICATIONS 1) Specifications Type/Weight 6F24 6-speed automatic transaxle / approx. 86 kg (including ATF) TORQUE 230 Nm Overall length / Center length 373.1 mm / 204 mm Descriptions Specification Gear ratio 1st gear 4.212 2nd gear 2.637 3rd gear 1.800 4th gear 1.386 5th gear 1.000 6th gear 0.772 Reverse gear 3.385 Shift pattern Variable Shift range 4 Range (P-R-N-D) + Manual mode Shift range valve VFS : 6EA Planetary gear 3EA (Front, Middle, Rear) Clutch 2EA Brake 3EA O.W.C 1EA Oil Type ATF SP-IV or SP-IV M Capacity approx. 7.1 L Change interval Maintenance free. However, under the severe conditions or commercially used, change the oil at every 100,000 km (EU: 90,000 km). Resistance of oil temperature sensor -20 Approx 15.6kΩ 0 Approx 5.88kΩ 20 Approx 2.51kΩ 100 Approx 0.18kΩ Weight 2WD 87.5kg 4WD 88.5kg |
