(6) Limitations/Interruption of smart key function

The SKM searches for a smart key inside the vehicle when it receives the information on entering the

theft deterrent mode from the BCM. If a normal smart key is identified, the SKM memorizes this as a

function-limited key (Silent Smart Key) or a function interrupted key (Deactivation Smart Key) according

to the conditions.

If a smart key, which outputs the door LOCK signal, is found inside the vehicle, the SKM memorizes

all the smart keys inside the vehicle as function limited keys (Silent Smart Key).

The function limited smart key provides the passive START, ignition status change and REKES

functions except the passive UNLOCK function.

-

-

Function limitation

▶

Function interruption

▶

How to deactivate function limited/interrupted smart key

▶

Deactivate the theft deterrent mode.

-

If no smart key, which outputs the door LOCK signal, is found inside the vehicle, the SKM memorizes

all the smart keys inside the vehicle as function interrupted keys (Deactivation Smart Key).

The function interrupted smart key is not available for the passive LOCK/UNLOCK, passive START,

ignition status change and REKES functions.

-

-

04-17

8712-03

3) REKES Control Function

(2) REKES UNLOCK

The SKM receives the signal for [REKES UNLOCK] 0.1 sec. after the UNLOCK button on the smart

key is turned ON, and sends this signal through the BCAN.

-

When the SKM receives the REKES signals by the buttons on the smart key, it transmits the

corresponding signals through the BCAN.

Switch

Stage

Remark

LOCK

1 step

100 ms: 1 step CMD

1500 ms: 2 step CMD
1000 ms: 3 step CMD

unlocked

1 step

Tailgate open

3 step

PANIC

3 step

(3) Remote keyless tailgate open

When the SKM receives the signal for [REKES UNLOCK] by the UNLOCK button on the smart key, it

transmits this signal through the BCAN.

(1) REKES LOCK

The SKM receives the signal for [REKES LOCK] 0.1 sec. after the LOCK button on the smart key is

turned ON, and it transmits this signal through the BCAN.

When the REKES LOCK signal is received with the ACC ON, the ACC is turned OFF and the signal

for [REKES LOCK] is sent.

-

-

When the SKM receives the signal for [REKES LOCK] by the LOCK button on the smart key, it transmits

this signal through the BCAN.

The SKM receives the tailgate open signal 1 sec. after the tailgate open button on the smart key is

turned ON with the ignition status OFF, ACC or IGN ON, and it transmits the signal for [REKES

tailgate open] through the BCAN.

-

When the SKM receives the signal for [REKES tailgate open] by the tailgate open button on the smart

key, it transmits this signal through the BCAN.

Remote keyless tailgate open

▶

04-18

(4) Remote keyless panic

When the SKM receives the panic signal with the ignition status OFF, ACC ON or IGN ON, the SKM

transmits the REKES panic signal through the BCAN.

The SKM transmits the signals for [REKES panic] by the panic button of the smart key to the BCM.

Panic siren mode by REKES panic control

▶

The SKM receives the REKES panic signal 1 sec. after the panic button on the smart key is turned ON

with the ignition status OFF, ACC or IGN ON, and it transmits this signal through the BCAN.

Remote keyless panic

▶

04-19

8712-03

4) Smart Key Verification Time Control

(1) Pre-verification timer

When the operation signal from the START switch is received, the START & power control functions can

be performed without smart key verification.

(2) Immobilizer verification timer

The immobilizer verification status indicates that it is possible to respond to the request message sent

from the EMS to deactivate the immobilizer. The SKM verified a smart key and the engine can be

started.

The 30-second immobilizer verification time is started when:

the ignition status is changed to IGN by the START switch while the pre-verification timer is activated.

the ignition status is changed to IGN by the smart key verification while the pre-verification timer is

stopped; the SKM verified a smart key by the brake switch signal while the immobilizer verification

timer is stopped or the ignition status is IGN ON.

the SKM verified a smart key successfully if the immobilizer verification timer is stopped with IGN

ON/immobilizer verification /brake switch ON.

-

-

-

Condition

SKM operation

- when door closed signal is input with - B+ or ACC ON
- when brake is applied with - B+ or ACC ON
- when START switch is operated with - B+
- when smart key is inserted into slot & brake switch is
  operated or START switch is operated with - B+

Once the vehicle interior verification
is completed, 30 sec. pre-verification
timer is started

when the ignition is turned OFF with IGN ON and engine
running

30 sec. pre-verification timer is
started without re-verification

Timer deactivation conditions: after 30 sec. has passed, IGN ON, Outside door handle switch ON,
entering theft deterrent mode when door condition is changed

IGN1 OFF

30 sec. has passed after immobilizer verification

Any door is opened and then closed when all doors are closed & smart key out

When the engine starts to run, the immobilizer verification status is determined, and the immobilizer will

not be deactivated until the ignition status is changed to IGN/ACC/OFF.

The immobilizer is not deactivated when the key out warning condition is met while the engine is

running. (when the RND is received by the EMS reset while the engine is running)

When attempting to start the engine without immobilizer verification, the system performs smart key

verification procedures, and sends the engine start request to EMS only when the verification result is

normal.

-

-

-

*

*

*

Entry conditions

▶

Deactivation condition

▶
