01-14

Engine ECU

2. FUEL SYSTEM

Engine compartment

Purge control solenoid

valve

Fuel rail

Injector

01-15

0000-00

Fuel tank assembly

Canister

Fuel filter

Fuel pump & fuel sender assembly

01-16

3. IGNITION SYSTEM

Ignition coil

Ignition plug

Engine ECU

Knock sensor

Camshaft position

sensor

Crankshaft position

sensor

01-17

0000-00

Electronic throttle body

4. INTAKE SYSTEM

Air cleaner element

VIS valve

VIS solenoid valve

Intake manifold assembly

T-MAP sensor
