1A2 -- 2 GENERAL ENGINE INFORMATION
DAEWOO MY_2000
SPECIFICATIONS
ENGINE SPECIFICATIONS
Application
E23 Engine
E20 Engine
Engine Model
M161.970
M161.940
Displacement (CC)
2295
1998
Cylinder (Bore x Stroke) (mm)
90.9 x 88.4
89.9 x 78.7
Fuel Injection / Ignition System
MSE 3.53S
←
Compression Ratio
10.4:1
9.6:1
Number of Cylinders
4
←
Camshaft Valve Arrangement
DOHC
←
Camshaft Drive Type
Chain--Driven
←
Max. Output (ps/rpm)
149 / 5500
135 / 5500
Max. Torque (kgSm/rpm)
22.4 / 4000
19.3 / 4000
Firing Order
1--3--4--2
←
Ignition Type
Distributorless
←
Ignition Timing
BTDC 6° ± 2°
←
Valve
Ti i
Intake
Open/Close
ATDC 19.25° / ABDC 28.76°
ATDC 13.15° / ABDC 13.57°
Timing
Exhaust
Open/Close
BBDC 20.62° / BTDC 15.08°
BBDC 16.58° / BTDC 17.05°
Valve Clearance Adjustment
Automatic Control
←
Idle Speed (rpm)
750 ± 50
←
Fuel Injection Pressure (kg/cm@)
3.2 -- 4.2
←
Oil Capacity (liter)
7.5
←
Lubrication Type
Forced by Gear Pump
←
Oil Filter Type
Full Flow with Paper Filter
←
Fuel
Unleaded Gasoline
←
MSE 3.62S/3.53S (Motorsteuer Elektronik : German)
MSE : Engine Control Electronic
3.62S : 6 cylinder version
3.53S : 4 cylinder version
