1B1 -- 2 M162 ENGINE MECHANICAL
DAEWOO MY_2000
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application
NSm
Lb-Ft
Lb-In
Fuel Feed and Return Line
21 -- 25
15 -- 18
--
Exhaust Manifold and Pipe
30
22
--
Propeller Shaft to Transmission
81 -- 89
60 -- 66
--
Engine Mounting Nuts
70
52
--
Generator Carrier Bolts
25
18
--
Tensioning Pulley Bolt
40.5 -- 49.5
29.9 -- 36.5
--
Steering Pump Bolts
22.5 -- 27.5
16.6 -- 20.3
--
A/C Bracket Bolts
22.5 -- 27.5
16.6 -- 20.3
--
Intake Air Duct Mounting Nuts
9 -- 11
--
80 -- 97
Spark Plug Cover Bolts
9 -- 11
--
80 -- 97
Cylinder Head Cover Bolts
9 -- 11
--
80 -- 97
Magnetic Assembly Bolt
9 -- 11
--
80 -- 97
Cylinder Head Front Cover Bolt
22.5 -- 27.5
16.6 -- 20.3
--
Cylinder Head Bolts
55
+90°
+90°
41
+90°
+90°
--
Timing Gear Case Cover Bolts
M8
22.5 -- 27.5
16.6 -- 20.3
--
g
M6
9 -- 11
--
80 -- 97
Crankshaft Sealing Rear Cover Mounting Bolts
9 -- 11
--
80 -- 97
Vibration Damper Center Bolt
200 + 20
+90° + 10°
148 + 15
+90° + 10°
--
Connecting Rod Bearing Cap Bolts
40
+90°
30
+90°
--
Flywheel Mounting Bolt
45 + 5
+90° + 10°
33 + 3.7
+90° + 10°
--
Amarture Bolt
35
26
--
Camshaft Adjuster Flange Bolts
18 -- 22
60° ± 5°
13 -- 16
60° ± 5°
--
Intake Flange Shaft Bolts
18 -- 22
60° ± 5°
13 -- 16
60° ± 5°
--
Exhaust Camshaft Sprocket Bolts
18 -- 22
60° ± 5°
13 -- 16
60° ± 5°
--
Camshaft Bearing Cap Bolts
22.5 -- 27.5
16.6 -- 20.3
--
Chain Tensioner Screw Plug
40
30
--
Chain Tensioner Assembly
72 -- 88
53 -- 65
--
Oil Pump Sprocket Bolt
29 -- 35
21 -- 26
--
Tensioning Device Bolts
26 -- 32
19 -- 24
--
Water Pump Pulley Bolts
22.5 -- 27.5
16.6 -- 20.3
--
Upper Intake Manifold Bolt
22.5 -- 27.5
16.6 -- 20.3
--
Lower Intake Mainfold Bolt
22.5 -- 27.5
16.6 -- 20.3
--
Flange Bolt to Exhaust Mainfold
30
22
--
