SsangYong Actyon Sports II. Manual - part 45

12-9

8510-23

3) Decelerating with the Cruise Control System

(1) While the cruise control system is running

Push down the DECEL switch of the cruise control lever and hold it until the desired speed is reached

without a brake pedal intervention. But the cruise control system cannot maintain the cruise function at

less than 34 km/h.

When the desired speed is reached, release the lever.

1.

2.

(2) When the cruise control system is not running

To decrease the vehicle speed with the cruise control system when the system is not running, follow the

procedures below.

Push down the cruise control switch lever to DECEL side and hold it until the desired speed is

reached while the vehicle speed is over 36 km/h.

And then release the accelerator pedal slowly.

When the desired speed is reached, release the lever. But the cruise control system cannot maintain

the cruise function at less than 34 km/h.

1.

2.

3.

(3) Tap-down while the cruise control system is running

To decrease the vehicle speed in stages while the cruise control system is running, follow the

procedures below.

Push down the DECEL switch of the cruise control lever less than 0.5 second per one switching while

the cruise control system is running. This is a tap-down switching. When you operate a tap-down

switching, the vehicle is decelerated for 1.0 km/h below the previous set speed.

If you want to decelerate for 10 km/h, operate the tap-down switching ten times without the brake pedal

intervention.

1.

2.

12-10

4) Recovery of Set Speed (RESUME)

Even if the cruise control is cancelled, the previous set cruise speed can be recovered by pulling up the

cruise control lever when the current vehicle speed is over 36 km/h without an acceleration intervention.

But if you turn off the ignition switch, the memorized set speed is cleared and you cannot recover the

previous set speed.

But the driver should know the previous set speed to react to the changed vehicle speed properly. If the

vehicle speed increases abruptly, depress the brake pedal to adjust the vehicle speed properly.

12-11

8510-23

5) Normal Cancellation of the Cruise Control

The cruise control system will be canceled when one or more items of the following conditions are

applied;

When the brake pedal is depressed or When ESP is activated.

When the cruising speed is downed less than 34 km/h

When applying the parking brake during driving.

When using the clutch in order to shift (M/T only).

1.

2.

3.

4.

Keep the main cruise control switch in the neutral position when not using the cruise control.

12-12

Do not move the shift lever to Neutral position while driving with the cruise control turned on.

Otherwise, it may result in system malfunction or accidents.

Always be prepared to use the brake or accelerator pedal for safe driving while the cruise control

system is running.

The actual speed can be different from the set speed momentarily when driving on a uphill or

downhill. So, it is recommended to disable the cruise control function on a uphill or downhill. hen

driving on a steep hill use the engine brake and foot brake properly to protect the vehicle system

and for a safe driving.

Ensure that the safe distance is maintained and use the brake pedal if needed.

1.

2.

3.

4.

(1) Abnormal Cancellation of the Cruise Control

When the rapid deceleration is applied without braking.

When the rapid acceleration is applied without acceleration pedal intervention.

When the cruise control lever is faulty.

When the brake switch and the brake light switch input signal are implausible.

1.

2.

3.

When the cruise control function is cancelled abnormally or intermittent problems occur, stop the vehicle

and turn off the ignition switch and remove the key to reset the system. After a while, turn on the ignition

switch again to operate the cruise control system.
