1F1-26 M162 ENGINE CONTROLS
IDLING CONTROL AND ELECTRONIC PEDAL SYSTEM TEST
⇒
2.1
•
Ignition:ON
50
51
2.25 - 2.75 V
•••••
Pedal valve
sensor:
- Power
supply
(potentiometer 2)
•
Cable
•
ECU
Failure
code
Item
⇒
1.0
Checking method
•
Ignition:ON
•
Position of
accelerator pedal:
- Closed throttle
position
- Full throttle with kick
down
Test
step
Requirement
Specified
value
Possible cause
31
47
0.3 - 0.7 V
•••••
Pedal valve
sensor:
- Signal
(potentiometer 1)
160,
161,
164,
167,
4.3 - 4.8 V
•
⇒
1.1
•
Cable
•
Pedal valve sensor
⇒
1.1
•
Ignition:ON
31
32
4.75 - 5.25 V
•••••
Pedal valve
sensor:
- Power
supply
(potentiometer 1)
•
Cable
•
ECU
⇒
2.0
•
Ignition:ON
•
Position of
accelerator pedal:
- Closed throttle
position
- Full throttle with kick
down
50
48
0.1 - 0.4 V
•••••
Pedal valve
sensor:
- Signal
(potentiometer 2)
162,
163,
164,
167,
2.1 - 2.5 V
•
⇒
2.1
•
Cable
•
Pedal valve sensor
⇒
3.0
•
Engine:in idling
84
87
0.3 - 0.9 V
•••••
Throttle
valve
actuator:
- Signal
Throttle valve
potentiometer 1
104,
105,
108,
109,
116,
119,
185,
4.0 - 4.6 V
•
⇒
3.1
•
Cable
•
E-GAS actuator
•
Position of
accelerator pedal:
- Closed throttle
position
- Full throttle with kick
down
