Infotainment system

it is possible to tune into a station with traffic
information.

If no station with traffic information can be
tuned in, the device automatically searches
for stations with tunable traffic information.

Stations with traffic information are not avail-
able in all countries.

Activating and deactivating the TP func-
tion

In Radio mode or Multimedia mode, press

Settings > Traffic station (TP)

.

Online radio

Online radio is a type of reception for Internet
radio stations and podcasts that are inde-
pendent of AM, FM and DAB. Thanks to Inter-

net transmission, reception is not limited to
the region.

Online radio is only available through the In-
ternet connection of the active infotainment
system. The use of online radio can generate
expenses due to the transmission of data
from the Internet.

In Online radio mode, press and set the au-

dio quality to high or low to tune the online ra-
dio.

Station logos

In the case of some frequency bands, station
logos may already be pre-installed in the in-
fotainment system.

If in the FM/DAB frequency band settings the

automatic selection of station logos

 is ac-

tivated, station logos are automatically as-
signed to the stations.

In the Online radio mode, the infotainment
system accesses the station logos of the on-
line database and automatically assigns
them to the stations

Assign station logos manually

In FM/DAB mode, press

Station logos

.

Press on the

 icon and then select the

station to which a station logo is to be as-
signed.

Select the station logo. If desired, repeat

the same process with other stations.

OR

, via the menu

Settings > Station logos

.

172

Infotainment operation

Media Mode

Introduction

Fig. 124

Schematic representation: Multimedia

view

In Media mode you can play multimedia files
from data media and streaming services
through the infotainment system.

Depending on the equipment, the following
data media can be used:

USB storage support (for example, a USB

stick, a mobile phone connected via USB).

Bluetooth® device (for example, a mobile

phone or a tablet).

Depending on the equipment, the following
types of multimedia files can be played:

Audio files.

Video files (depends on the system).

You can also use streaming services. The
availability of streaming services depends on
the equipment and the country.

To use streaming services you need to have
your own user account in the streaming serv-
ice in question.

Access the MEDIA menu

Press

HOME >



›››

Fig. 124

.

Access the settings

Press

HOME >

 >

.

Limitations and indications of data media

Data media may not work if they have been
exposed to high temperatures or have been
damaged. Please bear in mind the manufac-
turer’s indications.

Quality differences between data media pro-
duced by different manufacturers can cause
multimedia playback malfunctions.

Incorrect configuration on a data media may
cause the data media to be unreadable.

Playlists only specify a playback order and
refer to the storage location of the multime-
dia files within the folder structure. In a

»

173

Infotainment system

playlist there are no multimedia files saved.
To play a playlist, multimedia files have to be
found in the storage places of the data media
to which the playlist refers.

Note

SEAT assumes no liability for any deteriora-
tion or loss of files on data storage devices.

Features of the multimedia equip-
ment and symbols

Audio, multimedia and connectivity:

Multimedia playback and control via Blue-

tooth®.

Audio playback in these formats: AAC,

ALAC, AVI, FLAC, MP3, MP4, WMA.

Video playback in these formats: MPEG-1

and MPEG-2 (.mpg, .mpeg), ISO MPEG4, DivX
3, 4 and 5 Xvid (.avi), ISO MPEG4 H.264
(.mp4, .m4v, .mov), Windows Media Video 10
(.wmv, .asf).

Playlists on any type of device.

Multimedia streaming (online).

Multimedia search.

Universal symbols in Media mode

To start playback.
To pause playback.

To change to the previous title.
To change to the next title.
Repeat the current track.
Repeat all titles.
To activate the shuffle playback order.
To display the favourites list.
Add multimedia file as favourite.
Top right: Select multimedia source.
Access the settings.
Open the search.
To return to the top folder of the multi-
media source.

Select and play a multimedia
source

Select multimedia source

Before playing multimedia files you must first
connect a multimedia source.

To use streaming services you must be con-
nected to the Internet.

Connect an external multimedia source.

Select the connected media source to be

used for playback.

Playing audio and video files

You can search and play multimedia files
from an available multimedia source in differ-
ent ways.

Search in the folder structure

Multimedia files can be catalogued by cate-
gories (for example, album, artist, title). In

My

media

 this category view is always dis-

played. The classic folder structure of individ-
ual USB data media is also found in

My me-

dia

.

Activate the folder structure.
The folder structure of the selected mul-
timedia source is displayed. When

My

media

 is selected, the categories (mu-

sic, videos, playlists) and connected
multimedia sources are displayed first.
Search for the title you want in the folder
structure.

OR:

 press

 to start the text search. The

input field is displayed.
Enter the name of the desired title. The
list of the titles found is updated while
entering the text.
Press the desired title.
If at the beginning of the playback your
selection is in a folder of a multimedia
source, the multimedia files that are in it
are also added to the playback.

1.

2.

3.

4.

174

Infotainment operation

If a playlist is played, all available titles
in the playlist are added to the play-
back.
Close your selection with

.

Select favourites

In favourites you can save titles, music gen-
res, artists and albums individually for play-
back.

Access favourites

.

Press the favourite you want.

Depending on your selection, all the titles be-
longing to the favourite are added to the
playback.

Configure streaming services

Depending on the equipment you can use
streaming services directly through the info-
tainment system. For this you need to have a
premium user account of the streaming serv-
ice in question and you have to log in with it in
the infotainment system. You also need to be
connected to the Internet.

Select

 Streaming

 as the multimedia

source.
A list of available streaming services is
displayed.

5.

1.

Select the streaming service you want.
Follow the steps indicated by the info-
tainment system.
The streaming service is added to the list
of multimedia sources as a new function
button.

Save favourites

Only multimedia files in

My media

 of the info-

tainment system can be saved as favourites.
You can save up to a maximum of 30 titles, al-
bums, artists and music genres individually as
favourites.

Start playback.
Access favourites.
Tap a favourite that is not assigned.

OR:

 press on an existing favourite and

old for approx. 3 seconds.
Select from the selection list: Title, Al-
bum, Artist, Music genres, Playlist.

The selection is saved instead of the previ-
ously selected favourite. If the favourite was
already assigned, the previously saved fa-
vourite is overwritten.

The selectable options in the selection list
depend on the data attached to the multime-

2.
3.

1.
2.
3.

4.

dia file. If the music genre is not indicated in
the music files, for example, you cannot save
the music genre as favourite.

If a video file is playing, only that video can
be saved as favourite.

Playing entertainment content in
the infotainment system

Depending on the infotainment system, vid-
eos can be played.

Video mode

When in video mode, a video can be played
on the infotainment screen if this is stored on
a data media, in

My media

 or is sourced from

a streaming service. In this case, the video
sound is played through the vehicle's speak-
ers.

The image is only displayed if the vehicle is
stopped. When the vehicle is in motion, the in-
fotainment screen turns off. The sound of the
video can still be heard.

A stable Internet connection is required for
playback from a streaming service. In this
case, telephony costs may be generated.

175

Infotainment system

Navigation

Introduction

Fig. 125

Schematic representation: Navigation

view

A global satellite system determines the cur-
rent position of the vehicle and the sensors
mounted on the vehicle analyse the routes
taken. All measured values and possible traf-
fic events are compared with the available
maps to allow optimal navigation to the des-
tination.

Navigation announcements and graphic rep-
resentations will guide you to your destina-
tion.

Navigation management is carried out on the
screen.

Depending on the country, some functions of
the infotainment system will not be available

on the screen when travelling above a certain
speed. It is not a malfunction, but is due to
compliance with legislation.

Navigation announcements

Navigation announcements are acoustic indi-
cations for driving referred to the current
route.

The type and frequency of navigation an-
nouncements depend on the driving situation,
for example, starting the guide to the destina-
tion, driving on the motorway or on a round-
about and the settings.

If the exact destination cannot be reached
because, for example, it is in a non-digitised
area, indications relating to the address and
the distance to the destination are displayed
on the screen.

During dynamic route guidance, you will re-
ceive information about reported traffic con-
gestion on the route. An additional navigation
announcement is provided if the route is re-
calculated due to traffic congestion.

While a navigation announcement is playing,
its volume can be adjusted. The following
navigation announcements provided will be
played with the newly adjusted volume.

176

Infotainment operation

Limitations during navigation

If the infotainment system cannot receive da-
ta from GPS satellites, for example, in a tunnel
or in an underground garage, navigation con-
tinues using the vehicle's sensors.

In areas that are not digitised or are only par-
tially digitised on the infotainment memory,
the infotainment system will still attempt to
provide route guidance.

In the case of missing or incomplete naviga-
tion data, it may not be possible to determine
the exact position of the vehicle. This may
mean that navigation is not as precise as usu-
al.

Roads and streets are subject to constant
change (e.g. new roads, road works, roads
closed to traffic, changes to street names
and building numbers). If the navigation data
is obsolete, this may lead to errors or inaccur-
acies during the route guidance.

Managing the navigation map

To allow an optimal view, you can also man-
age the navigation map with additional finger
movements.

Move the map



(tip: use your index finger).

Move the map with your finger.

Zoom in the view



(tip: use your index finger).

To increase the view in a certain position,

double-click on the map.

Zoom out the view



(tip: use your index and

middle fingers).

Press on the map with both fingers at the

same time.

Change view



(tip: use your index finger).

Press twice on the map and keep your fin-

ger pressed on the screen.

To zoom out the view of the map, move your

finger upwards. To zoom in the view of the
map, move your finger downwards.

Change view



(tip: use your index and middle

fingers).

Press on the map with both fingers at the

same time and keep them pressed.

To zoom out the view of the map, move one

finger towards the other. To zoom in the view
of the map, move one finger away from the
other.

Tilt the view



(tip: use your index and middle

fingers).

Press on the map with both fingers at the

same time and horizontal to each other, keep
them pressed.

To tilt the view of the map forward, move

your fingers upwards. To tilt the view of the
map backward, move your fingers down-
wards.

Rotate view



(tip: use your index and middle

fingers).

Press on the map with both fingers at the

same time and keep them pressed.

To rotate the map view, turn your fingers

clockwise anticlockwise.

Saved data

The infotainment system saves certain data,
for example, frequent routes and position da-
ta, to make the entry of the destination more
agile and optimise the route guidance.

Delete saved data

Press

Settings > Basic function settings >

Delete

 and then

OK

WARNING

Select the settings, enter the destination
and the modifications for navigation only
with the vehicle at a standstill.

Note

If a detour is passed during route guid-

ance, navigation may recalculate the
route.

The quality of the navigation recommen-

dations given by the Infotainment system
depends on the navigation data available
and any reported traffic congestions.

»

177

Infotainment system

Navigation announcements are not emit-

ted if the sound is muted in the infotainment
system.

Navigation functions and symbols

Navigation

Navigation functions depend on the equip-
ment and country.

Functions

Entering destination and route calculation

(offline and online).

Displaying two navigation maps at the

same time (display and instrument cluster).

Update of online maps.

Predictive navigation.

3D urban maps.

Online traffic information

Dynamic POIs (points of interest)

Symbols on the map

The buttons and indications depend on the
settings and the current driving situation.

Symbols for traffic events and points of inter-
est (POIs) are displayed on the map, for ex-
ample, petrol stations, train stations or inter-
esting stopovers, provided navigation has
such data

›››

page 181

.

Current position
Search for destinations.
Destinations along the route.
Final destination
Home address
Work address
Favourite destinations
Additional window with more options.
Additional window with route options.
Centre the map on the current position.
Change view: 2D oriented to the north,
or 2D oriented to the direction of travel,
or 3D to the direction of travel.
Information about the current route
guidance.
Map scale.

Symbols in the additional window

To open the additional window, press

.

Repeat the last navigation announce-
ment.
Volume of navigation announcements.
Map lighting in Automatic, Day or Night
mode.
Offer new guidance routes.

Other symbols

Entering the detailed destination for an
address.
Search for destinations.
Frequent destinations.
Last destinations.
Favourite destinations
Back

Symbols in the route details

Current position.
Destination of the current guidance.

POI symbols (points of interest)

POIs (points of interest) are shown on the
map, provided the navigation has said data.

Click on the desired POI (point of interest) to
start a route guidance

›››

page 179

.

Petrol station.
Parking lot.
Tourist information offices.
Train station.
Restaurant.

Traffic information.

POIs (points of interest) are shown on the
map, provided the navigation has said data

›››

page 181

.

178

Infotainment operation

Click on a traffic event to open an additional
window with further details

›››

page 181

.

Slow traffic.

Traffic jam.

Accident.

Broken down vehicle.

Slippery surface (ice or snow).

Road closed to traffic.

Slippery road hazard.

Danger.

Road works.

Strong wind.

Reduced visibility.

Navigation data

The Infotainment system is equipped with a
built-in navigation data memory. Depending
on the country, the necessary navigation da-
ta may already be pre-installed.

To provide correct route guidance and make
the most of the functions offered, the infotain-
ment system should be updated on a regular
basis.

Using obsolete data may lead to errors dur-
ing navigation. Current routes cannot be
traced or the route guidances will lead to
mistaken destinations.

Ensure navigation data is updated at all
times.

Online updating of navigation data

The navigation data of the regions through
which you travel frequently is automatically
updated in the background if the Internet
connection is established and the privacy
settings are valid.

With the ignition switched on, the naviga-

tion data is updated automatically.

Manual update of navigation data

Current navigation data for large regions, for
example Western Europe, can be downloa-
ded from www.seat.com and stored on USB
data devices. Navigation through USB data
devices is not possible.

Download the navigation data to a USB da-

ta device.

Turn on the ignition of the vehicle.

Connect the USB data device to the info-

tainment system. Navigation data is automat-
ically updated in the background.

The map version is displayed in

HOME >

 >

System information

.

WARNING

If you update the navigation data manually
while driving, it may cause accidents with
serious injuries.

Update the navigation data only with the

vehicle at a standstill.

Note

Automatic update of the navigation data is
subject to the privacy settings. In “Incogni-
to” mode, no update is carried out.

Start route guidance

Depending on the country and equipment,
different functions are available to enter des-
tinations.

The different functions for entering destina-
tions are found in the navigation main menu.

Opening the Navigation main menu

Press

HOME >

.

Select the destination and start naviga-
tion

Press

.

Select the desired destination. You can
chose from



Frequent destinations

Last destinations

 and



Favourite

destinations

.

»

1.
2.

179

Infotainment system

OR:

 press

 and enter the address in

the input screen.

OR:

 detailed address.

Press

Start

.

 Frequent destinations

The destination synopsis uses recorded data
to propose possible destinations.

Select the destination and start naviga-
tion

Press

 and then

.

Select the desired destination. The route
guidance starts automatically.

Quick start:

 for a quick start, press and hold

the desired destination for a few seconds.

 Last destinations

Navigation saves the last destinations to
make them available for a route guidance.

Select the destination and start naviga-
tion

Press

 and then

.

Press the desired destination.
Press

Start

.

Quick start:

 for a quick start, press and hold

the desired destination for a few seconds.

3.

1.
2.

1.
2.
3.

 Favourite destinations

Save up to 20 destinations as favourites.

To save a destination as a favourite press

in the split screen when entering the destina-
tion.

Select the destination and start naviga-
tion

Press

 and then

.

Press the desired destination.
Press

Start

.

Note

Enter the destination as accurately as pos-
sible. If you enter a destination incorrectly,
the route guidance will not be able to start
or it will guide you to an incorrect destina-
tion.

Start route guidance by selecting
from the map

The navigation map includes active areas at
many points that are suitable for entering the
destination. To do this, press the desired posi-
tion or place on the map. If there is map data
at this point, you can start a route guidance.

Whether it is possible to enter the destination
through the navigation map depends on the

1.
2.
3.

state of the data and it is not possible for all
positions.

To start “offroad navigation”, press an empty
area without position data.

Start navigation

Press

.

Move the view on the map until the desired

position can be selected. The navigation map
can be used by means of additional finger
movements

›››

page 177

.

Press the desired destination on the map.

Press

Route

.

Offroad navigation

“Offroad navigation” calculates routes to se-
lected destination points using unknown da-
ta. When a destination point is outside the
known roads or position data, navigation
finds the route to the next point of the known
road and completes the path to the next des-
tination point with a direct connection.

Start navigation

Move the view on the map until the desired

position can be selected. The navigation map
can be used by means of additional finger
movements

›››

page 177

.

Press on any point on the map without posi-

tion data.

Press

Route

.

180

Infotainment operation

Start route guidance using contact
details

Start route guidance with the saved address
data of a contact. Contacts saved without
address data cannot be used for route guid-
ance.

Start navigation

Press

.

Press on the contact you want.

Press

Route

.

Note

If the address details of a contact are ob-
solete, the route guidance will nevertheless
take you to the registered address. Check
that the contact address is updated.

Traffic information

The infotainment system receives detailed
traffic information automatically if the Inter-
net connection is established. This informa-
tion is shown with symbols and highlighting
the road network in colour on the map.

Traffic incidents

Traffic incidents, for example, traffic jams or
congested traffic, are shown on the naviga-
tion map using symbols.

With an active route guidance, traffic inci-
dents that are on the current route are shown
in the route details. Such traffic incidents can
be avoided

›››

page 181

.

Hazard information

Hazard information is shown on the naviga-
tion map with symbols in the same way as
traffic incidents. In this case, the source of this
information is another vehicle that has detec-
ted the hazard and has uploaded the infor-
mation to the service provider.

The hazards shown are: accident, broken
down vehicle and slippery road surface.

Traffic flow indication

The navigation map shows traffic flow ac-
cording to current traffic events, highlighting
the road network in colour.

Orange:

 Slow traffic.

Red:

 Traffic jam.

Note

Traffic information receipt is subject to the
privacy settings. In maximum Privacy
mode, no traffic information is received.
Tracking or Location level setting is neces-
sary.

Function descriptions

Route details

The route details contain information on all
incidents, for example, the starting point,
stopovers, traffic events, POIs and destina-
tion, provided the navigation has such data.

If you press on an incident, an additional win-
dow opens providing more options. The avail-
able options depend on the incident and the
current settings.

Open and close the route details

To open, press

|

 or swipe it.

To close, press

|

 or swipe it.

Edit route guidance

To edit route guidance, move the stopovers to
the destination in the TripView view.

Hold the desired destination pressed until it

is visibly highlighted.

Move the destination to the desired posi-

tion.

Remove your finger from the screen. The

route will recalculate.

Avoid traffic incidents

The details of the route show the current traf-
fic incidents if the navigation has such data.

»

181

Infotainment system

Avoid traffic incidents by editing route details

›››

page 181

.

Press on a traffic event.

Press on

Avoid

. The route will recalculate.

Split screen

When handling navigation functions, an addi-
tional window with other options may open.
Possible options depend on the function be-
ing used.

Close the additional screen

Press on an empty area outside the addi-

tional window.

OR:

 press

.

OR:

 press

Accept

.

Functions in the additional window:

Show on map

Show what is selected on the
map.

Add stopover

Add a stopover to the route guid-
ance.

Direct route

Starts direct route guidance.

Functions in the additional window:

Delete

Delete a stopover from the route
guidance.

Avoid

Avoid traffic jam. The route will re-
calculate.

Stopping route
guidance

Ends the current route guidance.

Close the additional window.

Add a destination to favourites.

Learn usage pattern

When the vehicle is in motion, navigation
saves routes and destinations used to auto-
matically generate destination proposals.
Destinations are learned based on the time of
day and the day of the week.

Navigation can propose up to 5 routes at the
same time. The proposed routes may be dif-
ferent from the routes of the normal route
guidance.

If one of the proposed destinations is selec-
ted, the guide to that destination is started.

The route guidance follows the selected route
until the vehicle deviates from it. In that case,
the route is recalculated and takes you back
along the most direct path to the initially se-
lected destination.

Important traffic jams are taken into account
in the route guidance, and are avoided if al-
ternative routes are available, provided navi-
gation has such data.

You can activate and deactivate the function
whenever you want.

Enable and disable learning usage pattern

The setting is in the corresponding navigation
menu

 > Basic function settings

.

To activate the function, activate

Learn us-

age pattern

.

To disable the function, disable

Learn us-

age pattern

.

To delete saved data, press

Delete usage

pattern

.

182

Infotainment operation

Telephone interface

Introduction

Fig. 126

Schematic representation: Phone view

You can use the telephone interface to con-
nect your mobile to the infotainment system
and operate phone functions through it. The
sound is played through the vehicle's speak-
ers.

You can connect up to two mobile phone de-
vices simultaneously to the infotainment sys-
tem.

High speeds, poor weather or road conditions
and a noisy ambience (even outside of the
vehicle), as well as the quality of reception
can all affect the quality of a telephone con-
versation in the vehicle.

Note

As a general rule, pairing a device (for ex-

ample, a mobile phone device) is only nec-
essary once. You can restore the device
connection via Bluetooth® or Wi-Fi with the
infotainment system whenever you want
without having to pair the device again.

The availability of some telephone func-

tions will depend on the mobile phone con-
nected to the infotainment system.

Telephone interface equipment and
symbols

Equipment features

Hands-free function.

Use up to two phones at the same time.

Phone book with up to 5,000 contacts, de-

pending on the infotainment system.

SMS functions via Bluetooth®: SMS reading,

SMS writing (templates included), SMS play-
back, message history.

Email functions via Bluetooth®: reading

email, writing email.

»

183

Infotainment system

Connection to wireless charging option.

Connection to the microphone mounted on

the vehicle.

Symbols in the main menu

Contacts.
List of incoming and outgoing calls.
Enter telephone number.
Text messages (SMS and emails).
Telephone interface settings.

Symbols for calls

The symbols may be different depending on
the infotainment system.

Start a call or bringing it to the fore-
ground.
End or reject a call.
Open contact list.
Enter telephone number.
Mute the sound of the hands-free
Hold call.
Continue call.
Start conference call.
Pass call to private mode
Make an emergency call.
Get help in case of breakdown.

Obtain information on the SEAT brand
and selected additional services related
to traffic and your travel.
Voice mail.

Call list symbols

To open the call lists, press

.

Incoming call.
Outgoing call.
Missed call.
Telephone number (company).
Telephone number (private).
Mobile telephone number (company).

Mobile telephone number (private).
Fax (private).
Fax.

Symbols for text messages

The symbols may be different depending on
the infotainment system.

To open the text messages, press

.

Activate voice control input

›››

page 167

.

Templates for text messages.

Places with special regulations

Switch off the mobile telephone and the tele-
phone interface in places with a risk of explo-
sion. These places are not always clearly
marked. They include, for example:

The vicinity of chemical pipelines and

tanks.

The lower decks of boats and ferries.

In the proximity of vehicles that run on liq-

uefied gas (such as propane or butane).

Places where the air is laden with chemi-

cals or particles such as flour, dust or metal
powder.

All other places where the vehicle engine or

telephone must be switched off.

WARNING

Switch off the mobile phone in areas with a
risk of explosion!

Note

In areas where special regulations apply or
the use of mobile phones is forbidden, it
must be switched off at all times. The radi-
ation produced by the mobile phone when
switched on may interfere with sensitive
technical and medical equipment, possibly
resulting in malfunction or damage to the
equipment.

184

Infotainment operation

Pair, connect and manage

Requirement for pairing:

Bluetooth® is activated on the mobile

phone device.

Bluetooth® is activated on the infotainment

system.

Depending on the mobile device, it will be

necessary to have the Bluetooth® menu open
or activate the

Visibility

 option so that the

device is visible from the infotainment system.

Pair a mobile phone device suitable for tel-
ephony with the infotainment system to use
the telephone interface functions. On the first
connection, the mobile phone device is
paired with the infotainment system. Doing so
saves a user profile

›››

page 185

.

The pairing can take a few minutes. The func-
tions available depend on the mobile phone
device used and its operating system.

Pair a mobile phone device

Open the list of available Bluetooth® devi-

ces on the mobile phone device and select
the name of the infotainment system.

Please note and, if necessary, confirm the

messages that appear on the mobile phone
device and on the infotainment system. If the
pairing was successful, the phone data is
saved in the user profile.

Optional:

 confirm the data transfer mes-

sage on the mobile phone device.

Active and passive connection

To use the functions of the telephone inter-
face, there must be at least one mobile
phone device

connected

 to the infotainment

system. If there are several mobile phone de-
vices connected to the infotainment system,
you can switch between active and passive
connections. To use the telephone interface
with the desired mobile phone device, estab-
lish the active connection with the infotain-
ment system.

Difference between connection types

Primary

The mobile phone device is paired and
connected. The functions of the tele-
phone interface are performed with the
data of said mobile phone device.

Secon-

dary

The mobile phone device is paired and
connected. Calls can be managed but

the phone book, messages or other

functions will not be active.

Paired mobile phone devices are stored in the
infotainment system, even if they are not cur-
rently connected.

Connect a mobile phone device

Requirement: the mobile phone device is
paired with the infotainment system.

Bluetooth® is activated on the mobile

phone device.

Establish an active connection

Requirement: several mobile phone devices
are connected to the infotainment system at
the same time.

Select the desired mobile phone device

from the drop-down menu. All other mobile
phone devices are automatically in the pas-
sive connection.

User profiles

For each of the paired mobile phone devices
an individual user profile is automatically cre-
ated. In the user profile, data from the mobile
phone device is stored, for example, contact
details or settings. A maximum of four user
profiles can be saved in the infotainment sys-
tem at the same time.

WARNING

If you perform the pairing while driving, it
could cause an accident or injury.

Perform pairing only with the vehicle at a

standstill.

»

185

Infotainment system

Note

In the pairing of some mobile phone devi-

ces, a PIN number is shown on the screen of
the mobile phone device. Enter that number
in the infotainment system to complete the
pairing.

While the infotainment system is in the

Known mobile phones menu, the wireless
charging function is disabled. When you
exit this menu, the wireless charging func-
tion is activated again.

Basic and Comfort Telephony

Depending on the equipment, two types of
telephone interface can be used:

Basic telephone interface.

Comfort telephone interface.

Basic telephone interface

The Basic telephone interface uses the Blue-
tooth® HFP profile for transmission. This inter-
face allows the use of telephone functions
through the infotainment system and play-
back through the vehicle's speakers.

Comfort telephone interface

Like the Basic telephone interface, the Com-
fort telephone interface also uses the Blue-
tooth® HFP profile.

The Comfort phone interface can be equip-
ped with the wireless charging function

›››

page 187

.

In order to use the functions of the wireless
charging function, you have to place a suita-
ble mobile phone device correctly in the stor-
age compartment. The mobile phone device
will then connect to the vehicle antenna. This
improves the reception and sound quality of
calls.

To call

Open the telephone interface

Press

HOME >

.

Make a call

Select a phone number to start a call. Differ-
ent functions are available for selecting a
phone number:

 Contacts

If a contact has several registered phone
numbers you have to select one.

Press

 and press a number on the list to

start the call.

OR:

 press

 and enter the contact name in

the input field to search for it. Press on the
contact to start the call.

OR:

 press a favourite in the telephone inter-

face main menu to start the call.

 Calls

The telephone interface shows the call list of
the mobile telephone device. Start a call from
the call list.

Press

 > All

 and press a number on the list

to start the call.

OR:

 press

 and filter the call list entries

(for example, missed calls or dialled num-
bers). In filtered list, press a number to start
the call.

 Dial

Manually enter a phone number to start a
call. While entering the phone number, con-
tacts that match that number are shown on
the infotainment screen.

Press

 and enter telephone number.

Press

 to start the call

The last call is dialled by pressing and hold-
ing the

 button on the multifunction steering

wheel.

Send messages

Depending on the mobile phone device and
the infotainment system used, you can send

186

Infotainment operation

and receive SMS and e-mails through the tel-
ephone interface.

Send an SMS

Press

 > Text message > Enter new

message

 and enter the message on the

screen.

Enter the contact you want in the search

bar.

To send the message press

OK

.

Send an e-mail

Press

 > E-mail > Enter new message

and enter the message on the screen.

Enter the contact you want in the search

bar.

To send the message press

OK

.

Phone book, favourites and speed
dial buttons

In the first connection of a telephone with the
infotainment system, the phone book is saved
in the infotainment system. It may be neces-
sary to confirm the data transmission on the
mobile phone.

Each time the phone is reconnected, the
phone book is updated.

If conference calls are supported, the phone
book can be accessed during a call. If there
is a saved image for a contact, it can be dis-
played in the list next to the entry.

Favourites

A speed dial button can be assigned to a
maximum of 5 or 6 favourites from the phone
book (depending on the equipment). If there
is a registered photo saved to the contact, it is
shown on the speed dial button.

All speed dial buttons have to be manually
edited and will be assigned to a user profile.

Assign the speed dial button

In the

Favourites

 menu, press the

 button,

then open the phone book to select a con-
tact as a favourite. If the contact has several
phone numbers, press on the number in the
list.

Edit the speed dial button

To edit or delete a favourite contact press

on the icon

 in the

Favourites

 menu screen.

You can delete one or more favourites.

Call a favourite

Press the assigned speed dial button.

Note

Favourites are not updated automatically.
If you change a contact's phone number,
you have to reassign the speed dial button.

Connectivity Box

Fig. 127

In the centre console: pad for the mo-

bile phone connection.

The Connectivity Box includes the

Wireless

Charger

 functionality.

»

187















Content      ..     9      10      11      12     ..
