LANE DEPARTURE WARNING (3/4)
Temporarily not available
Adjustment
- very fast lane departure;
With the vehicle stationary, engine run-
- driving continuously on a line;
ning, from the multimedia screen 4
- four seconds approximately after
select the “Settings” menu, “Vehicle”
4
changing lanes;
tab, the
“Driving assistance” menu,
- tight bends;
then “Lane”:
- impaired visibility;
- “Vibration”: adjust the steering wheel
- activation of one of the direction indi-
vibration level;
cator lights;
- hard acceleration etc.
- “Alert”: adjust the sensitivity level for
line detection. To do this, select:
When the function is not available, the
- “Late”: line detected when cross-
ing;
warning light and the left/right in-
- “Standard”: line detected on ap-
dicators turn to grey on the instrument
proach;
panel.
- “Early”: line detected nearby.
Operating faults
Please refer to the multimedia instruc-
Conditions for non-activation
tions for further information.
In the event of a malfunction, the left
of the system
and right line indicators (and, depend-
The system cannot be activated when:
ing on display style, the
warning
- reverse gear is engaged;
light) disappear or stay grey on the in-
- the field of vision of the camera is ob-
strument panel.
structed;
In some cases, they are accompanied
- the® warning light is displayed.
by the “Front camera to check” mes-
The
warning light and the left/
right line indicators turn to grey on the
instrument panel.
instrument panel.
Consult an approved dealer.
2.37
LANE DEPARTURE WARNING (4/4)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate
the function, then consult an authorised dealer.
- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried
out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
Some conditions can disturb or damage the operation of the system, such as:
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, hail, black ice, rain, etc.);
- poor visibility (night, fog etc.);
- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface);
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding or undulating (tight bends etc.);
- closely following a vehicle travelling in the same lane.
Risk of false alarms or absence of warnings
2.38
LANE KEEPING ASSIST (1/5)
Note: make sure the windscreen is not
obscured (dirt, mud, snow, condensa-
1
tion etc.).
Using information from the 1 camera,
the function triggers corrective action
on the vehicle steering system when
a continuous or broken line is crossed
or when approaching the roadside (di-
vider, barrier, pavement, embankment,
etc.) without the direction indicator
lights being activated.
This function is an addi-
tional driving aid. This func-
tion is not under any circum-
stances intended to replace
the due care and attention of the
driver, who should at all times be
in control of the vehicle.
You can retake control of the ve-
hicle at any time by operating the
steering wheel.
2.39
LANE KEEPING ASSIST (2/5)
To disable the function, press the 2
switch as many times as required to
select “Lane Keeping deactivated” on
the instrument panel.
goes out on the in-
Warning light
strument panel.
Note: deactivating the “Lane Keeping
Assist” function causes deactivation of
the “Lane Departure Warning” function.
2
Activation/deactivation
To activate the function, press the 2
switch as many times as required to
select “Lane Keeping Assist” on the in-
strument panel.
The “Lane Keeping activated” message
and “
” warning light are displayed
on the instrument panel.
When Lane Keeping Assist is activated,
the “Lane Departure Warning” function
is automatically activated. ➥ 2.35.
Each time the vehicle is started,
the function continues the mode
saved the last time the engine was
stopped.
2.40
LANE KEEPING ASSIST (3/5)
In these cases:
Special case
– the function triggers an action on the
If the system no longer detects any
vehicle’s steering system to correct
action by the driver on the steering
the vehicle trajectory;
wheel, the
warning light illumi-
nates in yellow on the instrument panel,
- the warning light
and the indi-
accompanied by the message: “Keep
cator 3 on the side of the breached
3
hands on steering wheel” and a beep.
line turns to yellow on the instrument
panel.
The beep sounds together with the
warning light and the message until the
Note: on bends, the function allows for
driver takes control.
slightly cutting the bend.
If the corrective action on the steer-
ing system is not sufficient, the
warning light and 3 indicator on the side
Operation
of the breached line turn to red on the
When the function is activated, the
instrument panel, accompanied by a vi-
bration on the steering wheel.
warning light and the left and
right lines 3 are displayed in grey on the
instrument panel.
The function is set to operate when
the vehicle speed is between approxi-
mately 43 mph (70 km/h) and 112 mph
(180 km/h) and if the
warning
light and 3 correction indicators are col-
oured white.
The function operates if the vehicle
breaches a line or if the vehicle ap-
proaches the roadside (divider, barrier,
You can interrupt the trajectory cor-
pavement, embankment, etc.) without
rection at any time by moving the
the direction indicator lights being ac-
steering wheel.
tivated.
2.41
LANE KEEPING ASSIST (4/5)
Temporarily not available
Adjustment
With the vehicle stationary, engine run-
- Very fast lane departure;
ning, from the multimedia screen 4
- driving continuously on a line;
4
select the “Settings” menu, “Vehicle”
tab, the
“Driving assistance” menu,
- four seconds approximately after
then “Lane”:
changing lanes;
- “Vibration”: adjust steering wheel
- tight bends;
vibration for the
“Lane Departure
- impaired visibility;
Warning” function;
- “Alert”: adjust the sensitivity level for
- activation of one of the direction indi-
line detection. To do this, select:
cator lights;
- “Late”: line detected when cross-
- strong acceleration;
ing;
- “Standard”: line detected on ap-
- emergency braking;
proach;
- ...
- “Early”: line detected nearby.
Conditions for non-activation
Please refer to the multimedia instruc-
If the function is unavailable, the
of the system
tions for further information.
warning light and the left/right correc-
The system cannot be activated when:
tion warning lights 3 appear in grey on
- reverse gear is engaged;
the instrument panel.
Operating faults
- the field of vision of the camera is ob-
structed;
When the system detects an operating
- the® warning light is displayed.
fault, the
warning light lights up
on the instrument panel, with the mes-
The
warning light and the left/
sage “Front camera to check”.
right line warning lights are displayed in
Consult an approved dealer.
grey on the instrument panel.
2.42
LANE KEEPING ASSIST (5/5)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate
the function and consult an authorised dealer.
- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried
out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
Some conditions can disturb or damage the operation of the system, such as:
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, hail, black ice, rain, etc.);
- poor visibility (night, fog etc.);
- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface);
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding or undulating (tight bends etc.);
- closely following a vehicle travelling in the same lane.
In this case, the “Lane Keeping Assist” may react incorrectly or not at all.
Risk of unwanted, incorrect correction or no correction of trajectory.
Deactivating the function
You must disable the function if:
- the area of the camera has been damaged (on the windscreen side or the interior rear-view mirror side);
- the road is slippery (snow, black ice, aquaplaning, gravel etc.) ;
- poor visibility (night, fog etc.);
- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an Authorised
Dealer);
- the vehicle is towing a trailer or a caravan;
- the vehicle is entering an area with several surface markings (an area with road works etc.).
2.43
BLIND SPOT WARNING (1/5)
1
A
A
This function is an addi-
tional aid which indicates
other vehicles in the blind
spot area.
This system alerts the driver to other
Special feature
It can never in any case be a sub-
vehicles in the detection zone A.
Make sure that the sensors are not ob-
stitute for care nor for the driver’s
The system is activated when the ve-
scured (by dirt, mud, snow, etc.).
responsibility while in charge of his
hicle’s speed is between approximately
If a sensor is obscured, the message
vehicle.
19 mph
(30 km/h) and
87 mph
“Blind spotclean sensor” will appear on
The driver should always be ready
(140 km/h).
the instrument panel. Clean the sen-
for sudden incidents while driv-
This function uses sensors 1 installed in
sors.
ing: always ensure that there are
the front and rear bumper of both sides.
no moving obstacles (such as a
child, animal, pushchair or bicy-
cle) or small, narrow objects such
as stones or posts in the blind spot
when manoeuvring.
2.44
BLIND SPOT WARNING (2/5)
3
B
2
3
4
C
D
Activation/deactivation
Indicator 3
Operation
Vehicle stationary, engine running, from
An indicator light 3 is located on each
This function gives a warning:
the multimedia screen 2, select the
rear view mirror 4.
- when the vehicle speed is between
“Settings” menu, “Vehicle” tab, select
Note: clean the rear view mirrors 4 reg-
approximately 19 mph (30 km/h) and
the “Driving assistance” menu, “Blind
ularly so that the indicator lights 3 can
87 mph (140 km/h);
spot alert”, then select ON or OFF.
be seen properly.
- when another vehicle is in the blind
spot area and travelling in the same
direction as your vehicle.
If another vehicle is being overtaken,
the indicator 3 will be activated only if
that vehicle remains in the blind spot for
more than one second.
The system’s detection range oper-
ates according to a standard lane
width. If you are driving in narrow
traffic lanes, it may detect vehicles
in other lanes.
2.45
BLIND SPOT WARNING (3/5)
Display B
Operating faults
3
The function is activated and has not
If the system detects a fault, the mes-
B
detected any vehicles.
sage “Check blind spot alert” is dis-
played on the instrument panel. Call an
approved Dealer.
Display C
First warning: the indicator 3 means
C
that a vehicle has been detected in the
blind spot.
Display D
D
When the direction indicator is acti-
vated, the indicator light 3 flashes when
a vehicle is detected in the blind spot on
The system’s detection
the side towards which you are about to
Conditions for non-function
range operates according
steer. If you cancel the direction indica-
to a standard lane width. If
tor, the function will return to the initial
- If the object is not moving;
you are driving in wide traf-
warning (display C).
- if traffic is heavy;
fic lanes, the system might not be
- the road is winding;
able to detect a vehicle in the blind
spot.
- if front and rear sensors both detect
an object at the same time (e.g.
The system might be disrupted mo-
when passing an articulated lorry).
mentarily if it is exposed to strong
electromagnetic waves (as beneath
– ...
high-tension power lines) or to very
poor weather conditions
(heavy
rain, snow etc.). Remain aware of
Because sensors have
driving conditions.
been installed in the bump-
ers, any work (repairs, re-
There is a risk of accidents.
placements, touching up of
paintwork) must be carried out by a
qualified professional.
2.46
BLIND SPOT WARNING (4/5)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.
System servicing/repairs
- In the event of an impact, the alignment of the sensors may be changed and its operation may consequently be affected.
Deactivate the function and consult an authorised dealer.
- Any work in the area where the sensors are located (repairs, replacements, etc.) must be carried out by a qualified profes-
sional.
Only an authorised dealer is qualified to service the system.
System disturbance
Some conditions can disturb or damage the operation of the system, such as:
- complex surroundings (metal bridges, tunnels, roads with barriers at the edge, etc.);
- poor weather conditions (snow, hail, black ice, etc.).
Risk of false alarms or absence of warnings
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
2.47
BLIND SPOT WARNING (5/5)
Limitation of the system operation
- The sensors must be kept clean and free of modifications in order for the system to operate correctly.
- Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the
system.
- When the vehicle enters corners and curves, the system may temporarily cease to detect vehicles in adjacent lanes.
- The system may not react when there is a significant difference in speed with other vehicles.
- If the vehicle is being overtaken by a long vehicle (e.g. heavy goods vehicle overtaking at a similar speed to the vehicle) the
system may interrupt the warning before the end of the manoeuvre.
- The vehicle is travelling on a winding road.
Deactivating the function
You must disable the function if:
- the sensors have been damaged (rear bumper);
- the vehicle is fitted with a towbar that is not recognised by the system.
2.48
DETECTION OF ROAD SIGNS (1/4)
Note: make sure the windscreen is not
For vehicles equipped with a navigation
1
obscured (dirt, mud, snow, condensa-
system and if the vehicle is travelling in
tion etc.).
a country where the speed units differ
from those of the vehicle, the system
For vehicles which are equipped with it,
displays the speed limit sign in the unit
the system also uses information from
of the country, alongside the speed limit
the navigation system.
converted to the unit used by the vehi-
Once the speed limiter is activated, you
cle’s instrument panel.
can adjust the speed limiter indication
For countries where the speed limit is
displayed by the system.
reduced during rainy weather on some
If the limit speed is exceeded, the dis-
types of roads, on vehicles equipped
play panel is modified to warn the driver.
with a navigation system, the system
can modify the limited speed after a few
seconds of wiping the windscreen.
Special situations
The system detects speed limit signs
The system does not take into account
on the side of the road and displays the
exceptional speed limit measures, such
speed limit on the instrument panel.
as peak pollution days.
It mainly uses information taken from
the camera 1, attached to the wind-
screen behind the rear view mirror.
2.49
DETECTION OF ROAD SIGNS (2/4)
- press the 4 or 5 control repeatedly to
reach the “Settings” menu. Press the
switch 6 OK;
- press the 4 or 5 control repeatedly to
2
reach the “DRIVING ASSIST” menu.
Press the switch 6 OK;
- press the 4 or 5 control repeatedly
to reach the “Speed alert” menu and
press the 6 OK switch;
- press the 6 OK switch to activate or
3
deactivate the function:
4
=
function activated
6
5
function deactivated
<
Activating/deactivating the
With the function activated, depend-
ing on local regulations, you can acti-
system
vate the “Risk area display” option. The
Vehicles fitted with a multimedia
system will notify you of the distance
screen.
separating you from this zone, and
while you are travelling in the zone.
Vehicle stationary, engine running,
from the multimedia screen 2 select
Vehicles not fitted with a multimedia
the “Settings” menu, “Vehicle” tab, the
screen
“Driving assistance” menu,
“Traffic
- With the vehicle stationary, press
signs”, then select “ON” or “OFF”.
switch 3, as many times as required
to reach the “Vehicle” tab;
2.50
DETECTION OF ROAD SIGNS (3/4)
If the speed limit is exceeded, the circle
around the panel flashes (7 warning
light) along with a sound signal to warn
the driver.
7
8
9
10
Operation
Varying the limit speed
If the speed limit notification differs from
Warning lights
the detected speed value, press and
The function displays the following
hold the following switches:
warning lights:
- 9 (RES/+) to increase the notification
7 Speed limit road signs
speed to the detected speed;
8 Additional road signs (start or end
- 10 (SET/-) to reduce the notification
of “No overtaking” zone, slip road
speed to the detected speed.
speed limit, speed in case of a cara-
van, speed limit with length of appli-
cation, etc.)
2.51
DETECTION OF ROAD SIGNS (4/4)
Operating faults
The system cannot detect the speed
limit if:
- the windscreen is not clean;
- the camera is blinded by the sun;
- there is insufficient visibility (night,
fog etc.);
- the signs are not legible (snow, etc.)
or are hidden (by another vehicle or
by trees);
- the information taken from the navi-
gation system is not up to date.
This function is an additional driving aid. This function is not under any
circumstances intended to replace the due care and attention of the
driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, re-
gardless of the system indications.
The system detects speed limit signs and does not detect other signs (e.g. entry/
exit to/from urban areas, etc.).
The system may not detect all speed limit signs or may interpret them incorrectly.
The driver should not ignore signs that are not detected by the system and should,
as a priority, comply with the traffic signage and the highway code.
In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system
may not indicate the correct speed to the driver.
The driver should always adapt their speed to the traffic conditions, regardless of
the system indications.
2.52
SPEED LIMITER (1/4)
Controls
Driving
1 Speed limiter On/Off switch.
When a limit speed has been set but
not yet reached, driving is similar to
2 Cruise control On/Off switch.
driving a vehicle without the speed lim-
3 Switch to activate and decrease the
iter function.
limit speed (SET/-).
Once you have reached the stored
4 Switch to activate and increase the
speed, no effort on the accelera-
5
limit speed or to set the stored limit
tor pedal will allow you to exceed
1
speed (RES/+).
the programmed speed except in an
4
5 Speed limiter function standby (with
emergency (refer to information on
limited speed memory) (0).
“Exceeding the limit speed”).
3
2
The speed limiter function helps you
stay within the driving speed limit that
you choose, known as the limit speed.
You can link the speed limiter to
the “Road sign detection” function.
➥ 2.49.
2.53
SPEED LIMITER (2/4)
6
1
4
3
Switching on
To store the current speed, press the 4
switch (RES/+) or the 3 switch (SET/- ):
Press switch 1. The 6 warning light ap-
the limit speed replaces the dashes
pears in grey. The “Speed limiter ON”
and, depending on the vehicle, the 6
message appears on the instrument
warning light appears in white.
panel accompanied by dashes to indi-
The minimum stored speed is 20 mph
cate that the speed limiter function is in
(30 km/h).
operation, waiting to store a limit speed.
2.54
SPEED LIMITER (3/4)
Exceeding the limit speed
Limited speed cannot be maintained
It is possible to exceed the limit speed
When driving down a steep gradient,
at any time. To do this: press the accel-
the system may not maintain the limit
erator pedal firmly and fully (beyond
speed: the limit speed flashes in red
the resistance point).
on the instrument panel and an audi-
ble signal sounds at regular intervals to
While the speed is being exceeded, the
inform you of this situation.
speed limiter flashes red on the instru-
ment panel. Then, release the accelera-
tor pedal: the speed limiter function will
4
return as soon as you reach a speed
lower than the memorised speed.
3
Varying the limit speed
The limit speed may be changed by
pressing repeatedly or holding down:
- switch 4 (RES/+) to increase speed;
- switch 3 (SET/-) to reduce speed.
If the speed limiter is not
available (after several at-
The speed limiter function is
tempts to activate), contact
in no way linked to the brak-
an approved dealer.
ing system.
2.55
SPEED LIMITER (4/4)
6
Switching off the function
The speed limiter function is inter-
rupted:
- when you press the 1 switch. In this
case, the speed is no longer stored;
- when you press the 2 switch. In this
case the cruise control is selected
5
and there is no stored speed.
1
4
The warning light 6 disappears from
the instrument panel to confirm that the
function is no longer active.
3
2
Putting the function on
standby
The speed limiter function is suspended
when you press switch 5 (0). The limit
speed is stored and displayed in grey
on the instrument panel.
Recalling the limit speed
If a speed has been stored, it can be re-
called by pressing the 4 switch.
When the speed limiter is set to
standby, pressing the 3 switch re-
activates the function without taking
into account the memorised speed:
the speed at which the vehicle is
moving is taken into account.
2.56
CRUISE CONTROL (1/5)
Controls
1
Cruise control On/Off switch.
2
Switch to activate and decrease
cruising speed (SET/-).
3
Switch to activate and increase
cruising speed or to recall the mem-
orised cruising speed (RES/+).
4
5
4
Switch the function to standby (with
3
cruising speed saved) (0).
This function is an addi-
5
Speed limiter On/Off switch.
tional driving aid. The func-
tion does not take the place
2
1
of the driver.
Therefore, it can under no circum-
The cruise control function helps you to
stances replace the driver’s respon-
maintain your driving speed at a speed
sibility to respect speed limits and to
that you choose, called the cruising
be vigilant (the driver must always
speed.
be ready to brake).
This cruising speed may be set at any
Cruise control must not be used in
speed above 19 mph (30 km/h).
heavy traffic, on undulating or slip-
pery roads (black ice, aquaplan-
ing, gravel) and during bad weather
(fog, rain, side winds etc.).
There is a risk of accidents.
2.57















Content      ..     6      7      8      9     ..
