BATTERY: troubleshooting (2/3)
Starting the vehicle using the
battery from another vehicle
If you have to use the battery from an-
other vehicle to start, obtain suitable
jump leads (with a large cross section)
2
A
from an approved dealer or, if you al-
ready have jump leads, ensure that
they are in perfect condition.
The two batteries must have an iden-
tical nominal voltage: 12 volts. The
battery supplying the current should
have a capacity (amp-hours, Ah) which
is at least the same as that of the dis-
1
charged battery.
Ensure that there is no risk of contact
Battery in engine compartment
between the two vehicles (risk of short
circuiting when the positive terminals
The battery is not directly accessible.
are connected) and that the discharged
Use the terminal 1 ( + ) and the termi-
battery is properly connected. Switch
nal 2 ( - ) in the engine compartment.
off your vehicle ignition.
Raise the cover A of the terminal 1 (+).
Start the engine of the vehicle supply-
ing the current and run it at an interme-
diate engine speed.
With the engine running, the message
“Battery charging” appears on the in-
strument panel for approximately five
minutes.
5.27
BATTERY: troubleshooting (3/3)
2
1
B
A
4
3
Attach the positive cable A to the termi-
nal 1 ( + ) then to the terminal 4 ( + ) of
the battery supplying the current.
Connect the negative cable B to the
terminal 3 ( - ) of the battery supply-
ing the current and then to the termi-
nal 2 ( - ).
Start the engine, and as soon as it
Check that there is no con-
starts running, disconnect the cables A
tact between leads A and B
and B in reverse order ( 2 - 3 - 4 - 1).
and that the positive lead A
is not touching any metal
parts on the vehicle supplying the
current.
Risk of injury and/or damage to
the vehicle.
5.28
FITTING A RADIO
1
2
-
In all cases, it is very important to
follow the manufacturer’s instruc-
tions carefully.
-
The specifications of the brack-
Radio location 1
Front door speakers 2
ets and wires (available from our
Unclip the blanking cover. The connec-
To install any equipment, please con-
network) vary depending on the
tions: ( + aerial) and ( - supply and
sult an authorised dealer.
equipment level of your vehicle
speaker) are located behind it.
and the type of radio.
Consult an approved Dealer to
find out the correct part number.
-
No work may be carried out on
the vehicle’s electrical or radio
circuits, except by approved
dealers: an incorrectly connected
system may result in damage
being caused to the electrical
equipment and/or the compo-
nents connected to it.
5.29
ACCESSORIES
Electrical and electronic accessories
Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po-
sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer.
Before connecting an accessory to a socket, please ensure that you do not exceed the maximum power authorised for
the socket. ➥ 3.33, ➥ 3.17. Fire hazard.
No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected
system may result in damage being caused to the electrical equipment and/or the components connected to it.
If the vehicle is fitted with any aftermarket electrical equipment, make sure that the installation is correctly protected by a fuse.
Establish the rating and position of this fuse.
Using the diagnostic socket
The use of electronic accessories on the diagnostic socket may cause serious disturbance to the vehicle’s electronic systems.
For your safety we recommend that you use only electronic accessories approved by the manufacturer, consult an Approved
Dealer. Serious accident risk.
Use of transmitting/receiving devices (telephones, CB equipment etc.).
Telephones and CB equipment with integrated aerials may cause interference to the electronic systems originally fitted to the
vehicle: it is advisable only to use equipment with an external aerial. Furthermore, we remind you of the need to conform
to the legislation in force concerning the use of such equipment.
Fitting aftermarket accessories
If you wish to install accessories on the vehicle: please contact an authorised dealer. Also, to ensure the correct operation of
your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for your
vehicle, which are the only accessories for which the manufacturer will provide a warranty.
If you are using an anti-theft device, only attach it to the brake pedal.
Obstructions to the driver
On the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regu-
larly. Do not lay one mat on top of another. There is a risk of wedging the pedals.
5.30
FUSES (1/3)
1
3
B
A
2
Fuse box
Fuses located in the passenger
Tweezers 3
compartment behind a flap in the B
If any electrical component does not
Remove the fuse using the tweezers 3
glovebox
work, check the condition of the fuses.
on the back of the flap.
Unclip the access flap 2.
To remove the fuse from the tweezers,
Passenger compartment fuses A
slide the fuse to the side.
Unclip the access flap 1.
It is not advisable to use the free fuse
locations.
Check the fuse in question and replace it, if necessary, by a fuse of the
same rating.
To comply with current legislation, or
If a fuse is fitted with too high a rating, it may cause the electrical circuit
as a precaution, you can obtain an
to overheat (risk of fire) in the event of an item of equipment using an ex-
emergency kit from your approved
cessive amount of current.
dealer containing a set of spare
bulbs and fuses.
5.31
FUSES (2/3)
Allocation of fuses
(the presence of certain fuse depends on the vehicle equipment level)
Symbol
Allocation
H
Windscreen washer
Multimedia accessories socket, multimedia
î
screen
Æ
Front and rear second row accessories socket
Ì
Horn
Ý
Towbar socket
Heated rear view mirrors
Use the fuse allocation label in the
×
Brake lights, passenger compartment central unit
storage compartment to identify the
fuses.
Passenger compartment centre unit, rear wiper,
Certain fuses should only be re-
rear fog light
placed by a qualified professional.
These fuses are not listed on the
label.
Direction indicator lights, hazard warning lights,
D
high level brake lights
Only change the fuses represented
on the label.
5.32
FUSES (3/3)
4
C
Fuses in engine compartment C
4 fuse: LPG circuit shut-off.
Please note when work-
Some functions are protected by fuses
ing close to the engine that
located in the engine compartment
it may be hot. In addition,
(unit C).
the engine cooling fan may
However, because of their reduced
start at any moment. The
accessibility, we advise you to have
warning light in the engine compart-
your fuses replaced by an approved
ment reminds you of this.
Dealer.
Risk of injury.
Before carrying out any
action in the engine com-
partment, you must switch
off the ignition.
➥ 2.4 or
➥ 2.6.
5.33
WIPER BLADES: replacement (1/2)
A
1
B
2
3
4
Replacing the windscreen
To refit
wiper blades 2
To refit the wiper blade 2, insert it in its
To replace the wipers, first put them in
housing in the arm 3, then clip it until
the service positionB.
you hear a click. Make sure that the
Engine running or ignition on;
blade is correctly locked in position.
- set the stalk 1 to position A twice in
To return the blades to lowered posi-
succession (single sweep): the wiper
Check the condition of the wiper
tion, make sure that the blades are
blades will stop in the service posi-
blades. You are responsible for their
folded down onto the windscreen then
tion B away from the bonnet;
service life:
set the 1 stalk to position A (single
- lift the wiper arm 3;
- clean the blades, windscreen and
sweep): the windscreen wiper blades
- lower the 4 tab then remove the
rear screen regularly with soapy
will fold into the bonnet when the igni-
blade 2.
water;
tion is switched on.
- do not use them when the wind-
screen or rear screen are dry;
- free them from the windscreen or
rear screen when they have not
been used for a long time.
5.34
WIPER BLADES: replacement (2/2)
To refit
To refit the wiper blade, proceed in re-
verse order to removal. Make sure that
5
the blade is correctly locked in position.
C
6
– In frosty weather, make
sure that the wiper blades
are not stuck by ice
(to
avoid the risk of the motor
overheating).
- Check the condition of the wiper
blades. Replace the wiper blades
Rear screen wiper blade 5
as soon as they begin to lose ef-
Stalk in stop position (deactivated):
ficiency
(approximately once a
- lift the wiper arm 6;
year).
- turn the blade horizontally 5 (move-
When changing the blade, when it
ment C) until it unclips;
has been removed, do not let the
Check the condition of the wiper
- remove the blade by pulling it.
wiper arm fall against the window:
blades.
risk of breaking the window.
- clean the blades, windscreen and
rear screen regularly with soapy
water;
- do not use them when the wind-
screen or rear screen are dry;
Before changing the rear
wiper blade, make sure the
- free them from the windscreen or
stalk is in the stop position
rear screen when they have not
(deactivated).
been used for a long time.
Risk of injury.
5.35
TOWING: breakdown recovery (1/2)
Before carrying out any towing, posi-
The speed specified by current legis-
tion the gearbox in neutral position (po-
lation for towing must always be ob-
sition N on vehicles equipped with an
served. If you are driving the towing
automatic gearbox), unlock the steering
vehicle, do not exceed the permissible
column then release the parking brake.
towing weight for your vehicle. ➥ 6.9.
1
Steering column unlocking
Towing a vehicle with an
Insert the key into the ignition, set to
automatic transmission,
“On” ON 2 position or, depending on
the vehicle, with the card in the pas-
mechanical lever
2
senger compartment, press the engine
Transport the vehicle on a trailer or tow
start button for approximately two sec-
it with the front wheels off the ground.
onds.
In exceptional circumstances, you
Reposition the lever to neutral (position
may tow it with all four wheels on the
N for vehicles fitted with an automatic
ground, only in a forward gear, with the
gearbox).
gearbox in neutral position N, over a
When setting off, if the lever is locked in
The steering column unlocks, the ac-
maximum distance of 50 miles (80 km)
position P even though you are press-
cessory functions are powered: you
and not exceeding a speed of 16 mph
ing the brake pedal, the lever can be re-
can use the vehicle’s lights (direction
(25 km/h).
leased manually in order to unlock the
indicators, brake lights, etc.). At night
drive wheels.
the vehicle must have its lights on.
To do this, unclip the base of the gaiter
Depending on the vehicle, once you
and press the 2 button while simultane-
have finished towing, press the engine
ously pressing the 1 button on the lever
start button twice (risk of running down
to unlock the lever.
the battery).
Contact an authorised dealer as soon
as possible.
Leave the card in the vehi-
cle during towing.
Risk of the steering
column locking.
5.36
TOWING: breakdown recovery (2/2)
Tighten the towing hitch 5 fully: first
by hand until it stops, then finish by
locking it with the wheel brace or, de-
D
B
pending on the vehicle, the lever.
Only use the towing hitch 5 and the
4
6
wheelbrace or lever provided with the
tools. ➥ 5.7.
A
C
7
3
- Use a rigid towing bar.
If a rope or cable is used
5
(where the law allows this),
5
the vehicle being towed
Only use the front 3 and rear 7 towing
Access to towing points
must be able to brake.
points (never use the driveshafts or any
-
A vehicle must not be towed if it is
other part of the vehicle). These towing
Front towing point
not fit to be driven.
points may only be used for pulling.
Press zone A and keep depressed
-
Avoid accelerating or braking
They must never be used for lifting the
while pulling zone B to open flap 4.
suddenly when towing, as this
vehicle directly or indirectly.
may result in damage being
Rear towing point
caused to the vehicle.
Press zone C and keep depressed
-
In all cases, it is advisable not to
while pulling zone D to open flap 6.
exceed 15.5 mph (25 km/h).
When the engine is
Ensure that the towing eye
Do not leave the tools unse-
stopped, steering and brak-
is bolted correctly.
cured inside the vehicle as
ing assistance are not oper-
they may come loose under
Risk of losing the towed
ational.
braking.
object.
5.37
OPERATING FAULTS (1/7)
Using the card
POSSIBLE CAUSES
WHAT TO DO
The card does not lock or unlock the
Card battery is flat.
Replace the battery. You will still be able to
doors.
lock/unlock and start your vehicle. ➥ 1.16
and ➥ 2.4 or ➥ 2.6.
Use of appliances operating on the
Stop using the devices or use the key pro-
same frequency as the card (mobile
vided. ➥ 1.16.
phone, etc.).
Vehicle located in an area with strong
Use the key that is built into the card
electromagnetic radiation. Vehicle
➥ 1.16.
battery discharged.
The message “Place card on zone +
Place the card in the placement area
START” appears on the instrument
➥ 2.6 then press the START button.
panel.
The vehicle is started.
With the engine running, the card’s locking/
unlocking device is blocked. Turn off the ig-
nition.
Desynchronisation of the card
Unlock the driver’s door by inserting the
key integrated in the card into the door lock
➥ 1.16 then place the card in the placement
area ➥ 2.6 and press the START button to
synchronise the card.
5.38
OPERATING FAULTS (2/7)
The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact
an approved dealer as soon as possible.
Using the remote control
POSSIBLE CAUSES
ACTION REQUIRED
The remote control does not lock or The remote control battery is flat.
Use the emergency key.
unlock the doors.
Use of appliances operating on the same
Stop using the devices or use the key.
frequency as the remote control (mobile
phone, etc.).
Vehicle located in a high electromagnetic
Replace the battery. You will still be able to
radiation zone.
lock/unlock and start your vehicle. ➥ 1.16
Discharged battery.
and ➥ 2.4 or ➥ 2.6.
The vehicle is started.
With the engine running, the key’s locking/
unlocking device is blocked. Turn off the
ignition.
Desynchronisation of the remote control
Unlock the driver’s door by inserting the
key into the door lock ➥ 1.16, then start the
engine to synchronise the remote control
➥ 2.4 or ➥ 2.6.
5.39
OPERATING FAULTS (3/7)
The starter is activated
POSSIBLE CAUSES
ACTION REQUIRED
The instrument panel indicator lights are
Battery terminals not tight, bat-
Retighten or reconnect the terminals, or clean them if
weak or fail to light up and the starter
tery terminals disconnected or
they are oxidised.
does not turn.
oxidised.
Discharged battery or not op- Connect another battery to the faulty battery. ➥ 5.26 or
erational.
replace the battery if necessary.
Do not push the vehicle if the steering column is
locked.
Faulty circuit.
Consult an approved dealer.
The engine will not start.
Starting conditions are not ful- ➥ 2.4 or ➥ 2.6.
filled.
The “hands-free” card does not Place the card in the recess provided for this purpose
work.
on the centre console ➥ 2.4 or ➥ 2.6.
With the vehicle stationary, engine cold, Petrol version, this is not nec-
The engine’s idle speed should decrease after about
the engine’s idle speed is high.
essarily a fault. This may be
one minute. Otherwise, this may be caused by an-
caused by the increase in the
other fault. Call an approved Dealer.
engine temperature.
The engine cannot be switched off.
Card not detected.
Place the card in the recess provided for this purpose
on the centre console.
Press and hold the start button.
Electronic fault.
Press the start button 3 times quickly or press and
hold.
The steering column remains locked. Steering wheel locked.
Move the steering wheel while pressing the engine
start button (or, depending on the vehicle, operating
the ignition key) ➥ 2.4.
Faulty electrical circuit.
Consult an approved dealer.
5.40
OPERATING FAULTS (4/7)
On the road
POSSIBLE CAUSES
WHAT TO DO
Vibrations.
Tyres not inflated to correct pres-
Check the tyre pressures: if this is not the
sures, incorrectly balanced or dam-
problem, have them checked by an ap-
aged.
proved Dealer.
White smoke from the exhaust.
In the diesel version, this is not neces-
➥ 2.22.
sarily a fault. Smoke may be caused
by particle filter regeneration.
Petrol version, this is not necessarily
Reduce the engine speed and avoid
a fault. Depending on the climate con-
sudden acceleration to gradually make the
ditions (cold, humidity etc.), smoke
smoke disappear. Otherwise, this may be
may be produced under hard vehicle
caused by another fault. Consult an ap-
acceleration.
proved dealer.
Smoke under the bonnet.
Short-circuit or cooling system leak.
Stop, switch off the ignition, stand away
from the vehicle and contact an approved
dealer.
The oil pressure warning light comes
on:
while cornering or braking.
The level is too low.
Top up the engine oil ➥ 4.5.
is slow to go out or remains lit up
Loss of oil pressure.
Stop the vehicle and contact an approved
under acceleration.
Dealer.
5.41
OPERATING FAULTS (5/7)
On the road
POSSIBLE CAUSES
WHAT TO DO
Steering becomes heavy.
Assistance overheating.
Drive carefully at reduced speed, be aware
of the level of force in the steering wheel
needed to turn the wheels.
Fault with the electric assistance
Consult an authorised dealer.
motor.
Fault in the assistance system
The engine is overheating. The
Engine cooling fan not working.
Stop the vehicle, switch off the engine and
coolant temperature indicator is in
contact an approved dealer.
the warning zone and warning light
®
comes on.
Coolant leaks.
Check the coolant reservoir: it should con-
tain fluid. If there is no coolant, consult an
authorised dealer as soon as possible.
Coolant boiling in the coolant reser-
Mechanical fault: damaged cylinder
Stop the engine.
voir.
head gasket.
Contact an approved dealer.
Radiator: In the event of a significant lack of coolant, remember that you must never top up using cold coolant while
the engine is very hot. After any procedure on the vehicle which has involved even partial draining of the cooling
system, it must be refilled with a new mixture prepared in the correct proportions. Reminder: only products approved
by our Technical Department may be used for this purpose.
5.42
OPERATING FAULTS (6/7)
Electrical equipment
POSSIBLE CAUSES
WHAT TO DO
The wipers do not work.
Wiper blades stuck.
Free the blades before using the wipers.
Faulty electrical circuit.
Consult an approved dealer.
Fuse damaged.
Replace the fuse or have it replaced
➥ 5.31.
The wiper does not stop.
Faulty electrical controls.
Consult an approved dealer.
Direction indicators flashing more
Blown rear bulb.
➥ 5.16.
quickly.
The direction indicators do not work.
Faulty electrical circuit or control.
Consult an approved dealer.
Fuse damaged.
Replace the fuse or have it replaced
➥ 5.31.
The lights do not come on or go off.
Faulty electrical circuit or control.
Consult an approved dealer.
Fuse damaged.
Replace the fuse or have it replaced
➥ 5.31.
5.43
OPERATING FAULTS (7/7)
Electrical equipment
POSSIBLE CAUSES
WHAT TO DO
Traces of condensation in the head-
Traces of condensation may be a nat-
lights or rear lights.
ural phenomenon caused by varia-
tions in temperature and humidity.
In this case, the traces will disappear
slowly once the lights are switched
on.
The front seat belt reminder light
An object is stuck between the floor
Remove all objects from underneath the
comes on when the seat belts are
and the seat and is disrupting the op-
front seats.
fastened.
eration of the sensor.
5.44
Section 6: Technical Specifications
Vehicle identification plate
6.2
Technical Information for the emergency services
6.3
Engine identification
6.4
Dimensions
6.5
Engine specifications
6.6
Weights
6.9
Towing weights
6.9
Replacement parts and repairs
6.10
Service sheets
6.11
Anticorrosion check
6.17
6.1
VEHICLE IDENTIFICATION PLATES
A
1
2
3
4
5
A
10
6
9
7
8
The information shown on the ve-
4
MAM
(Maximum Authorised
hicle identification plate should be
Mass).
quoted on all correspondence or
5
GTW (Gross train weight: vehicle
orders.
fully loaded, with trailer).
6
MPAW (Maximim Permissible
The presence and location of the in-
Weight) for front axle.
formation depends on the vehicle.
7
MPAW on rear axle.
8
Reserved for related or additional
Vehicle identification plate A
entries.
1
Manufacturer name.
9
Not used.
2
EC design number or approval
10
Paint reference (colour code).
number.
3
Identification number.
B
Depending on the vehicle, this
information is also given on
markingB.
6.2
TECHNICAL INFORMATION FOR THE EMERGENCY SERVICES
A
A
The QR Code on the A label allows
emergency workers using a tablet or
smartphone to immediately access the
technical information useful for working
on the vehicle in the event of an acci-
dent.
Ensure that the A label is always visible
and present on the windscreen as well
as the rear screen.
Any modification or damage would
prevent access to the information.
6.3
ENGINE IDENTIFICATION
A
1
2
3
A
A
Please quote the engine identifica-
tion information in area A in all cor-
respondence or orders.
(Location varies depending on engine)
1
Engine type.
2
Engine suffix.
3
Engine serial number.
A
A
6.4















Content      ..     15      16      17      18     ..
