Renault Scenic (2018 year). Instruction - part 6





1.82

ON-BOARD COMPUTER: trip settings

(3/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with mileage-

before-service message

d) Mileage before service or oil change.

Mileage before service

With the ignition switched on, the engine not running and

the display set to “SERVICE INTERVALS”, press button OK  for

approximately 5 seconds to display the mileage before service

(distance or time to the next service). When the distance value

approaches its limit, there are several possible scenarios:

–

range less than 930 miles (1,500 km) or one month: the

message “Service due in” is displayed accompanied by the

nearest term (distance or time);

–

range equal to 0 miles (0 km) or date of service reached:

the message “Service required” is displayed accompanied by
the warning light

©

.

The vehicle requires a service as soon as possible.

SERVICE

INTERVALS

Service in

30 000 Kms / 12 mo

Service due in

300 Kms / 24 days

Service required

Resetting: to reset the distance before service, press and hold button 2 for approximately 10 seconds until the display shows

the mileage permanently.
NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.83

TRIP COMPUTER: trip settings

(4/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with distance before

next service message (cntd.)

d) Mileage before service or oil change.

Mileage before service

With the ignition on, the engine not running and the display

selected “SERVICE INTERVALS”, press button OK for about

5 seconds to display the mileage before the next service, then

press button 2 to view the mileage before the next oil change

(distance or time remaining before the next service). When the

distance value approaches its limit, there are several possible

scenarios:

–

range less than 930 miles (1,500 km) or one month: the

message “Service due in” is displayed accompanied by the

nearest term (distance or time);

–

range equal to 0 miles (0 km) or date of oil change reached:

the message “Service required” is displayed accompanied by
the warning light

©

.

The vehicle requires an oil change as soon as possible.

SERVICE

INTERVALS

Oil change in

30 000 Kms / 24 mo

Service due in

300 Kms / 24 days

Service required

Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,

door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can

therefore decrease more quickly in some cases than the actual distance travelled.
Resetting: to reset the mileage before a service, press and hold button 2 for approximately 10 seconds until the display shows

the range permanently.

NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.84

ON-BOARD COMPUTER: trip settings

(5/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

e) Reset the tyre pressure.

Refer to the information on the “Tyre pressure

monitoring system” in Section 2.

+

Tyre pressure

No message

memorised

f) Trip log.

Successive display:
–

information messages (passenger airbag OFF

etc.);

–

operating fault messages (Check injection

system, etc.).

1.85

TRIP COMPUTER AND WARNING SYSTEM: information messages

Examples of messages

Interpreting the display selected

“Parking brake on”

Indicates that the parking brake has been applied.

“Checking control

functions”

Displayed with the ignition on when the vehicle is running self-diagnostics.

“Turn steering

wheel + START”

Turn the steering wheel slightly whilst pressing the vehicle start button to unlock the steering

column.

“Steering wheel

not locked”

Indicates that the steering column has not been locked.

These can help in the vehicle starting phase, or give information about a selection or a driving status.

Examples of information messages are given in the following pages.

1.86

TRIP COMPUTER AND WARNING SYSTEM: operating fault messages

These appear with the

©

 warning light and mean that you should drive very carefully to an authorised dealer as

soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.

They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The

©

 warning light stays on. Examples of operating fault messages are given in the following pages.

Examples of messages

Interpreting the display selected

“Clean diesel filter”

Indicates the presence of water in the diesel filter; contact an approved Dealer

as soon as possible.

“Check lighting”

Indicates a fault in the headlights.

“Check vehicle”

Indicates a fault in one of the pedal sensors, battery management system or oil

level sensor.

“Check airbag”

Indicates a fault in the restraint system in addition to the seat belts. In the event

of an accident, it is possible that they may not be triggered.

“Check anti- pollution system”

Indicates a fault in the vehicle’s particle filter system.

1.87

TRIP COMPUTER AND WARNING SYSTEM: warning message

These appear with the

®

 warning light and require you to stop immediately, for your own safety, as soon as traf-

fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.

Some examples of warning messages are given below. Note: the messages appear on the display either individually or al-

ternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.

Examples of messages

Interpreting the display selected

“Engine failure hazard”

Indicates an injection fault, the vehicle’s engine has overheated or there is a

serious engine fault.

“Power steering fault”

Indicates a fault in the steering system.

“Braking system fault” or “Stop vehicle” Indicates a fault in the braking system. Apply the electronic parking brake ma-

nually and ensure that the vehicle is immobilised using a chock.

“Electric failure DANGER”

Indicates a fault in the vehicle battery charging circuit (alternator etc.).

“Puncture”

Indicates a puncture on the tyre displayed on the instrument panel.

1.88

VEHICLE SETTINGS CUSTOMISATION MENU

(1/2)

Adjusting the settings

Select the function to modify:
a) Unlock driver door only ;
b) Lock doors when in motion ;
c) Use handsfree card: open/close ;
d) Indicator sound volume ;
e) Internal welcome sound ;
f) External welcome ;
g) Automatic Cabin Light ;
h) Rear wipers when reverse is ON ;
i)  Driving style indicator ;
Depending on the function, select “ON"

or "OFF" to activate or disable it and "+"

or "-" to adjust the volume of the indi-

cators.

Depending on the vehicle equipment,

this function allows you to activate/de-

activate and adjust some of the vehi-

cle’s functions.

Vehicles fitted with a

navigation system

Accessing the settings menu
With the vehicle at a standstill, using

the multifunction screen 1, select menu

“Vehicle”, “User settings” to access the

various settings.

1

For safety reasons, carry

out any adjustments when

the vehicle is stationary.

1.89

VEHICLE SETTINGS CUSTOMISATION MENU

(2/2)

3

4

Once a line has been selected, press

the switch 3 OK to adjust the function.
If you select either “PARKING ASSIST

VOLUME” or “LANGUAGE”, you will

have to make a further selection (sound

volume of the parking distance control

or instrument panel language). In this

case, make your selection and con-

firm it by holding the switch 3 OK – the

selected value is shown by a

~

 in

front of the line.

To exit the menu, press the control 4

upwards or downwards. It may be nec-

essary to carry out this operation sev-

eral times.

Vehicles not fitted with a

navigation system

Accessing the settings menu on

display 2
With the vehicle at a standstill, press

and hold the switch 3 OK to access the

settings menu.

Adjusting the settings
Browse using the control 4 to select the

function to adjust:
a) Lock doors when in motion ;
b) Unlock driver door only;
c) Rear wipers when reverse is ON ;
d) Front park assist ;
e) Automatic main beam lights ;
f)  Lane departure warning : VOLUME ;
g) Lane departure warning : Sensitivity ;
h) Rear park assist ;
i) PARKING ASSIST VOLUME ;
j) LANGUAGE ;
k) UNIT ;
l) STYLE ;
m) COLOUR.

=

 function activated

<

 function deactivated

The vehicle settings personalisation

menu cannot be used when driv-

ing. At speed exceeding 12 mph

(20 km/h), the instrumental panel

display switches automatically back

to trip computer and warning system

mode.

2

1.90

External temperature

indicator

Special note:
When the exterior temperature is - 3 °C

to + 3 °C, the °C characters flash (sig-

nalling a risk of ice on the road).

The time and/or external tempera-

ture are displayed on the multifunc-

tion screen 1
Refer to the handbook for the equip-

ment.

CLOCK AND EXTERIOR TEMPERATURE

External temperature

indicator
As ice formation is related

to climatic exposure, local

air humidity and temperature, the

external temperature alone is not

sufficient to detect ice.

1

If the electrical supply is cut (battery

disconnected, broken supply wire,

etc.), the clock will automatically

go back to the right time after a few

minutes once the system is capable

of receiving information GPS.

1.91

STEERING WHEEL/POWER-ASSISTED STEERING

Power-assisted steering

Variable power-assisted steering
The variable power assisted steering

system is equipped with an electronic

control system which alters the level of

assistance to suit the vehicle speed.
Steering is made easier during parking

manoeuvres (for added comfort) while

the force needed to steer increases

progressively as the speed rises (for

enhanced safety at high speeds).

Special feature of Stop and Start
With the engine on standby, power-as-

sisted steering is no longer operational.

It returns to its original state when the

engine is restarted or when the speed

moves above 1 mph or 1 km/h (hill,

slope, etc.).

Adjusting the steering wheel

height and depth

Lower the lever 1 and position the

steering wheel in the required position.
Then, raise the lever fully, beyond the

point of resistance to lock the steering

wheel.
Make sure that the steering wheel is

correctly locked.

For safety reasons, only

adjust the steering wheel

when the vehicle is station-

ary.

Never leave the steering wheel at

full lock while stationary.

Do not switch off the engine

when driving downhill and,

as a general rule, when

driving (the power-assisted

steering and brake cannot operate

normally).

With the engine switched off, or if

there is a system fault, it is still pos-

sible to turn the steering wheel. The

force required will be greater.

1

NB: power-assisted steering depends

on the mode selected in the “Multi-

Sense” menu (please refer to the infor-

mation in “Multi-Sense” in Section 3).

1.92

Folding rear view mirrors

The door mirrors automatically fold in

when the vehicle is locked (switch 3 in

position B).

In any case, you can make the door

mirrors fold in (switch 3 in position C) or

fold out (switch 3 in position A).

Automatic mode is then deactivated. To

reactivate it, position switch 3 to B.

Welcome and goodbye function

(depending on the vehicle)
–  From the multifunction screen, select

the “Vehicle” menu, then “User set-

tings”, “External welcome” and acti-

vate or deactivate the function (ON

or OFF);

or
–  press and hold the 4  OK switch to

access the settings menu. Then

browse using control 5 to select the

“External welcome” menu.

REAR VIEW MIRRORS

(1/2)

Exterior rear view mirrors

Adjustment

Select the door mirror using switch 2

then use button 1 to adjust it to the de-

sired position.

Heated door mirrors

Mirror de-icing is carried out at the

same time as rear screen de-icing.

Please refer to the information

on “Manual air conditioning” and

“Automatic climate control”.

Objects observed in the

door mirror glass are actu-

ally closer than they appear.
For your safety, take this

into account in order to correctly

assess the distance before any ma-

noeuvre.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

A

B C

1

2

3

Depending on the selected choice, the

door mirrors will fold out:

–  when the ignition is next switched on

(function deactivated);

–  upon detecting the RENAULT card

or upon unlocking the vehicle (func-

tion activated).

5

4

1.93

Interior rear view mirror

Rear view mirror with lever 6
When driving at night, to avoid being

dazzled by the headlights of the vehicle

behind, depress the little lever located

behind rear view mirror 6.

Rear view mirror without lever 6
The rear-view mirror automatically

darkens when you are being followed

by a vehicle using main beam head-

lights or in very bright lighting.

REAR VIEW MIRRORS

(2/2)

Special feature:
When the rear-view mirror has been

manually deployed or folded back, it is

possible to reset it to a usage position.

To do this, position the switch 3 to C

A mechanical noise from the rear-view

mirror unit will be heard.
If it is not the case, place switch 3 to A

and then place switch 3 to C until the

mechanical noise of the rear-view

mirror is heard.

A

C

3

Depending on the vehicle, informa-

tion regarding the activation and

deactivation of the front passen-

ger airbag is displayed on the inte-

rior rear-view mirror (please refer to

information on “Child safety: front

passenger airbag deactivation/acti-

vation” in Section 1).

6

1.94

AUDIBLE AND VISUAL SIGNALS

Horn

Press the steering wheel boss A to ac-

tivate the horn.

Headlight flasher

Pull stalk 1 towards you then release it

to flash the headlights.

é

Hazard warning lights

Press switch 2. This switch ac-

tivates all four direction indicators and

the side indicator lights simultaneously.

It must only be used in an emergency to

warn drivers of other vehicles that you

have had to stop in an area where stop-

ping is prohibited or unexpected or that

you are obliged to drive under special

conditions.
Depending on the vehicle, the hazard

warning lights may come on automati-

cally under heavy deceleration. You can

switch them off by pressing switch 2.

Direction indicators

Move stalk 1 parallel to the steering

wheel and in the direction you are going

to turn it.

One-touch mode
When driving, it is possible that the

steering wheel may not be turned suf-

ficiently to return the stalk automatically

to its starting position.

In this case, briefly turn stalk 1 to the in-

termediate position, then release it: the

stalk returns to its original point and the

indicator light flashes three times.

2

A

1

1.95

EXTERIOR LIGHTING AND SIGNALS

(1/6)

á

Main beam headlights

With the dipped beam

headlights lit, push stalk 1. This indica-

tor light on the instrument panel comes

on.
To return to the dipped headlight posi-

tion, pull the stalk 1 towards you again.

š

Side lights

Turn ring 3 until the symbol is

opposite mark 2. This indicator light on

the instrument panel comes on.

k

Dipped beam

headlights

Manual operation

Turn ring 3 until the symbol is opposite

mark 2. This indicator light on the in-

strument panel comes on.

Automatic operation
Turn ring 3 until the AUTO symbol is op-

posite mark 2: with the engine running,

the dipped beam headlights switch on

or off automatically depending on the

brightness of the light outside, without

any action on stalk 1.

Before driving at night:

check that the electrical

equipment is operating cor-

rectly. As a general precau-

tion, check that the lights are not

obscured (by dirt, mud, snow or ob-

jects being transported).

1

3

2

1

1.96

EXTERIOR LIGHTING AND SIGNALS

(2/6)

Automatic main beam

headlights

Depending on the vehicle, this system

switches the main beam headlights on

and off automatically. It uses a camera

located behind the interior rear-view

mirror to detect vehicles that are being

followed and those coming in the oppo-

site direction.
The main beam headlights come on au-

tomatically if:

–  exterior light is weak;

–  no other vehicles or lighting are de-

tected;

–  the vehicle speed is above approxi-

mately 25 mph (40 km/h).

If any of the above conditions are not

fulfilled, the system switches to dipped

beam headlights.

The “automatic main beam

headlights” system should

under no circumstances be

used to replace driver atten-

tion and responsibility with regard

to vehicle lighting and adapting to

light, visibility and traffic conditions.

The system may encounter difficul-

ties under certain conditions, inclu-

ding:

–  extreme weather conditions (rain,

snow, fog, etc.);

–  obstruction in front of the wind-

screen or camera;

–  when a following or oncoming ve-

hicle has weak or hidden lighting;

–  incorrect settings for the front

headlights;

– reflective systems;

– ...

Switching on

Vehicle fitted with a navigation

system
From the multifunction screen 4, select

the “Vehicle” menu, then “Driving as-

sistance”, “Automaticmain beam lights”

then choose “ON” or “OFF”.

4

1.97

3

2

1

Vehicles without a navigation

system
–  With the vehicle stationary, press

and hold the OK switch 5 to access

the settings menu;

–  repeatedly press the control 6 up

or down until you reach the “Driving

assistance” menu. Press the OK

switch 5;

5

6

–  repeatedly press control 6 up or down

until you reach the “Automaticmain

beam lights” menu, then press the

OK switch 5;

–  press the OK switch 5 again to acti-

vate or deactivate the function.

Activation/deactivation

To activate automatic main beam

headlights:
– turn ring 3 until the AUTO symbol is

opposite mark 2;

– push stalk 1.

Warning light

 comes on the in-

strument panel.

To deactivate automatic main beam

headlights:
– pull stalk 1 towards you;
–  or turn ring 3 to a position other than

AUTO.

Warning light

 goes out on the in-

strument panel.
Note: make sure the windscreen is not

obscured (dirt, mud, snow, condensa-

tion etc.).

EXTERIOR LIGHTING AND SIGNALS

(3/6)

Each time you start the engine, pull

and then push the stalk 1 to reacti-

vate the system.















Content   ..  4  5  6  7   ..
