Deactivating, activating the


Press switch 1 to deactivate the func-

tion. The message “Stop & Start deac-

tivated” will appear on the instrument

panel and the integrated warning light 2

on the switch will light up.

Pressing again will reactivate the

system. The message “Stop & Start ac-

tivated” will appear on the instrument

panel and the integrated warning light 2

on the switch 1 will go out.



Deactivate the Stop and

Start function when perfor-

ming any operations in the

engine compartment.

Special feature of the automatic

engine re-start
Under certain conditions, the engine

can restart on its own in order to gua-

rantee your safety and comfort.

This can occur especially when:
–  the outdoor temperature is too low or

too high (less than around 0 °C or

higher than around 30 °C);

–  the “Clear View” function is activated

(please see “Automatic Climate

Control” in Section 3);

–  the battery is not sufficiently char-


–  the vehicle speed is above 4.34 mph

(7 km/h) (downhill slope etc.) ;

– repeated pressing on the brake

pedal or braking system require-


– ...

Before getting out of the

vehicle, you must switch

off the ignition by pressing

the engine stop (please see

“Starting, stopping the engine”).



Note: With the engine on standby,

press switch 1 to automatically re-

start the engine.

The system reactivates automati-

cally each time the vehicle is started

using the start button (please refer

to “Starting, stopping the engine” in

Section 2).

Operating faults

When the message “Check Stop &

Start” appears on the instrument panel

and the integrated warning light 2 lights

up on the switch 1, the system is deac-


Please consult an authorised dealer.

In the event of an emer-

gency, the engine can be

restarted by pressing on the

clutch pedal if the Stop and

Start function is activated.



The following operating conditions:
–  driving for long periods when the low

fuel level warning light is lit;

–  using leaded petrol;
–  using fuel or lubrication additives

which are not approved.

Or operating faults such as:
–  faulty ignition system, running out of

fuel or disconnected spark plugs re-

sulting in the engine misfiring or cut-

ting out when driving;

–  loss of power,
as they may cause the catalytic con-

verter to overheat and thus reduce its

efficiency,  or damage it irreparably

and cause heat damage to the vehi-


If you notice any of the above operating

faults, have the necessary repairs car-

ried out as soon as possible by an ap-

proved Dealer.
These faults may be avoided by regu-

larly taking your vehicle to an approved

Dealer at the intervals specified in the

Maintenance Service Booklet.

Starting problems

To avoid damaging the catalytic con-

verter, do not keep trying to start the

engine (using the start button, or by

pushing or towing the vehicle) without

having identified and corrected the

starting fault.
If the fault cannot be identified, do not

keep trying to start the engine, but con-

tact an approved Dealer.

Do not park the vehicle or

run the engine in locations

where combustible sub-

stances or materials such

as grass or leaves can come into

contact with the hot exhaust system.



Diesel engine speed

Diesel engines are fitted with injection

equipment which prevents the engine

speed being exceeded irrespective of

the gear selected.
If the message “Check anti-pollution

system” is displayed along with warn-

ing lights




, consult an

authorised dealer immediately.
When driving, depending on the fuel

grade used, it is possible that white

smoke may be emitted.
This is due to the exhaust particle filter

being cleaned automatically, and does

not affect the way the vehicle runs.

Running out of fuel

If the tank has been completely

drained, the system must be reprimed

after the tank is refilled: see information

on the “fuel tank” in section 1 before re-

starting the engine.

Do not park the vehicle or

run the engine in locations

where combustible sub-

stances or materials such

as grass or leaves can come into

contact with the hot exhaust system.

Precautions to be taken in


To avoid any faults in icy weather:
–  ensure that the battery is always fully


–  always keep the diesel tank rela-

tively full to avoid water vapour con-

densing in it and accumulating at the

bottom of the tank.



Selecting reverse gear

Vehicles with manual gearbox: follow

the grid drawn on knob 1, and depend-

ing on the vehicle, lift ring against the

gear lever knob to select reverse.
Vehicle with automatic gearbox: refer

to the information on the “Automatic

gearbox” in Section 2.
The reversing lights will come on as

soon as reverse gear is selected with

the ignition on.



To release:
Pull lever 2 up slightly, press button 3

and then lower the lever to the floor.

To apply:
Pull the lever 2 upwards and make sure

the vehicle is immobilised.

When stationary and de-

pending on the slope and/or

vehicle load, it may be nec-

essary to pull up the hand-

brake at least two extra notches and

engage a gear (1


 or reverse gear)

for vehicles with a manual gearbox

or position P for vehicles with an au-

tomatic transmission.



An impact to the under-

side of the vehicle while

manoeuvring (e.g.: strik-

ing a post, raised kerb or

other street furniture) may result in

damage to the vehicle (e.g.: defor-

mation of the rear axle).
To avoid any risk of accident, have

your vehicle checked by an ap-

proved Dealer.

Make sure that the hand-

brake is properly released

when driving (red indicator

light off), otherwise over-

heating, or even damage, may



Before leaving the vehicle,

check that the electronic

parking brake is fully ap-

plied. Indicator light 2 on

switch 3 and indicator light



on the instrument panel light up to

show that the parking brake is ap-

plied but go out when the doors are


To indicate that the electronic parking

brake is released, a beep sounds and

the message “Apply parking brake” ap-

pears on the instrument panel:
–  with the engine running: when the

driver’s door is opened;

–  with the engine switched off (eg.

when the engine stalls): when a front

door is opened.

In this case, pull and release switch 3 to

apply the electronic parking brake.

Automatic releasing of the

electronic parking brake
The brake will be released as soon as

the vehicle moves, by accelerating with

a gear selected and the engine running.

Automatic operation

The electronic parking brake en-

sures vehicle immobilisation when the

engine is stopped and engine Start/

Stop button 1 is pressed.
In all other instances, e.g. engine stal-

ling, the electronic parking brake is not

applied automatically. Manual mode

must be used.
For certain country-specific model ver-

sions, the automatic brake application

function is not activated. Refer to the in-

formation on “Manual operation”.



To confirm that the electronic parking

brake is applied, the message “Parking

brake on” and warning light



on the instrument panel and warning

light 2 on the switch 3 light up.
After the engine is switched off, indi-

cator light 2 goes out several minutes

after the electronic parking brake has

been applied and indicator light



goes out when the vehicle is locked.





Special cases

When parking on a slope or towing a

trailer, pull switch 3 for a few seconds

to obtain the maximum braking effect.
To park the vehicle without applying the

electronic parking brake (if there is a

risk of freezing, for example):
– with the engine running and

RENAULT card in reader 4, switch

off the engine by pressing engine

Start/Stop button 1;

–  remove the RENAULTcard from the

Reader  4 and insert it again in the


–  select a gear (manual gearbox) or

position P (automatic gearbox);

–  depress the brake pedal and press

switch 3 at the same time;

–  remove the RENAULT card from the

card reader.

Brief stop

To manually activate the electronic par-

king brake, (when stopping at a red

light, or stopping when the engine is

running, etc.): pull and release switch 3

The brake is released as soon as the

vehicle is started up again.






Manual operation

You can control the electronic parking

brake manually.

Applying the electronic parking


Pull switch 3. Indicator lights 2 and


 light up on the instrument panel.

Releasing the electronic parking


With the ignition on, depress the brake

pedal then press button 3: indicator

lights 2 and


 go out.



–  If there is an electronic parking brake

fault, warning lights


 light up

accompanied by the “Parking brake

fault” message, a beep and, in cer-

tain cases, warning light



This means that you must stop as

soon as traffic conditions allow.

Operating faults

–  If there is a fault, the



light illuminates on the instrument

panel accompanied by the “Check

parking brake” message and, in

some cases, the



Contact an approved Dealer as soon

as possible.



It is therefore essential to

immobilise the vehicle by

engaging first gear (manual

gearbox) or position P (au-

tomatic gearbox). If the slope re-

quires it, chock the vehicle.

Versions with an automatic


For safety reasons, automatic release

is deactivated when the driver’s door

is open or not shut properly and the

engine is running (in order to prevent

the vehicle from moving without the

driver). The “Release parking brake

manually” message appears on the

instrument panel when the driver de-

presses the accelerator.

Never leave your vehicle

without moving the selec-

tor lever to position P or N

This is because when the

vehicle is stationary with the engine

running and a gear engaged, the

vehicle may begin to move if you

There is a risk of accidents.

If no lights or sounds are

apparent, this indicates

a fault in the instrument

panel. This indicates that

it is essential to stop immediately

(as soon as traffic conditions allow).

Ensure that the vehicle is correctly

immobilised and contact an appro-

ved Dealer.




Fuel consumption is accredited in ac-

cordance with a standard regulatory

method. Identical for all manufactur-

ers, this enables vehicles to be com-

pared with one another. Consumption

in real time depends on vehicle usage

conditions, the equipment fitted and the

user’s driving style. To optimise fuel

consumption, please refer to the follow-

ing advice.
Depending on the vehicle, you will have

various functions which enable you to

lower your fuel consumption:
–  gear change indicator;

–  the journey record and eco-driving

advice via the multimedia display;

If fitted on the vehicle, the navigation

system provides additional information.

Gear change indicator

To optimise consumption, a warning

light on the screen 1 tells you the best

time to change gear:



 to shift up a gear;



 to shift down a gear.

Journey record

Once the engine is switched off, you

will see “Journey record” displayed on

the screen 1, enabling you to view in-

formation relating to your last journey.
This indicates:
–  average fuel consumption;

–  number of miles/kilometres travelled;

–  number of miles/kilometres saved.





An overall rating from 0 to 100 is dis-

played to let you assess your eco driv-

ing performance. The higher the score,

the better your eco-driving perform-


Eco advice is given to help improve

your performance.

With your favourite journeys saved, you

can evaluate your performance.

For more information, please see the

multimedia system instructions.

Obstructions to the driver

On the driver’s side, only

use mats suitable for the

vehicle, attached with the

pre-fitted components, and check

the fitting regularly. Do not lay one

mat on top of another.

There is a risk of wedging the


Driving advice, Eco-driving

–  Drive carefully for the first few miles

until the engine reaches its normal

operating temperature, rather than

let it warm up while the vehicle is sta-


–  Speed is expensive.
–  Sporty driving uses a lot of fuel: drive

with a light right foot.

–  Do not overrev the engine in the in-

termediate gears.

  You should always use the highest

gear possible.

–  Avoid sudden acceleration.
–  Brake as little as possible. If you an-

ticipate an obstacle or bend in ad-

vance, you may then simply release

the accelerator pedal.

– Do not try to maintain the same

speed up a hill, accelerate no more

than you would on the level. Keep

your foot in the same position on the

accelerator pedal.

–  Double declutching and accelerating

before switching off are unnecessary

in modern vehicles.

–  Bad weather, flooded roads:

Do not drive through floods

if the water is above the

lower edge of the wheel





–  An underinflated tyre increases fuel


–  The use of non-recommended tyres

can increase fuel consumption.

Advice on use
–  Electricity is fuel; switch off all the

electrical components which are

not really needed. However (safety

first), keep your lights on when the

visibility is bad (“see and be seen”).

–  Use the air vents. Driving with the

windows open at 60 mph (100 km/h)

will increase fuel consumption by


–  Never fill the fuel tank right to the

brim to avoid overflow.

–  In vehicles fitted with air condi-

tioning, it is normal to observe an

increase in fuel consumption (espe-

cially in urban conditions) when it is

used. For vehicles fitted with manual

air conditioning, switch off the system

when it is not required.
Advice for reducing consumption

and therefore helping to preserve

the environment:
If the vehicle has been parked in the

sun, open the doors for a few mo-

ments to let the hot air escape before

starting the engine.

– Do not leave an empty roof rack

fitted to the vehicle.

–  It is better to fit a trailer for bulky ob-


–  When towing a caravan, fit a wind

deflector and adjust it carefully.

–  Avoid using the car for door-to-door

calls (short journeys with long waits

in between) because the engine

never reaches its normal operating




Your vehicle complies with criteria for

recycling and recovering vehicles at the

end of their service life, which will come

into force in 2015.
Some of the parts on your vehicle have

been designed to be recycled later.
These parts are easily removable in

order to be collected and reprocessed

in recycling networks.
Furthermore, by virtue of its design,

moderate fuel consumption and initial

settings, your vehicle also conforms

to current anti-pollution regulations.

The manufacturer is actively striving

to reduce pollutant exhaust gas emis-

sions and to save energy. However,

the fuel consumption of your vehicle

and the level of pollutant exhaust gas

emissions are also your responsibility.

Ensure that it is maintained and used



It is important to remember that fail-

ure to respect anti-pollution regulations

could lead to legal action being taken

against the vehicle owner.
In addition, replacing engine, fuel

supply system and exhaust compo-

nents with parts other than those origi-

nally recommended by the manufac-

turer may alter your vehicle so that it

no longer complies with anti-pollution

Have your vehicle adjusted and

checked by an authorised dealer, in ac-

cordance with the instructions given in

your maintenance schedule: they will

have all the equipment necessary for

ensuring that your vehicle is maintained

to its original standard.

Engine adjustments

  Air filter, fuel filter: a choked ele-

ment will reduce efficiency. It must

be replaced.

 Idle  speed: no adjustment is


Exhaust gas monitoring


The exhaust gas monitoring system will

detect any operating faults in the vehi-

cle’s antipollution system.

If this system malfunctions, toxic sub-

stances may be released into the at-

mosphere or damage may occur.


This warning light on the in-

strument panel will indicate if

there are any faults in the system:

This lights up when the ignition is

switched on and goes out when the

engine is started.
–  If it lights up continuously, consult an

approved Dealer as soon as possi-


–  if it flashes, reduce the engine speed

until the light stops flashing. Contact

an authorised dealer as soon as pos-





Your vehicle has been designed to

emit fewer greenhouse gases (CO2)

while in use, and therefore to consume

less fuel (eg. 140 g/km, equivalent to

5.3 l/100 km for a diesel vehicle).
Our vehicles are also equipped with a

particle filter system including a cata-

lytic converter, an oxygen sensor and

an active carbon filter (the latter pre-

vents vapour from the fuel tank being

released into the open air).
For certain diesel vehicles, this system

also has a particle filter to reduce the

volume of soot particles emitted.

Please make your own

contribution towards

protecting the environment


–  Worn parts replaced in the course of

routine vehicle maintenance (vehi-

cle battery, oil filter, air filter, batter-

ies, etc.) and oil containers (empty or

filled with used oil) must be disposed

of through specialist organisations.

–  At the end of the vehicle’s service

life, it should be sent to approved

centres to ensure that it is recycled.

–  In all cases, comply with local legis-



Your vehicle is 85% recyclable and

95% recoverable.
To achieve these objectives, many of

the vehicle components have been de-

signed to enable them to be recycled.

The materials and structures have

been carefully designed to allow these

components to be easily removed and

reprocessed by specialist companies.
In order to preserve raw material re-

sources, this vehicle incorporates nu-

merous parts made from recycled plas-

tics or renewable materials (vegetable

or animal-derived materials such as

cotton or wool).

Your vehicle has been designed with

respect for the environment in mind for

its entire service life: during production,

use and at the end of its life.

This commitment is illustrated by the

Renault eco² signature.


Your vehicle has been manufactured at

a factory which complies with a policy

to reduce the environmental impact

on the surrounding areas (reduction of

water and energy consumption, visual

and noise pollution, atmospheric emis-

sions and waste water; sorting and re-

using waste).


If the vehicle is equipped with the func-

tion, this system monitors the tyre pres-


Operating principle

Each wheel (except for the emergency

spare wheel) has a sensor in the infla-

tion valve which periodically measures

the tyre pressure. The system informs

the driver via the display 1 and on-

board computer 2 that the tyres are suf-

ficiently inflated and warns if they are

underinflated or leaking. The warning

light 4

 on the instrument panel

comes on to warn the driver if the pres-

sure is too low.

It should always be done after checking

the tyre pressure of all four tyres when


Tyre pressures must correspond to the

current usage of the vehicle (empty,

carrying a load, motorway driving, etc.).
With the ignition on:

–  Make short presses on the control 3

to select the tyre pressure display

(see “On-board computer: settings”

in Section 1);

–  press and hold (around 3 seconds)

the button 3 to launch the reset. A

flashing tyre followed by the mes-

sage “Pressure ref Ongoing” indi-

cates that the request to learn the

reference pressure has been taken

into account;

–  reset can take several minutes of







Resetting the standard level

for the tyre pressures

This should be done:
– when the standard tyre pressure

needs to be changed to adapt to

usage conditions (empty, carrying a

load, motorway driving, etc.);

–  after swapping wheels over (how-

ever this practice is not recom-


–  after changing a wheel.

This function is an additio-

nal driving aid.

However, the function does

not take the place of the

driver. It cannot, therefore, under

any circumstances replace the vig-

ilance or the responsibility of the


Check the tyre pressures, including

the emergency spare wheel, once a





The warning light 4

 on the in-

strument panel along with the display 1

and messages on the display 2 indicate

any tyre pressure faults (flat tyre, punc-

tured tyre, system fault, etc.).





The wheel A, together with the warn-

ing light 4

, indicates that the af-

fected wheel is punctured or severely

underinflated. Replace it or contact an

authorised dealer if it is punctured. Top

up the tyre pressure if the wheel is de-


This message appears along with the


 warning light.

“Adjust tyre pressure”

A coloured wheel A, together with the

warning light 4

, indicates a flat


Check and, if necessary, readjust the

pressures of the four wheels when cold.

While driving the warning light 4


goes off after a few minutes.



Warning light



quires you to stop immedi-

ately, for your own safety,

as soon as traffic conditions allow.

The sudden loss of pressure in a

tyre (burst tyre, etc.) cannot be de-

tected by the system.







The warning light

 flashes for

several seconds, then stays on, along

with the message “CHECK TYRE

PRESSURE SENSORS” and a missing

wheel B.

This message appears along with the


 warning light.

This message appears when at least

one wheel fitted on the vehicle does not

have sensors (e.g. emergency spare

wheel). In other cases, contact an au-

thorised dealer.

Replacing wheels/tyres

This system requires specific equip-

ment (wheels, tyres, sensors, etc.).
Contact an authorised dealer to replace

the tyres and to find out about avail-

able accessories compatible with the

system: the use of any other accessory

could affect the correct operation of the

system or damage a sensor.

Changing a wheel

The system may take sev-

eral minutes depending on

use for the new wheel po-

sitions and pressures to be recog-

nised; check the tyre pressures after

all operations.




Interchangeability of wheels

If you wish to swap the wheels around,

please consult an approved dealer to

reinitialise the system.

Each of the sensors incor-

porated in the valves 5 is

dedicated to a single wheel:

under no circumstances

should you swap the wheels, with-

out resetting the system.
There is a risk of incorrect informa-

tion which could have serious con-




Readjustment of tyre


The tyre pressures must be adjusted

when cold (please refer to the label lo-

cated on the edge of the driver’s door).
If tyre pressures cannot be checked

when the tyres are cold, the recom-

mended pressures must be increased

by 0.2 to 0.3 bar (3 PSI).

Never deflate a hot tyre.

Emergency spare wheel

If the vehicle is equipped with an emer-

gency spare wheel, it will not have

a sensor. When it is fitted to the ve-

hicle, the message “CHECK TYRE

PRESSURE SENSORS” is displayed

on the instrument panel.







Depending on the vehicle, to mark the

correct position of the wheel, note the

colour of the ring 6 (after cleaning, if ne-

cessary) on each valve:
C yellow ring
D black ring
E red ring
F green ring

Each of the sensors incorporated in the valves 5 is dedicated to a single

wheel: under no circumstances should you swap the wheels, without re-

setting the system.
There is a risk of incorrect information which could have serious conse-


Tyre repair product and

inflation kit

Because the valves are specially de-

signed, only use equipment approved

by the approved network.











Content   ..  5  6  7  8   ..
