Renault Duster (2016 year). Instruction - part 9

3.8

From the front passenger

seat

Operate switch 6.

ELECTRIC WINDOWS

(1/3)

Manual window winders

Turn the handle 1 to lower or raise the

window to the desired height.

Electric windows

With the ignition on, press the switch

to lower the window to the required

level;
Lift the switch to raise the window to the

desired height.

From the driver’s seat

Operate the switches as follows:
–  2 for the driver’s side;
–  3 for the front passenger side;
–  4 and 5 for the rear passengers.

Avoid resting any objects against a

half-open window: there is a risk that

the electric window winder could be

damaged.

Closing windows can cause

serious injury.

3.9

ELECTRIC WINDOWS

(2/3)

From the rear seats

Operate switch 7.

Safety of rear occupants
The driver can prevent operation of the rear electric windows by press-

ing switch 8.

Driver’s responsibility
Never leave your vehicle with the key inside, and with a child, adult who is not

self-sufficient or a pet, even for a short while. They may pose a risk to themselves

or to others by starting the engine or activating equipment (such as the gear lever

or electric windows). If any part of the body becomes trapped, reverse the direc-

tion of the window immediately by pressing the relevant switch.
Risk of serious injury.

3.10

ELECTRIC WINDOWS

(3/3)

One-touch windows

When the vehicle is equipped with this

function, the one-touch mode works in

addition to the operation of the electric

windows described previously.
It is only fitted to the driver’s window.
– Fully and briefly press down on the

relevant switch down: the window

will open completely.

– Fully and briefly lift the relevant

switch: the window will close com-

pletely.

Pressing the switch again while the

window is moving will stop its move-

ment.

Special features

If the window detects resistance when

closing (e.g.: branch of a tree, etc.) it

stops and then lowers again by a few

centimetres.
If you use the switch while the window

is moving, it stops working.

Operating faults

In case of a fault when closing a window,

the system reverts to normal mode: pull

the switch concerned up to fully close

the window, then hold the switch (still

on the closure side) for three seconds

then lower and raise the window fully to

reinitialise the system.
If necessary, contact an approved

Dealer.

When closing the windows,

ensure that no part of the

body (arm, hand, etc.) is

protruding from the vehicle.

Risk of serious injury.

Avoid resting any objects against

a half-open window: there is a risk

that the electric window could be

damaged.

3.11

INTERIOR LIGHTING

(1/2)

Courtesy light

Pressing switch 1 provides:
– continuous lighting;
– or temporary lighting by opening one

of the front doors, or by opening one

of the four doors, depending on the

vehicle. The light only goes out when

the doors are correctly closed;

– no lighting.

Map reading lights

Pressing switch 2 provides:
– continuous lighting;
– no lighting.

3.12

INTERIOR LIGHTING

(2/2)

Automatic operation of interior

lighting

(depending on the vehicle)

– if the doors are unlocked using

the remote control, the lighting

is switched on for approximately

30 seconds.

– If a door is open (or not properly

closed), the lighting is switched

on for approximately 3 to 30 mi-

nutes.

– if all the doors are closed, the

lighting start to dim when the ig-

nition is switched on.

Boot light 4

The light 4 comes on when the boot is

opened.

Glovebox light 3

Light 3 comes on when the cover is

opened.

3.13

Grab handle 4

This offers support and can be held

when the vehicle is being driven.
Do not use these for getting into or out

of the vehicle.

SUN VISOR/GRAB HANDLE

Sun visor

Lower the sun visor 1 or 3 over the

windscreen or unclip it and turn it over

the side window.

Courtesy mirrors 2

Depending on the vehicle, the sun

visors are fitted with a courtesy mirror.

3.14

Cigarette lighter 3

With the ignition on, push in the ciga-

rette lighter 3.
It will spring back with a click when it is

ready. Pull it out to use. After use, re-

place it without pushing it all the way in.

Accessories sockets 3 and 5

The sockets are provided for con-

necting accessories approved by our

Technical Department.

ASHTRAYS/CIGAR LIGHTER/ACCESSORIES SOCKET

Ashtray

It can be housed in either position 1

or 4.
Lift the cover 2 to open.
Remove the ashtray to empty it.

If your vehicle is not fitted with a

cigar lighter and an ashtray, these

can be obtained from an approved

Dealer.

Connect accessories with

a maximum power of

120 Watts (12 V) only.
When several accessory

sockets are used at the same time,

the total power of the connected

accessories must not exceed

180 watts.
Fire hazard.

3.15

REAR HEADRESTS

The headrest is a safety

component. Ensure that it is

fitted and in the correct po-

sition: the top of your head

should be in line with the top of the

headrest.

To remove the headrests A or B
Raise the headrest as far as it will go,

then press button 1 and remove the

headrest.

To adjust the height of the

headrest A

(depending on vehicle)
Press the button 1 and simultaneously

slide the headrest to the desired height.

To reinstall the headrests A or B
Insert the rods in the holes, press

button 1, lower the headrest and check

that it is securely in place.

Position for using the headrest B

(depending on vehicle)
Lift the headrest to maximum height,

then lower it until it locks.

Storage position for the headrest B

(depending on vehicle)
Press the button 1 and lower the head-

rest completely.
When the headrest is set at the

lowest position (position C), this is

for storage only: it should not be in

this position when a seat is occupied.

3.16

Dashboard upper storage

compartment 2

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(1/4)

Front door storage

compartments 1

Ensure that no hard, heavy

or pointed objects are

placed in the “open” sto-

rage compartments in such

a way that they may fall onto pas-

sengers during sudden turning, bra-

king or in the event of an accident.

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

Mobile phone storage

compartment 3

(depending on the vehicle)

Do not hang any heavy and/

or sharp objects which may

fall whilst driving.

Risk of injury.

3.17

Centre console storage

compartment 5

(or location of the 4x2 (2WD) and 4X4

(4WD) mode selector)

Locations for cup holder or

ashtray 6.

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(2/4)

Centre console storage

compartment 4

(or radio location)

When cornering, accelera-

ting or braking, ensure that

the cup does not spill.
There is a risk of burning if

hot liquid escapes.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” sto-

rage compartments in such

a way that they may fall onto pas-

sengers during sudden turning, bra-

king or in the event of an accident.

3.18

This glove box can be used to store A4

format documents.
Inside the cover, a section 8 has been

provided for pens, maps, etc.

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(3/4)

Passenger side glove box

Pull handle 7 to open it.

Precautions during use
Cover A in the bottom of the glove

box protects a socket reserved ex-

clusively for operations by the ap-

proved dealer network
You should therefore avoid keeping

liquids in this compartment (there is

a risk of liquid leaking and getting

into this socket).

Nothing should be placed on the floor area in front of the driver as such

objects may slide under the pedal during braking manoeuvres, thus obs-

tructing its use.

3.19

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(4/4)

Front seat storage pockets 9

Ensure that no hard, heavy

or pointed objects are

placed in the “open” sto-

rage compartments in such

a way that they may fall onto pas-

sengers during sudden turning, bra-

king or in the event of an accident.

Bottle holders 10

It can hold a 1.5 litre bottle.

3.20

Lower the rear headrests completely

(refer to the information on the “Rear

headrests” in Section 3).
Lower handle(s) 3.
Lower the seatback B or C.

Depending on the vehicle, the seat A

and the seatback B or C may be folded

away to allow bulky objects to be car-

ried.

To fold the back B or C
Ensure that the front seats are far

enough forward.
Insert buckles 1 into housings 2 before

moving the seatback(s).

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

REAR BENCH SEAT

(1/3)

When moving the rear

bench seat, ensure that

nothing obstructs the an-

chorage points (part of the

body, a pet, gravel, cloth, toys, etc.).

Check that the rear seat

belts are positioned and

operating correctly each

time the rear bench seat is

moved.

3.21

REAR BENCH SEAT

(2/3)

When refitting the seat-

back, make sure it is cor-

rectly locked in place.

If seat covers are fitted,

make sure these do not prevent the

seatback latch from locking in.

Make sure that the seat belts are

positioned correctly.

Reposition the headrests.

Check that the rear seat

belts are positioned and

operating correctly each

time the rear bench seat is

moved.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

To reposition the seat back B or C
Lift the seatback(s).
Check the seatbacks are correctly

locked in position.
Refit the rear headrests (refer to the

information on the “Rear headrests” in

Section 3).

To fold away the seat base
Tilt the seat base A against the front

seats.

To fold the back B or C
Press the tab and lift the headrest to

remove it.
Proceed as described above.

3.22

REAR BENCH SEAT

(3/3)

To reposition the seat A in place
Fasten all of the rear seat belts before

refitting the seat base (refer to the in-

formation on the “Rear seat belts” in

Section 1).
Push down the seat base until it comes

into contact with the seatback(s).
Check that the seat belt stalks 5 are po-

sitioned correctly when refitting the seat

base: to do this, pull the straps 4 so that

all the seat belt stalks 5 are on top of

the folded down seat base.

Unbuckle all of the rear seat belts and

position them correctly (refer to the in-

formation on the “Rear seat belts” in

Section 1).
Check that the four Isofix mounting

rings are on top of the seat base after it

is folded down; refer to the information

on “Child safety: Mounting a child seat”

in section 1.

When moving the rear

bench seat, ensure that

nothing obstructs the an-

chorage points (part of the

body, a pet, gravel, cloth, toys, etc.).

Check that the rear seat

belts are positioned and

operating correctly each

time the rear bench seat is

moved.

3.23

TAILGATE

Manual control

To open, insert the key in the lock and

turn it (movement A).

Remove the key and press button 1.

Lift the tailgate.
To close, lower the tailgate using inte-

rior handle 2 to help at first.

Once you have lowered the tailgate

to shoulder height, release the interior

handle and finish closing the tailgate by

pressing down on the tailgate from the

outside.

Insert the key in the lock and turn it

(movement B).

Electric central locking

The tailgate is locked and unlocked at

the same time as the doors.
To open, press the button 1 and lift the

tailgate.
To close, lower the tailgate using inte-

rior handle 2 to help at first.
Once you have lowered the tailgate

to shoulder height, release the interior

handle and finish closing the tailgate by

pressing down on the tailgate from the

outside.

Content .. 7 8 9 10 ..
