89
ELECTRICAL DIAGRAMS
89 - 92
LINK WIRE FUNCTIONS
CODES
A
SUPPLY + AFTER CONTACT
A3
PROTECTED
ACCESORIES
AP29
+ AFTER PROTECTED CONTACT ENGI
NE SAFETY FUNCTION
AP40
SUPPLY + PROTECTED
ACCESSORIES
AP43
+ AFTER PROTECTED CONTACT
B
+ BATTERY
BCP3
+ PROTECTED BA
TTERY CEILING LIGHTING
BP11
+ PROTECTED BATTERY > COCKPIT 1
BP27
+ PROTECTED BA
TTERY/ GMV COOLING, THERMO-CONTACT
BP54
+ PROTECTED BA
TTERY > FOG LIGHTS
BP7
+ PROTECTED BA
TTERY > G.M.V. SAFETY FUSE 1
C
+ HIGH-BEAM LIGHTS
CPD
+ RIGHT PROTECTED HIGH-BEAM LIGHTS
CPG
+ LEFT PROTECTED HI
GH-BEAM LIGHTS
D
+ STARTER CONTROL
H1
CONTROL - HANDBRAKE WI
TNESS, I.C.P. BRAKING CIRCUIT
H66P
CONTROL + BACKWARDS RUNNING LIGHTS
HK
LINE K DIAGNOSIS SIGNAL
HL
LINE L DIAGNOSIS S
IGNAL
L
+ POSITION LIGHT
LPG
+ LEFT PROTECTED POSITION LIGHTS
MA
RIGHT FRONT ELECTRIC MASS
MB
LEFT FRONT ELECTRI
C MASS
MF
RIGHT REAR
ELECTRIC MASS
MG
LEFT REAR
ELECTRIC MASS
ML
BATTERY ELECTRIC MASS
MN
LEFT WINDSCREEN CROSS ELECTRIC
MASS
MU
HANDBRAKE MASS
NF
MASS :AIR, WATER, TEMPERA
TURE SENSORS, POTENTI
OMETER
R
+ RUNNINGS LIGHTS
RPD
+ RIGHT PROTECTED RUNNI
NG LIGHTS
RPG
+ LEFT PROTECTED RUNNI
NG LIGHTS
S
+ ACCESSORIES
SP16
+ PROTECTED
ACCESSORIES
SP22
SUPPLY + PROTECTED
ACCESSORIES
SP3
+ PROTECTED
ACCESSORIES > GMV CLIMATE CONTROL
2A
CONTROL - CHARGE WITNESS
3AC
CONTROL - FUEL PUMP RELAY CONTROL
3AM
CONTROL - INJECTOR
3AQ
SIGNAL + VALVE POTENTIOMETER
3AY
IDLE MOTION SWITCH MASS SIGNAL
3B
SIGNAL + AIR TEMPERATURE SENSOR
3BB
CANISTER PURGING VALVE CONTROL
3BG
ENGINE ROTATION SIGNAL > ROTATION SENSOR
3BL
SIGNAL - ENGINE ROTATION > ROTA
TION SENSOR
3BR
+ AFTER CONTACT > M
AIN RELAY
3BU
IDLE MOTION REGULATOR CONTROL 1
3BV
IDLE MOTION REGULATOR CONTROL2
3C
SIGNAL+ WATER TEMPERA
TURE SENSOR
3CV
CONTROL - IGNITION COIL FOR CYLINDERS 1-4
3CW
CONTROL - IGNITION COIL FOR CYLINDERS 2-3
3FH
CONTROL- INJECTION DAMAGE WI
TNESS
WIRE FUNCTIONES EXPLANATION
